Industrial motors & drive systems
ATB customers in the industrial motors and drive
systems sector primarily benefit from the company's extensive experience,
high quality standards and constant further development of its know-how.
|
|
|
|
Standard three-phase motors with squirrel cage rotor
Design: industrial motor with aluminium housing
Main applications: water and vacuum pumps, fans, compressors, drive
systems, transmissions
Special applications: machine tools, garden equipment, vehicles,
elevator doors, food machines, extruders
Performance range:0,06 - 37 kW
Size: 56 - 200
|
 |
Standard three-phase motors with squirrel cage rotor
Design: industrial motor with cast iron housing
Main applications: chemical industry, ship and marine
engineering, use under difficult environmental and general
conditions
Special applications: agricultural and construction
machinery, hydraulic systems, mixing machines, stone
processing equipment, separators
Performance range: 37 - 315 kW
Size: 225 - 355
|
|
Explosion-protected motors
Design: EEx e II ignition protection "Increased
Safety” type EEx de II ignition protection "Pressure-resistant sealing type,
in accordance with ATEX 100a
Main applications: areas subject to the danger of explosion such as
the chemical and petrochemicals industry, process engineering, drive systems
Special applications: environmental technology
Performance range: 0,09 - 165 kW
Size: 56 - 355
|
|
Brake motors
Design: with single-disk, spring brake
Main applications: machine tools, timber processing, drive
technology, transmission, process technology
Special applications: winches, jetways, elevators, stage equipment,
printing machines, packaging machines
Performance range:
0,06 - 37 kW
Size: 56 - 200
|
|
Single-phase motors with squirrel cage rotor
Design: With running capacitor and additional
starting capacitor and relay, with starting capacitor and relay
Main applications: ironing machines, grinding machines
Performance range:
0,07 - 2,2 kW
Size: 56 - 100
|
|
|
|
Special, customised motors without housings for the
following applications
Design: specific
Main applications: Industrial: meat processing
machines, office equipment, grain mills; Devices: ironing
machines, grinding machines
Performance range: specific
Size: specific
|
|
Asynchronous ATB FLEXIDRIVE
Design: modular squirrel cage rotor motor as a
standard, three-phase motor for low voltages, explosion protected motor,
brake motor, single-phase motor
Main applications: all types of industrial operations
Special applications: -
Performance range: -
Size: 63 - 90
|
|
ATB ECODRIVE economy class, three-phase motor
Design: industrial version with aluminium or cast
iron housing
Main applications: all types of industrial operations
Performance range:
0,25 - 55 kW
Size: 71 - 250
|
|
Ventilation technology systems – induced draught fans
for boilers
Design: Complete induced draught fans (motor +
attachment + impeller + housing) Integrated induced draught fan modules
(motor + attachment + impeller) for the 100 - 650 Pa pressure range, air
volumes of 200 - 4,000 m3/h and media temperatures of up to 300 °C
Main applications: Firing units, wood and billet wood fired boilers
Special applications: Pellet boilers, heating plants with straw
firing
Performance range: 30 W – 2.2 kW
Size: (45) 63 - 90
|
|
Ventilation technology systems – radial/circulatory fans
Design: Complete radial fans (motor + attachment +
impeller + housings + [accessories]) Radial fans – integrated modules (motor
+ [flange] impeller) For the 100 – 1,200 Pa pressure range and air volumes
of 300 - 1,000 m3/h.
Main applications: Heating branch, air conditioning/and drying
technology, ovens, curing chambers
Special applications: Railway technology, medicine technology,
ventilation and extraction
Performance range: 120 -750 W
Size: 63 - 90
|
|
|
|
Ventilation technology systems – axial ventilators
Design: Complete axial fans (motor + ring-/or
tubular housing with attached console + impeller + protective mesh) Used in
the 200 - 600 Pa pressure range and for air volumes of 2,000 - 8,000 m3/h.
Media temperatures - 40 to + 60 °C
Main applications: Rail vehicle transport technology, air
conditioning rail version
Special applications: Cooling and ventilation, air conditioning with
noise insulation
Performance range:
370 - 2200 W
Size: 63 - 90
|
|
Ventilation technology systems – system ventilators
Design: Complete axial fans (special motor + ring
housing with attached console + special impeller) Used in the low pressure
range for air volumes of 5,000 - 150,000 m3/h. Media temperatures of up to
135°C, aggressive ambient conditions , 100 % rel. humidity
Main applications: Air circulation for wood drying
Special applications: Air circulation for brick, glass and ceramic
drying, and the foods industry
Performance range:
0.37 - 22 kW
Size: 71 - 200
|
|
Ventilation technology systems – pellet transporters
Design Radial – high-pressure fans/side channel
compressors (motor + attachments + side channel compressor + accessories)
Max. transport capacity approx.15 m with 1.5“ or 2“ diameter and 3 m height
difference. With tube silencer (62dB(A) , 2’’ connection 160 -200 m3/h
volume flow, pressure up to 100 mbar (10,000 Pa)
Main applications: Fans for the transport of wood pellets
Special applications: -
Performance range:
1.5 kW ( 2.2 kW )
Size: 80 - 90
|
|
|
|
|
|
|
|
Servomotors
We offer the ideal servomotor for every specific drive
task, ranging from motors for rope elevator systems to drive technology for
production and machine tools.
|
|
|
|
Upgraded standard three-phase motors
Design: "V-series”, motor similar to standard,
optimised for frequency inverter operation
Main applications: machine tools, fans, pumps, textile machinery,
drive technology, food processing equipment
Special applications: conveyors, test stands, packaging machines,
stage equipment, jetways, cranes, elevators
Performance range:
with 1500 s/min. / 0.25 - 132 kW
Size: 63 - 315
|
|
Main spindle motors for dynamic applications
Design: Fully sealed and surface-cooled “KUV
series” main spindle motor in angular design
Main applications: machine tools, drive technology, test stands
Special applications: conveyors, textile machinery, packaging
machines, printing machines
Performance range:
with 1500 s/min. / 2.2 - 75 kW
Size: 90 - 180
|
|
Main spindle motors for dynamic applications
Design: Water cooled ”KUW series“ main spindle
motor in circular design
Main applications: vehicle drives, printing machines, paper machines
Special applications: conveyors, mining, extruders
Performance range:
with 1500 s/min. / 5 - 150 kW
Size: 90 - 180
|
|
AC-servo motors for highly dynamic applications
Design: "M.GN series”, brushless, permanent
excited, three-phase servo motor
Main applications: machine tools, textile machines, printing
machines
Special applications: handling, dosing, winding and paper
machines
Performance range:
with 3000 s/min. / 0.5 - 52 kW
Size: 70 - 190
|
|
Compact ATB DYNAMOT
Design: standard motor with integrated frequency
inverter
Main applications: fans, pumps, drive technology,
transmissions
Special applications: conveyors, mixing machines
Performance range:
at 1500 s/min. / 0.25 - 7.5 kW
Size: 63 - 132
|
|
|
|
Elevator motors
Design: three-phase, frequency inverter driven
motor
Main applications: passenger and freight rope elevators
Performance range:
at 1500 s/min. / 3 - 36 kW
Size: 100 - 200
|
|
Frequency inverters
Design: Digital converter with d.c. link for
general industrial applications
Main applications: all DC motor applications
Special applications: -
Performance range:
0,3 - 250 kW
Size: -
|
|
|
|
|
|
|
|
|
|
Motors for house and garden appliances
ATB drive technologies also guarantee top quality and
reliability for house and garden applications. ATB drives are used in this
area for everything from water pumps, lawn mowers and choppers, to
high-pressure cleaning devices.
|
|
|
|
ATB MULTIDRIVE
Design: with and without fan
Main applications: all types of industrial uses, e.g. pump
drives, fans and grain mills
Special applications: -
Performance range:
P1=0,02 - 2,6 kW
Size: 45 - 90
|
|
ATB MULTIDRIVE
Design: with and without fan
Main applications: lawn mowers, chopping machines, lawn
aerators, concrete mixer, etc.
Special applications: -
Performance range:
P1=0,8 kW to P2=3,0 kW
Size: 71, 80
|
|
ATB MULTIDRIVE
Design: with fan
Main applications: high-pressure cleaning machines, etc.
Special applications: -
Performance range:
P1=1,2 kW - 4,6 kW
Size: 80 - 100
|
|
ATB MULTIDRIVE
Design: with rectangular external contour
Main applications: document shredders, machine tools, drills,
hobby devices, etc.
Special applications: -
Performance range:
from P2=0,02 kW - 0,3 kW
Size: 45
|
|
ATB MULTIDRIVE
Design: wet running copper rotor motors
Main applications: heating and cold water pumps, etc.
Special applications: -
Performance range:
P2=0,01kW - 0,55 kW
Size: 1, 2, 3, 12, 14
|
|
|
|
POWER PACK
Design: available with internally and externally
mounted fan
Main applications: lawn mowers, chopping machines, lawn
aerators, high-pressure cleaning, machines, pumps, etc.
Performance range:
P2=0.8kW - 2.2 kW
Size: POWERPACK
|
|
|
|
|
|
|
|
|
|
|
|
Explosion-proof electrical motors
|
|
|
|
Low Voltage Motors
Design: Low-noise three-phase a.c. motor
This version is particularly low-noise. The split terminal
box enables easy connection.
Special applications: -
Performance range: 0,06 – 800
Ex-proof: II 2 G EEx de IIC T4
|
|
Energy-Efficient Motors
Design: Energy-efficient motors with special
components
Special applications: -
Performance range: 1,1 - 90
Ex-proof: II 2 G EEx de IIC T4
|
|
Special Motors
Design: Motor with integral brake or tacho-generator.
This compact method of construction offers significant
advantages in terms of space and the possibility of
attaching a second shaft end.
Special applications: -
Performance range: 0,55 - 30
Ex-proof: II 2 G EEx d(e) IIB T4
|
|
Special Motors
Design: Motor with attached brake
Special applications: -
Performance range: 0,55 - 250
Ex-proof: II 2 G EEx de IIC T4
|
|
Special Motors
Design: Motor with attached DC tacho-generator
Special applications: -
Performance range: 0,55 – 30
Ex-proof: II 2 G EEx de IIC T4
|
|
|
|
High Voltage Motors
Design: Low noise high voltage motor. This motor is
particularly low in noise and is equipped with built-in
temperature sensors for monitoring the bearings. An
additional terminal box for PT 100, anti-condensation
heaters, etc. is also provided.
Performance range: 160 – 800
Ex-proof: II 2 G EEx de IIC T4
|
|
Compact Drives
Design: Compact motor type CD 112 M-4I. With this
design, the motor can be directly installed and the drive speed can be
controlled
Special applications: Voltage: 380 to 500 V
Performance range: 0,55 – 11
|
|
Frequency Inverters
Design: MX DRIVEŽ frequency inverter: in the
version suitable for chemical environments, with bypass and additional
devices in compliance with VIK-NAMUR guidelines.
Performance range: 4,0 - 800, For a motor rating from 250 kW
|
|
|
|
|
