Qioptiq releases new mini camera tubes for Optem FUSION Lens Systems

Photo by Qioptiq

Photo by Qioptiq

Qioptiq introduces New Mini Camera Tubes for Optem FUSION Lens Systems to reduce lens assembly length and streamline OEM system integration. The Optem FUSION Lens System delivers extreme imaging versatility for OEMs, researchers and system integrators who require precision micro imaging performance.

The modular design allows user-configurable modification of performance, function and form. Simple change-out of modules defines a wide range of performance envelopes for 7:1 or 12.5:1 zoom imaging, Or replace the zoom module with a Fixed-Aperture Module and users can configure a wide range of economical fixed-magnification lenses.

Mini Tubes are 60% shorter than their standard-length FUSION Camera Tube counterparts for easier integration in space-constrained systems. Available in 0.8X, 1.0X, 1.5X, 2.0X, 2.5X and 3.0X magnifications, Optem FUSION Mini Camera Tubes now optimize sensor coverage for camera formats up to 43mm diagonal. Additionally, the compact design further reduces lens length and streamlines integration by delivering higher-magnification to most any size sensor and yielding magnification as high as 12X without the cost and length of microscope objectives.

Superior optical design ensures near-zero distortion for precision imaging and Mini Camera Tubes are compatible with the full array of FUSION Camera Mounts to accept C, CS, F, EOS, 4/3 and other camera mount types. All Mini Tubes are internally focusable via an adjustable inner cell for easier parfocality calibration and system setup.

Optem FUSION Lens System options include integrated LED illumination, internal fine focus, manual or motorized zoom and/or focus, and a wide range of accessories. It is ideal for use in optical metrology, wafer processing, inspection, machine vision, material analysis, crystal monitoring, well plate scanning and more.

For more information, please visit http://www.qioptiq.com.
