miniBOOSTER introduces its new M-HC-013 In-line Intensifier System

Photo by miniBOOSTER Hydraulics

Key features

• Automatic activated (sequence valve)
• High Pressure – up to 700 bar (10,000 psi)
• Fast fill – system flows up to 100 l/min
• Extended Service Life
• Robust Design
• Flexible Design–several boosters / intensification ratios
• Switch from by-pass to intensified flow
• Max inlet pressure = 345 bar
• Adjustable outlet pressure

Description

The M-HC-013 In-line Intensifier System is designed to boost the hydraulic pressure from the pump to the workload. It operates when and only when needed, for the sake of saving energy.

The system is dynamical by means of being able to provide flow at high pressure for intermittent use (< 10 min duty cycle).

The function of the system is simple, but smart. The hydraulic oil is by-passed directly from the pump to the workload at maximum flow when back pressure from the workload has reached a set point close to the maximum pressure of pump.

A sequence valve opens and directs the oil to the booster, which rises the pressure. The shift between maximum pump pressure and high pressure happens without intervention from the user and ensures that the workload at all time will be driven at a maximum speed in relation to the high pressure needed.

A relief valve is installed to valve control the maximum allowable pressure the system can output, allowing the booster to go for a higher end pressure producing flow at the decided pressure.

Easy installation

The M-HC-013 is provided with four mounting holes for through bolt installation. The four connection ports are placed logically in pairs and in line of each other on the HIC block. All surfaces are electroplated for good protection and fine surface finish.

Typical Applications

Mobile attachments (Motors – Steering Systems – Cutters – Crushers – Shears), Off Highway Equipment, Injection Molding Machines and Hydraulic Presses. Applicable for machines with insufficient pump capacity to prevent machine stoppage when peak pressures occur.

For more information, please visit http://www.minibooster.com.
