Qioptiq’s new Mag.x System 125 comes with built-in autofocus components

Photo by Qioptiq

Photo by Qioptiq

Qioptiq is expanding their modular, high-performance mag.x system 125 by the addition of built-in autofocus components. The new AF base unit and the piezo-module can now be used to create an automated microscope system with through-the-lens autofocus.

The mag.x system 125 is an industrial microscope system specially developed for use with large sensors – up to 57 mm diagonal – to enable sub-micrometer resolution over large object fields. This unmatched optical performance is achieved with high numerical aperture lenses that feature an exceptionally large exit pupil.

Exact focusing is essential when using resolutions this high. To simplify focusing in an automated environment, Qioptiq has integrated a complete, modular autofocus solution in the mag.x system 125. The piezo-module plays the active role: in a fraction of a second it focuses to within a few nanometers of accuracy. The new AF base unit couples the laser from an autofocus sensor into the beam path. The autofocus sensor and piezo-module constitute a closed-loop system that ensures optimum focus in object plane. The modular design and open interfaces make a number of configurations possible, so the device is compatible with a wide range of applications.

Thus Qioptiq enables the use of microscopy technology for inspection of large areas and objects using large area or line sensors. Since no stitching is needed and high-resolution sensors can be used, the mag.x system 125 enables significantly shorter tact times without compromising the resolution of the inspection system.

For more information, please visit http://www.qioptiq.com.
