US Digital introduces optical commutation encoder for BLDC motors

The high performance 35mm commutation kit encoder EC35 works perfectly with brushless DC motors. It has a high resolution, resulting in better accurate timing than Hall effect sensors. The EC35 optical commutation encoder makes assembly for OEM applications an easy task.

Commutation Encoder

EC35 Optical Commutation Kit Encoder
Photo by US Digital

 The EC35 has following  include

  • A/B/Z Differential Outputs
  • Frequency Response from DC to 1 MHz
  • 500 – 10.000 Cycles Per Revolution (CPR)
  • 2.000 – 40.000 quadrature states per revolution
  • U/V/W commutation outputs (differential or open-collector)
  • Fits shaft diameters from 0.197″ (5mm) – 0.394″ (10mm)



The EC35 is ideal for high volume, low cost, OEM motion control applications. “The EC35 encoder is being introduced into the BLDC motor motion control market to fill customer’s needs for a cost competitive, simple to assemble, high performance commutation encoder that has the virtue of being manufactured in a vertically integrated, US encoder factory. This vertical integration enables the EC35 to be an extremely reliable product for supply chain management,” states Jim Stevens, VP of Sales & Marketing.

Like US Digital’s current encoder offerings, the EC35 will feature quick delivery, high reliability and competitive pricing. US Digital manufactures precision motion control products, including incremental and absolute encoders, inclinometers, interfaces, drives and more

For further information visit: www.usdigital.com/
