—Flange diameter: 30 mm
—Pulses: 4 to 7500
—Shaft

—Flange diameter: 65 to115 mm or 70 x 70 x 95 mm
—Pulses: 1 to 12500
—Aluminum / Stainless Steel
—Shaft and Hollow Shaft

—Flange diameter: 50 to 115 mm
—Pulses: 1 to 12500
—High Shaft Loads up to 100 N
—Shaft and Hollow Shaft

—Flange diameter: 24 to 40 mm
—Pulses: 1 to 7500
—Shaft and Hollow Shaft

—Flange diameter: 16 to 20 mm
—Pulses: 1 to 5000
—Shaft and Hollow Shaft

—Flange diameter: 9 mm
—Pulses: 1000
—Hollow Shaft
—Vacuum Hose

—Explosion Proof
—Shaft and Hollow Shaft.
—Flange diameter: 68 mm
—Heavy Duty
—Stainless Steel

—Explosion Proof
—Shaft and Hollow Shaft.
—Flange diameter: 24 mm to 68 mm
—Heavy Duty
—Aluminium / Stainless Steel

—Water Proof down to 50 meters under sea level, and Explosion Proof with ATEX certification.
—SSI - Profibus - CanOpen – Devicenet

—SSI
—Profibus
—CanOpen
—Devicenet
—Bit Parallel
—Ethernet TCP/ IP

—SSI
—Mini Hollow Shaft
—Flange diameter: 24 mm

—Explosion Proof
—Shaft and Hollow Shaft.
—SSI - Profibus - CanOpen - Devicenet
—Flange diameter: 78 mm
—For mining
—Stainless Steel

—Explosion Proof
—Shaft and Hollow Shaft.
—SSI - Profibus - CanOpen - Devicenet
—Flange diameter: 78 mm to 100 x 184 mm
—Off Shore and Extreme Heavy Duty
—Aluminium / Stainless Steel

This Explosion Proof Box can be used for
Scancon electronics for fiber optic
encoder signal transmission. Or can be
used for other applications as junction box.

Series SC 80:
Features:
Std. Interchangeble Design
Quadrature Dual Channels
Linedriver 3,3 VDC to 5,5 VDC

- Semi-absolute multi-turn, 32 bit resolution
- 50 mm to 115 mm diameter
- programmable functions
- 4,500 rpm max. operating speed

The module will protect the encoder
from malfunctioning due to disturbances
coming through the cable.
