| TC100 HANDY |
The TC100 HANDY combines reliability and convenience by
means of intelligent technology and ergonomic design. The transmitter can easily
be operated single-handed.
Standard Model:
- 6 dual pressure pushbuttons with perceptible pressure point
- 3 pushbuttons
- 1 mushroom-head switch for stop-function
- 1 electronic selector switch
- 1 key switch
The TC100 HANDY is an inexpensive alternative to cable-based crane controls.
Innovative technology permits master/slave operation or tandem operation.
Latest synthesizer technology enables the operator to set or adjust frequencies
by means of DIP-switches. A carrying bag with or without a side window is
available. |
|
| EXCALIBUR |
With the latest ct24-technology and innovative ergonomics
for controlling all types of cranes and hoists anywhere in the world.
Two transmitter housing sizes are available; with 6 or 8 and 10 or 12
pushbuttons.
Standard Model:
- 6 or 8, 10 or 12 pushbuttons with excellent tactile feedback, herein
- 1 pushbutton STOP
- 1 pushbutton On/Horn
A wide range of applications from simple hoists, machine control or gate
control through to overhead travelling cranes.
Customer specific application configured via a transponder key (transKey).
3 different ct24 receivers are available depending on the number of output
commands required. |
|
| TC100 MINI |
The TC100 MINI combines innovative technology with perfect
design. The transmitter is robust and ergonomic in design.
Standard Model:
- 1 single axis joystick for 1 two-step drive 2-0-2
- 1 dual axis joystick for 2 two-step drives 2-0-2
- 2 pushbuttons
- 1 pushbutton on the side
- 1 mushroom-head switch for stop-function
- 1 key switch
- 1 three-way selector switch
Synthesizing technology and tandem operation are integral components of the
TC100 MINI-technology and optionally available. In addition to the basic version
the TC100 MINI is available with customized transmitter designs.
The transmitter is supplied with a cushioned waist belt or as option with a
user-friendly body harness.
|
|
 |
 |
 |
| TC200 MINI |
The TC200 radio remote control family of Cattron-Theimeg
features a modular design. This module system enables all available components
to be combined to form customized solutions.
Standard Model:
- 1 single axis joystick for 1 two-step drive 4-0-4
- 1 dual axis joystick for 2 two-step drive 4-0-4
- 3 pushbuttons
- 1 mushroom-head switch for stop-function
- 1 key switch
- 1 three-way selector switch
- PC interface for free configuration and diagnosis
The robust transmitter with its ergonomic design is capable of being used in
a wide range of applications. It is supplied with a cushioned waist belt which
offers maximum comfort. A body harness is also available upon request.
The transmission power of 10-500 mW allows maximal capacity.
The battery power is adequate for at least one shift with 80% ED. The TC200 MINI
transmitters are supplied with a plug-in charger unit. A processor-controlled
charger unit is as option available for a longer battery life and a rapid
recharging cycle.
In addition to the basic version the TC200 MINI is available with customized
transmitter designs. |
|
| TC200 EASY |
The TC200 radio remote control family of Cattron-Theimeg
features a modular design. This module system enables all available components
to be combined to form customised solutions.
Standard Model:
- 1 single axis joystick for 1 two-step drive 4-0-4
- 1 dual axis joystick for 2 two-step drive 4-0-4
- 3 pushbuttons
- 1 mushroom-head switch for stop-function
- 1 key switch
- 1 three-way selector switch
- PC interface for free configuration and diagnosis
The robust transmitter with its ergonomic design is capable of being used in
a wide range of applications and is supplied as standard with a cushioned waist
belt and offers maximum ease of wearing. A comfortable body harness is also
available.
In order to suit many applications the transmitter output power can be selected
between 10 and 500 mW.
In comparison to the TC200 MINI, the TC200 EASY housing offers a larger
operating element and is thus able to accommodate more control switches when
requested.
In addition to the basic version the TC200 EASY is also available with
customized transmitter designs.
|
|
| TH-EC/40 |
This fail-safe radio remote control system is the ideal
solution for highly customized applications. The transmitter can transmit up to
40 digital commands and can be equipped with up to 3 joysticks with maximum 6
steps. On the receiver side, up to 48 digital or analogue output channels are
available.
Standard Model:
- 1 single-axis joystick for 1 four-step drive
- 1 dual-axis joystick for 2 four-step drives
- 3 pushbuttons
- 1 mushroom-head switch for stop-function
- 1 key switch
- 1 three-way selector switch
- PC interface for system configuration and diagnosis
In order to suit many applications the transmitter output power can be
selected between 10 and 500 mW. The system can also be equipped with exclusive,
co-ordinated frequencies where required or requested by customers.
TH-EC/40 can optionally be supplied with a TDMA mode. This mode allows the
economical use of the frequency spectrum with up to 7 systems simultaneously
operating on the same frequency.
As a carrying aid the transmitter is supplied with a cushioned waist belt, a
comfortable body harness is also available.
|
|
|
|
 |
 |
 |
| TH-EC/LO-SFS |
The remote control system TH-EC/LO is recommended for use
in all types of locomotives and is compliant with the highest required safety
standards SIL3 (EN 50128), SIL3 (EN 50129) and SIL3 (EN 61508) as well as the
European Standard EN 50239 »Radio remote control system for traction vehicles
and freight traffic«.
The transmitter of the remote control family TH-EC/LO with its ergonomic design
is lightweight and easy to operate.
The transmitter TH-EC/LO-SFS is fitted with a single axis joystick. Up to 6
throttel/brake command positions are available. The first and the last step can
selectively be set as a momentary or maintianed step.
The order of the switches on the operating panel allows for single-handed
operation.
Standard Model:
- 1 key switch
- 1 mushroom-head switch for stop-function
- 1 single axis joystick, 5-step for throttle-/ brake commands
- 9 additional momentary or maintained switches
- 1 buzzer - warning signal
- time division multiple access frequency management system for up
- to 5 systems simultaneously on one channel in the same area
The transmitter housing conforms to protection class IP65. System functions
such as battery, transmitting and fault status are indicated via 3 LEDs. |
|
| TH-EC40/LO |
Remote Control for Shunting Vehicles.
The radio control system TH-EC40/LO has been especially developed and
manufactured for low speed shunting vehicles used at loading stations with low
safety requirements.
The TH-EC40/LO does not match the safety requirements according EN 50239.
The transmitter TH-EC/LO-VFS is fitted with a single axis joystick. The order of
the switches on the operating panel allows for single-handed operation.
Standard Model:
- 1 key switch
- 1 mushroom-head switch for stop-function
- 1 single axis joystick, 5-step for throttle-/ brake commands
- 9 additional momentary or maintained switches
- 1 buzzer - warning signal
The transmitter housing conforms to protection class IP65. As standard the
system is fitted with a high-power NiCd battery, the capacity is sufficient for
8hour operation. |
|
| TH-EC/LO-TFS |
The remote control system TH-EC/LO is recommended for use
in all types of locomotives and is compliant with the highest required safety
standards SIL3 (EN 50128), SIL3 (EN 50129) and SIL3 (EN 61508) as well as the
European Standard EN 50239 »Radio remote control system for traction vehicles
and freight traffic«.
The transmitter of the remote control family TH-EC/LO with its ergonomic design
is lightweight and easy to operate.
The transmitter TH-EC/LO-TFS is fitted with pushbuttons and switches for
throttle-/brake commands.
Standard Model:
- 1 key switch
- 1 mushroom-head switch for stop-function
- 2 pushbuttons for power control
- 9 additional momentary or maintained switches
- 1 buzzer - warning signal
- 3 status LEDs
- time division multiple access frequency management system for up
- to 5 systems simultaneously on one channel in the same area
The transmitter housing conforms to protection class IP65. System functions
such as battery, transmitting and fault status are indicated via 3 LEDs.
|
|
 |
 |
|
| TH-EC/LO-VFS |
The remote control system TH-EC/LO is recommended for use
in all types of locomotives and is compliant with the highest required safety
standards SIL3 (EN 50128), SIL3 (EN 50129) and SIL3 (EN 61508) as well as the
European Standard EN 50239 »Radio remote control system for traction vehicles
and freight traffic«.
The transmitter of the remote control family TH-EC/LO with its ergonomic design
is lightweight and easy to operate.
The transmitter TH-EC/LO-VFS is fitted with a dual axis joystick. The
throttle/brake commands are activated by moving in the appropriate direction.
The order of the switches on the operating panel allows for single-handed
operation.
Standard Model:
- 1 key switch
- 1 mushroom-head switch for stop-function
- 1 dual axis joystick 2 x 1-0-1 for throttle-/ brake commands
- 9 additional momentary or maintained switches
- 1 tilt switch
- 1 buzzer - warning signal
- time division multiple access frequency management system for up
- to 5 systems simultaneously on one channel in the same area
The transmitter housing conforms to protection class IP65. System functions
such as battery, transmitting and fault status are indicated via 3 LEDs.
|
|
| TH-AMR |
The TH-AMR terminal is a universal locomotive radio unit
for bi-directional data communication. The applications range from fully
automatic hump yard (ADT) operations to master/slave locomotive (MTT)
operations. The communication of TH-AMR is remote controlled so that no wiring
is necessary.
The universal locomotive radio unit TH-AMR is a fully redundant radio control
with the immediate evaluation of the received signal.
The transmission part has a dual processing feature, which sends out the signal
alternately.
The dual layout of the processor has three advantages:
- Increased availability of the terminal
- Increased safety of receiver signal
- Increased range
|
|
|
|
|
 |
 |
|
| IFD 3230 |
The intelligent data transmission radio system IFD 3230
can be used for point-to-point or point-to-multipoint communication
applications.
The IFD 3230 consists of a base station and up to 15 mobile units. The data sent
from the base station is received by all the mobile units, each automatically
verifying the data and processing if applicable.
This wireless data transmission system has been used successfully in marshalling
yards, where the pushing and shunting of locomotives is not automated, but is
manually done by the locomotive operator who receives from the signal box the
desired speed, which is displayed on his mobile unit.
Standard Model:
- Range: approx. 1.5 km (unobstructed)
- Current Consumption: max. 320 mA
- Supply Voltage: 12V/24V DC
- Interface: RS232 or RS422/RS485
8 Data Bits, no Parity, 1 Stopp Bit
9600 Baud Mobile Unit / 19200 Baud Base Station
- Frequency Range: 400 MHz bis 470 MHz (70cm Band)
- Channel Spacing: 20 KHz
- Transmission Rate: 4800bit/sec
- RF Output Power: 300 mW at 50 Ohm
The IFD 3230 is available as unidirectional or bidirectional version.
|
|
| HST 100 |
The high speed HST-100 offers a simple and quick data
communication link to terminals or serial interfaces, in any environment where
conditions are too difficult for a cable connection.
The HST-100 consists of two radio modems that establish a wireless
point-to-point link.
Standard Model:
- Range: 500m unobstructed
- Current Consumption: 250 mA
- Power Voltage: 12V/24V DC
- Serial Interfacing: 8 data bits, choice parity, 1 stop bit
1,2 k baud - 115,2 k baud
- Frequency Range: 2,4 GHz ISM Band; DSSST
- Channels: 58 (2,413 - 2,470 GHz)
- Transmission Rate: 1,84 Mbit/sec
- HF Output Power: 100 mW
The areas of application for the HST100 are the following:
- Measuring and test equipment
- Identification
- Production
- Automation
- Manufacturing
- Diagnostic
- Monitoring
- Facility management
|
|
|
|
|
 |
 |
 |
| MP96 |
| Multi-Processor, top-of-the-line system with up to 48
inputs and 96 outputs. The MP96 series offers the safety and dependability
required for operating machinery in harsh industrial environments. |
|
| TH-EC40 |
| Total modular design with 40 bit data transmission, up to
48 addressable outputs and up to six-stage joysticks. (Not available in the U.S.
or Canada) |
|
| AT |
| “Advanced Technology” and high performance with up to 32
outputs at an affordable price. |
|
 |
 |
 |
| TC200 |
Modular design and dual microprocessor technology allow
for a variety of configuration options.
(Not available in the U.S. or Canada) |
|
|
| LCAS |
| Collision avoidance with laser accuracy for overhead
cranes, hoists and machinery. |
|
E
