Measuring range mm(in): 320(12); 620(24); 1020(40)
Resolution mm(in): 0.01/0.001 (.0005/.00005)
Max. permissible errors 1) mm: 0.02: 0.03; 0.04
Repeatability (2s) 1) mm: 0.005
Displac. speed of the measuring carriage mm/s: 1.5
Measuring force N: 3
Frontal squareness deviation 1) mm: 0,02; 0.03; 0.03
Data output: OPTO RS232
Height (with cast iron base) mm: 513; 813; 1275
Height (with granite base) mm: 558; 858; ---
Weight (with cast iron base) kg: 6.2; 10.5; 24
Weight (with granite base) kg: 14; 18.3; ---

Measuring range mm(in):
370(14); 620(24) --- 370(14); 620(24)
Application range mm(in):
450(18); 700(28) --- 450(18); 700(28)
Resolution mm(in): 0.01/0.001 (.0001/.00005)
Max. permissible error 1) μm: 8; 10; 3+ L(mm)/200
Repeatability (2s) 1) μm: 2 (Ø : 4) --- 2
Displac. speed of the measuring carriage mm/s: 1.5
Measuring force N: 0.8
Battery life h:
100 (without air cushion) --- 40 (without air cushion)
Frontal squareness deviation μm: 15; 20 --- 8;12
Data output: RS232C
Operational temperature °C: +10 ... +40
Weight kg: 10; 12 --- 10; 12

Measuring range mm(in): 300(12); 600(24); 1000(40)
Application range mm(in): 535(21); 835(32); 1235(48)
Resolution mm(in): 0.01/0.001 (.0001/.00005)
Max. permissible errors μm: 2.5 + L(mm)/300
Repeatability (2s) μm: 2
Displac. speed of the measuring carriage mm/s: 1.5
Measuring force N: 0.7 - 1.6 (0.3 - 1.2 version 305C+)
Battery life (without air cushion) h: 100
Battery life (with air cushion) h: 30
Frontal squareness deviation μm: 5; 8; 12
Data output: RS232C
Operational temperature °C: +10 ... +40
Total height mm: 565; 965; 1275
Weight kg: 10; 12.3; 15.3

Measuring range mm(in): 364(14); 620(24)
Application range mm(in): 464(18); 720(28)
Frontal squareness deviation μm: 8/5; 10/6
Max. permissible errors μm: 3 + L(mm)/200
Resolution mm(in): 0.001 (.00005)
Repeatability (2s) μm: 2
Displac. speed of the measuring carriage mm/s: 0.2
Measuring force N: 0.25 - 0.5
Battery life h: 10
Data output: RS232 / Centronics
Weight kg: 11.5; 13

Measuring range mm(in):
305(12); 610(24); 1046(40) --- 1524(60); 2034(80)
With second probe holder mm(in):
267(22); 872(34); 1278(50) --- 1786(70); 2296(90)
Max. permissible errors μm:
2 + L(mm)/400 --- 2.5 + L(mm)/300
Repeatability (2s) μm: 1 (Ø : 2)
Resolution mm(in):
0.01 / 0.001 / 0.0001 (.001 / .0001 / .00001)
Manual carriage displacement speed mm/s: 1000
Motorized carriage displacement speed mm/s: 150
Measuring force N: 0.5 ... 1.8
Power supply limit h: >8
Frontal squareness deviation μm: 4; 6; 10 --- 15; 25
Data output: 2 x RS232 C and 2 x USB (A and B)
Operational temperature °C: +10 ... +40
Temperature of storage °C: +-0 ... +40
Total height mm: 645; 950; 1357 --- 1866; 2376
Weight kg: 20; 23; 27; 39; 44

Measuring range mm(in): 305(12); 610(24); 1016(40)
With second probe holder mm(in): 567(22); 872(34); 1278(50)
Max. permissible errors μm: 1.2 + L(mm)/1000
Repeatability (2s) μm: 0.5 (Ø : 1)
Resolution mm(in): 0.01 / 0.001 / 0.0001 (.001/.0001/.00001)
Manual carriage displacement speed mm/s: 1000
Motorized carriage displacement speed mm/s: 150
Measuring force N: 0.5 ... 1.8
Power supply limit h_ >8
Frontal squareness deviation μm: 4; 6; 10
Data output: 2x RS232 C and 2 x USB (A and B)
Operational temperature °C: +10 ... +40
Temperature of storage °C: -10 ... +40
Total height mm: 645; 950; 1357
Weight: 20; 23; 27

Measuring range for internal measurements mm(in):
10 - 100 (.4-4)
Measuring range for external measurements mm(in):
0 - 100 (0-4)
Max. permissible errors (according to measuring element used) μm: 1.5
Repeatability (2s) μm: 0.1
Resolutions (according to measuring element used) mm(in): 0.1 to 0.0001(.001 to .00001)
Measuring force N: 3 - 8
Weight kg: 15

Internal measuring range mm(in):
1 - 305 (.04 - 12); 1 - 505 (.04 - 20)
External measuring range mm(in):
25 - 325 (1 - 13); 25 - 525 (1 - 20)
Max. permissible errors μm: 1.5 + L(mm)/300
Repeatability (2s) μm: <1
Resolution mm(in): 0.001 (.00001)
Displacement speed of measuring carriage mm/s: 50
Data output: RS232
Operational temperature °C: +10 ... +40
Weight kg: 50; 75

Measuring range mm(in):
520 (20); 1020(40); 1520(60); 2020(80)
Max. permissible errors μm: 2.5 + L / 300
Repeatability (2s) μm: 1
Resolution mm(in): 0.01/0.001 (.0001/.00005)
Measuring force N: 3
Displacement speed of measuring carriage m/s: 1.5
Data output: RS232C
Operational temperature °C: +10 ... +40
Weight kg: 94;126; 158; 190

Measuring range mm: 550;1050; 1550; 2050; 3050
Max. permissible errors μm: 0.7 + L(mm)/1000
Repeatability (2s) μm: 0.2
Max resolution mm: 0.0001

Absolute measuring range mm(in): 50(2)
Application range (internal) mm(in): 5-100(2-4)
Application range (external) mm(in): 0-100(0-4
Max. permissible errors 1) μm: 0.2+ L (mm) /250
Repeatability (2s) 1) μm: 0.1
Resolutions (according to display unit) mm(in):
0.01 to 0.00001 (.0001 to .000001)
Measuring force (adjustable) N: 0-4
Weight (without stand) kg: 22
Weight (with stand) kg: 41

Measuring range mm: 550;1050 --- 550;1050
Max. permissible errors μm:
0.3 + L(mm)/1500 ---  0.15 + L(mm)/2000
Repeatability (2s) μm: 0.1 --- 0.05
Max resolution mm: 0.00001

Measuring range mm(in): 350(14)
Application range mm(in): 0-350(14); 0-600(24); 0-1100(44)
Max. permissible errors μm: 0.7 + L(mm)/2000
Repeatability (2s) μm: 0.03
Max resolution mm: 0.000001= 1nm

Measuring range, length X mm(in):
400(15) --- 800(31); 1200(47); 2000(78)
Measuring range, diameter Y mm(in): 125(5) --- 125/160(5/6)
Max. permissible errors, length X μm: 3 + L (mm) / 100
Max. permissible errors, diameter Y μm: 1.5 + D (mm) / 100
Repeatability, length X (2s) μm: ≤ 2.0
Repeatability, diameter Y μm: ≤ 1.0
Resolution, length X mm(in): 0.001 / 0.0001
Resolution, diameter Y mm(in): 0.001 / 0.0001
Measuring force, length and diameter N: 2.0
Electrical connections: 230V / 50Hz, 0.2 kVA
Max. part weight kg: 10 / 20 / 100
Weight (instrument) kg: 120 --- 140: 180; 240

Measuring range μm: Ra, Rq :
0 - 20 / all other meas. values : 0 - 200
Resolution μm: Ra, Rq :
0.01 (<0.1 μm : 0.001)/all other meas. values: 0.1
Precision category according to ISO/EN/DIN: 1 (5%)
Cutoff Ic mm: 0.25, 0.8, 2.5
Traversing length It mm: 1.50, 4.8, 15.0
Traversing length CNOMO mm: 1, 2, 4, 8, 16
Humidity: max. 80%, not condensable
Diamond stylus tip: 5 μm, 90° (standard) or 2 μm, 60° (option)
Statistical measuring force, stylus tip mN: < 0.5
Statistical measuring force, sliding skids N: < 0.15
Traversing speed mm/s: 0.5
Reverse motion mm/s: 1.0

Measuring range in X mm: ---; 100; 100
Measuring range in Y mm: ---; ---; 100
Vertical displacement range Z mm: 240
Max. weight of the component kg: 20
Weight of the instrument kg: 80

Measuring range diameter (X) mm(in): 20(8) --- 300(12)
Measuring range length (Z) mm(in):
300(12); 400(16); 600(23); 700(27); 800(31); 1000(39)
Resolution mm(in): 0.01/0.001 (.0005/.00005)
Autonomy h: 2000
Data output: RS232
Weight kg: 21 --- 35; 36; 37: 38; 40

Measuring range diameter (X) mm(in): 310(12) --- 462(18)
Measuring range length (Z) mm(in):
320(12); 422(16) --- 523(20); 1228(48)
Max. concentricity error of tool spindle mm: 0.002
Resolution mm(in): 0.001(.0001)

Measuring range diameter (X) mm(in): 310(12) --- 462(18)
Measuring range length (Z) mm(in):
320(12); 422(16) --- 523(20); 1228(48)
Max. concentricity error of tool spindle mm: 0.002
Resolution mm(in): 0.001(.0001)
