"plug-in" version - Flow rate up to 275 l/min.

construction "plug-in" - Flow rate 550 at 3500 l/min. Valves islands 2005-2012 ISO 15407-2

Flow rate up to 900 l/min.

Different lengths of winding material are offset with cylinders piloted by proportional pressure regulators.The tensile stress is controlled at the same time.

The proportional pressure regulator controls the pinching force of the welding head depending on the material to be welded and its thickness.

The pressure acting against the roller is controlled with a proportional pressure regulator. Different thickness in the materials is offset.

The proportional pressure regulator is incorporated in the bypass of a vacuum pump. The brake booster is checked against the set-point.

Speed and torque are controlled by changing the pilot pressure.

The proportional valve controls the force acting against work pieces on grinding belts, pneumatic presses etc

A proportional valve adjusts the flow of steam until the desired temperature at the exchanger outlet is reached.

A proportional valve adjusts the flow of gas to the burner until you have the desired flame (heat) at the output.

Spray gun control: Control of paint flow and spray density, and of the surface of the part being painted.

The control unit uses four proportional valves to regulate the gas supply to the four burners.

Servovalves control the positions on palletising installations with distance sensors (linear potentiometers) mounted to rodless cylinders.

The proportional pressure regulator controls the pressure in dependence on the set-point. The volume of glue dispensed is dosed accordingly.

A new generation of DIGITAL electronic pressure regulators:

• DIRECT OPERATED : precise control and quick response times
• DYNAMIC : short stabilising periods and low oscillation frequency

Gives you full control over the parameters used inside the valve:

• Manual control: the incorporated DISPLAY and the two push-buttons
  enable pressure readout, pressure manual set-point and LED diagnosis
• Computer control :
  • Parameters features: this flexibility allows you to adapt the valve to your application and optimise its response time, accuracy and pressure control
  • Valve diagnosis: read valve information such as serial number and valve temperature, and watch the operation time using the operation counter. Read valve status and perform test functions for installation and service.
• Storage of parameters: once the optimal parameters are determined, you can store them in a project file for your personal use, or you may forward the file to our Product Support Department for future serial production..

The SENTRONIC valve with its internal control loop combines innovative pneumatic technology with the integrated analog electronics. This valve series allows for accurate adjustment of pressure, flow, force, speed, and linear or angular positions. All orifices have the same diameter for short response times when applying or exhausting pressure. The combined effect of all components assures a control behaviour at an extremely low hysteresis...

Unlike SENTRONIC valves, PULSTRONIC valves operate with pulsed pilot valves which change the pressure in a control chamber. A pressure booster converts the pilot pressure into an outlet pressure with increased flow. The outlet pressure is measured with a pressure sensor and fed into the internal control loop. The set-point is established over the electrical plug-in connector as a standard signal [0 to10 V, 0(4) to 20 mA]..
The PULSTRONIC is particularly suited for pressure control applications with a constant flow, e.g. flow control over nozzles, turbine speed control, glue and lacquer dosing, pressure control of welding equipment.

Greater versatility in automated production processes: due to electronics, the new generation of SERVOTRONIC products increases the range of application and performance of pneumatic components. The two SERVOTRONIC versions directly respond to all pressure and flow control needs and indirectly meet the performance in the control of physical variables, such as position, velocity, acceleration, force, mass, etc..
The combination of innovative pneumatic technology, high-precision mechanics and modern electronics allows for quick control of flow or pressure in a pneumatic actuating system in relation to a signal received from the controlling electronics.
The SERVOTRONIC valve is used for flow control (proportional flow) and is provided with a precision-lapped spool and sleeve with hardened and tempered surface allowing for very high pulse frequencies at extremely short response times. The SERVOTRONIC valve has a constant air consumption

These miniature proportional solenoid valves are particularly adapted to the very precise air and neutral gases control for medical or industrial applications.
Technology dedicated to precision
Better precision control is achieved by a special flat spring kit: 2 flat springs keep the core in suspension and give a perfect axial guidance without friction.

Main features

• Low hysteresis : <3%
• Excellent repeatability and sensitivity: <1%
• Does not require a minimum operating pressure
• Differential pressure: -0.9 to 10 bar
• Variable flow, proportional to the control signal
• No steps in flow curve
• PWM control signal (Pulse Width Modulation)
• Digital regulator or proportional control electronics available.

Did you know?
ASCO Numatics was a pioneer in the proportional pneumatics field in the 1980’s.
Are you looking for high frequency and a high flow accuracy?
Then FLOWTRONICD is for you.

Just give it your settings and you're away!
Whether your flow is constant or variable the regulating electronics control the opening and closing of the proportional valve to obtain the exact flow rate you want. Simple and efficient.

• Proportional valve
• Setpoint
• Control electronics
• Differential pressure sensor
• Pressure sensor
• Application requiring a controlled flow

The PIEZOTRONIC valve with proportional control is a high-tech solution designed in particular for those applications with an extremely low power consumption. It is suited for use with battery-operated equipment or in potentially explosive areas. Due to its long service life of 1 billion cycles it is also integrated in measuring systems such as medical equipment and gas analysers. It can even be powered by solar cells. Moreover, the PIEZOTRONIC valve is particularly suited for portable equipment because of its low weight.

POSIFLOW proportional valves can be used in practically all applications in which the flow of a liquid or gas needs to be controlled. Since a single proportional valve replaces two or three conventional valves connected in parallel (NO / NC) to obtain low, medium or high flow rates, it is extremely cost and space saving. The core is guided by two rider rings so that the valve has low friction and high dynamic properties. An electronic control unit which is directly fitted onto the POSIFLOW increases its range of application even further. The integrated potentiometer is used to adjust minimum current, maximum current and frequency. A current ramp which can be altered by a potentiometer can also be connected. Thus slow changes in flow can be obtained in spite of sudden changes in the set-point. In case of set-points < 200 mV (<.4 / 4.4 mA), the piloting current is completely switched off, so that the valve is without current (tightly closed function).
