RoboCylinder: electric cylinder actuators of the latest generation are easy to use, have a high performance, are energy efficient and low in price.

With a wide product range and practical functions, they help in solving many different design-related problems.

The IAI single-axis robots are highly rigid actuators, usually equipped with ball screw (ISA/ISPA series), linear guide and AC servo motor. They work with a max. repeatability of ± 0.01 mm.

Easy operation by a special controller.

- Maximum payload: 120kg, maximum travel distance: 4.15m
- Due to the strong acceleration of max. 3G and a top speed of 2.5 m/s, the cycle time can be reduced significantly.
- Multi-slider and synchronous function.
- Wide range of models with the standard sizes: compact, small, flat, medium and large.
- Compact shaft type with small dimensions and a low price.
- Version with high thrust, suitable for large loads.

RCP2CR
RoboCylinder cleanroom types of the RCP2 series

RCACR
RoboCylinder cleanroom types of the RCA series

RCS2CR
Cleanroom Linear Robot with Elektrostatics Protection

- The dustproof and waterproof design of the actuators allows use even in adverse environments with suspended dust and splashing water.
- Depending on the application, select the slider, rod and SCARA version that is the most appropriate model for you.
- Depending on the working environment, the protective structure can be selected for suitable deployment in IP54, IP65 and IP67 protection classes.
- The type RCP2W-SA slider series provides waterproof models with IP67 class protection.

These are 2-, 3-, 4- or 6-axis robots made by combining single-axis robots, mounted at right angles to each other; this allows configurations such as "X + Y axis", "X + Z axis", "Y + Z axis", "gantry","X + Y + Z axis", etc. for up to 6 sliders.

In addition, a 4-axis combination, comprising either a 3-axis combination plus a single rotary axis of (RS) - or a 2-axis combination with a vertically movable rotary (ZR) are also possible.

- Repeatability: ±0.02 mm
- Integrated XSEL controller
- Choice between gantry and cantilever type
- Choice between 2 work envelopes: 200mm x 200mm and 400mm x 400mm
- Connection to fieldbus networks (optional)

- Swivel arm robot (horizontal 4-axis robot), "top of the class" with a high speed, high payload and precision.
- Compact and highly rigid
- Substantially improved path accuracy and interpolation function.
- Considerably simplified operation
- Simple to program
- Z-axis pressure function
- Straightforward installation of collision control zones.

The new Mini RoboCylinder is an achievement in small electromechanical cylinders. It incorporates a newly developed motor, and its significantly reduced length, width and height make it comparable in size to air cylinders.

The Mini RoboCylinder is the perfect replacement for air cylinders in systems that previously could only use air cylinders due to size constraints.

Shaped like an air cylinder and easy to use
The new RoboCylinder is available in shapes similar to air cylinders. Users accustomed to the operation of pneumatic systems are able to use the new RoboCylinder effortlessly.

Special IAI controller 24 VDC
Special IAI controller 230 VAC

With IAI, custom-specific control can be selected from three operating modes: Positioning, program or pulse train controls. Our wide product range offers the ideal control system for your application, too.

- Small robots - even easier to use.
- High functionality and high performance
- Various I/O extension cards
- Safety
