Offer Profile
Individual solutions with
efficient systems for all fuel types and applications
Viessmann sets the technological pace for the heating industry. The
comprehensive product range from Viessmann offers individual solutions with
efficient systems for all applications and all types of fuel. As
environmental pioneers, the company has been supplying particularly
efficient and clean heating systems for oil and gas, as well as solar
thermal systems and heating systems for sustainable fuels and heat pumps,
for decades.
The comprehensive product range from Viessmann offers superior technology
and sets new benchmarks. With its high energy efficiency, this range helps
to save heating costs and is always the right choice where ecology is
concerned.
|
|
|
|
Product Line Up
|
Combined heating and power stations
Tailor-made energy concepts for applications
requiring a medium output in municipal buildings, and industrial and
commercial enterprises.
A gas driven combined heat and power unit (CHP) generates heat and power
simultaneously. They are sized to suit residential units and commercial
operations. On the heating side, the CHP unit operates in parallel to a
boiler. For generating heating water and DHW heating, both heat sources are
connected to the heating system.
|
|
|
|
Vitobloc 200 EM-18/36
Vitobloc 200, module EM-18/36 in combination with a peak load boiler is
ideal for residential complexes from 30 to 50 units, for medium-sized
hotels, residential homes for the elderly, and car showrooms, etc. With an
overall efficiency of 96.4%, the mini CHP unit operates highly efficiently
thanks to its condensing technology and is recommended both for new build
and modernisation projects.
Specification
Output: 18 kWel, 36 kWth
Fuel: Natural gas
4-cylinder gas engine
Efficiency: 96.4% (Hi) – High efficiency through condensing technology
|
 |
Vitobloc 200 EM-50/81
An additional powerful version is the mini CHP Vitobloc
200, module EM-50/81, which offers an overall efficiency of 90.3%. This CHP
unit is also eligible for subsidies through to the mini CHP incentive
programme [Germany].
Specification
Output: 50 kWel, 81 kWth
Fuel: Natural gas (biogas on request)
4-cylinder gas engine
Efficiency: 90.3% (Hi)
Operation with a heating bias eligible for subsidies in Germany
according to the Mini-CHP Incentive Programme
|
|
Vitobloc 200 EM-70/115
Specification
Output: 70 kWel, 115 kWth
Fuel: Natural gas (biogas on request)
6-cylinder gas engine
Efficiency: 90.7% (Hi)
|
|
|
|
Vitobloc 200 EM-140/207
Specification
Output: 140 kWel, 207 kWth
Fuel: Natural gas (biogas on request)
6-cylinder gas engine
Efficiency: 90.4% (Hi)
|
|
Vitobloc 200 EM-199/263
Specification
Output: 199 kWel, 263 kWth
Fuel: Natural gas (biogas on request)
6-cylinder gas engine
Efficiency: 89,6.(Hi) – High electrical efficiency through external
mixture cooling
|
|
Vitobloc 200 EM-199/293
Specification
Output: 199 kWel, 293 kWth
Fuel: Natural gas (biogas on request)
6-cylinder turbo-charged gas engine
Efficiency: 89% (Hi)
|
|
|
|
Vitobloc 200 EM-238/363
Specification
Output: 238 kWel, 363 kWth
Fuel: Natural gas (biogas on request)
12-cylinder gas engine
Efficiency: 90.1% (Hi)
|
|
Vitobloc 200 EM-363/498
Specification
Output: 363 kWel, 498 kWth
Fuel: Natural gas (biogas on request)
12-cylinder turbo-charged gas engine
Efficiency: 89,7% (Hi)
|
|
Vitobloc 200 EM-401/549
Specification
Output: 401 kWel, 549 kWth
Fuel: Natural gas (biogas on request)
12-cylinder turbo-charged gas engine
Efficiency: 92.7% (Hi) – High electrical efficiency through external
mixture cooling
|
|
|
|
Control technology
|
|
|
|
Vitotronic - Control systems for freestanding and
wall-mounted boilers
Vitotronic: economic energy management for all system
sizes
Vitotronic control units think for you – from installation through operation
to maintenance. Whether used in an apartment, a detached home or in large
systems, they offer the optimum solution for every need. As digital control
systems with communication capability they ensure an economical and reliable
operation of your heating system with well thought out electronic
management.
|
|
New Vitotronic 200 for all compact appliances
Now operating the new oil/gas fired and heat pump
compact appliances is actually fun.
The large graphic display offers several lines of plain text.
With the new Vitotronic generation of programming and control units for the
new oil/gas fired and heat pump compact appliances, Viessmann introduces a
control system with user prompts for heating systems. Navigation is as easy
as can be and mirrors the well-known scroll wheel you are familiar with from
mobile phones or TV remote controls.
|
|
Vitosolic - Solar control units
Vitosolic: Intelligent energy management
Solar heat is especially effective when Vitosol solar collectors are used in
conjunction with the Vitosolic energy management. The Vitosolic solar
control units cover all conventional applications and can control up to four
separate consumers. Data is exchanged via the KM BUS with the
weather compensated Vitotronic control unit.
|
|
|
|
Data communication
|
|
|
|
Vitocom 100
Monitoring a heating system made easy via mobile phone
The Vitocom 100 offers affordable and uncomplicated remote monitoring,
specifically designed for the requirements of holiday homes as well as
detached houses and twofamily homes. As a result, you can rely on 24 h/365
day supervision of all relevant monitoring and control functions.
Everything under control – even from afar
To be able to monitor and control a heating system from anywhere and at any
time is an invaluable benefit. One "call" is enough to ensure that your home
is comfortably warm when you arrive. Operation via simple SMS commands.
Faults are also reported to a mobile phone via SMS – in plain text.
|
|
Vitocom 200
Data communication – easier and more reliable
The Vitocom 200 is a stand-alone remote monitoring device with integral,
web-based user interface. An attractively priced solution offering ideal
conditions for comprehensive data communication – perfect for private homes
and smaller utility buildings, for example public facilities such as
kindergartens.
Monitoring and operating your heating system via the internet
Access to your heating system and its operation can be provided by a
standard PC or a Smartphone. No additional software is required. All you
need when utilising a mobile phone network is internet access for the
programming unit and the connection between the Vitocom 200 and the
Vitotronic of the heating system. Using analog landlines with dial-up
connection requires a modem and WebBrowser.
|
|
Vitocom 300
Remote monitoring – convenient and comprehensive via
the internet
The Vitocom 300 offers powerful communication for larger residential
complexes and utility buildings, making it a particularly valuable tool for
heat utilities such as heat contractors or municipal utilities. All heating
systems are connected to the Vitodata 300 server, enabling access to the
relevant system data via the internet. It enables a rapid and affordable
check, maintenance and optimisation of heating systems.
High performance, low
costs
No specific costly control centre software, software updates or local
software required. The Vitocom 300 and the central Vitodata 300 server host
all functions. Connection requires no specialist know-how. What about
configuration? Very simple via the internet.
|
|
|
|
Vitohome 300
Increase convenience and lower heating costs at the
push of a button
Vitohome 300 from Viessmann is a wireless home automation system that offers
greater convenience and still manages to reduce energy consumption. It
enables an individual adjustment of the temperature in each room, in
accordance with the lifestyle of the occupants. Once set up, the Vitohome
300 automatically safeguards the required temperature – individually in
every room and at any time of day or night.
|
|
Vitogate 200
For the following heating systems with Vitotronic
control unit:
- Single and multi-boiler systems with freestanding
boilers
- Wall mounted and compact boilers
-
Remote control of heating systems via suitable visualisation facilities
(e.g. switching, changing set values)
-
Transmission of up to 34 data points that can be configured (incl. one fault
bit and one fault byte).
-
Data transmission via LON from the Vitotronic to the - Vitogate 200 and
vice-versa
-
Data transmission via EIB from the Vitogate into the KNX/EIB system and
vice-versa (on-site connecting cable). The BUS protocol used is matched to
the existing on-site KNX/ EIB system
|
|
|
|
|
|
Domestic hot water cylinders
Domestic hot water cylinders, 80 to 1000 litres
The demand for hot water is completely different in every household. One
factor is the number of residents and another is their bathing and showering
habits. For example, several people in one household frequently go to work
and school at the same time, so lots of hot water needs to be continuously
available for the shower in a short space of time. Those who prefer a bath
will also want to have enough hot water to fill the tub. Finally, the DHW
cylinder should also provide sufficient water if, in an apartment block for
example, hot water is drawn from more than one outlet at the same time. The
Vitocell DHW cylinders fulfil these requirements in every respect and can
also meet every aspiration where equipment levels are concerned. In all
instances, the installation of a solar thermal system is recommended to save
energy and heat the water without cost.
|
|
|
|
Vitocell 100-V
Type CVA / DHW cylinder made from steel with
Ceraprotect enamel coating
160 to 1000 litres capacity
|
|
Vitocell 300-V
Hygienic, convenient and economic DHW heating with DHW
cylinders made from stainless steel – vertical version. 130 to 500 litres capacity
|
|
Vitocell 100-H
DHW cylinder made from steel with Ceraprotect enamel
coating
130 to 200 litres capacity
|
|
Vitocell 300-H
DHW cylinder made from stainless steel
160 to 500 litres capacity
|
|
|
|
Vitocell 100-W
DHW cylinder for wall mounted boilers, made from steel
with Ceraprotect enamel coating
120 to 300 litres capacity
|
|
Vitocell-300-W
DHW cylinder for wall mounted boilers, made from
stainless steel
160 and 200 litres capacity
|
|
Vitocell 100-L
DHW cylinder made from steel with Ceraprotect enamel
coating
500, 750 and 1000 litres capacity
|
|
Vitocell 100-U
DHW cylinder for dual-mode DHW heating
300 litre capacity
|
|
|
|
Vitocell 100-B
Domestic hot water cylinder with two indirect coils.
Constructed from steel with Ceraprotect enamel finish.
Capacity: 300, 400 and 500 litres.
|
|
Vitocell 300-B
Domestic hot water cylinder with two indirect coils.
Constructed from stainless steel.
Capacity: 300 and 500 litres
|
|
Vitocell 100-W
Domestic hot water cylinder with two indirect coils.
Constructed from steel with Ceraprotect enamel finish.
Capacity: 300 litres
|
|
Vitocell 100-V
Type CVW / DHW cylinder made from steel with
Ceraprotect enamel coating
390 litres capacity
|
|
|
|
Vitocell 100-E
Hot water storage cylinder
200 (Type SVW) 400, 750 and 950 (Type SVP) litres capacity
|
|
Vitocell 140-E
Heating water buffer cylinder with integral solar heat
exchanger
Capacity: 750 and 950 litres
|
|
Vitocell 160-E
Heating water buffer cylinder with integral solar heat exchanger
Capacity: 750 and 950 litres
|
|
Vitocell 340-M
Multi-mode heating water buffer cylinder with integral
DHW heating
750 and 950 litres capacity
|
|
|
|
Vitocell 360-M
Multi-mode heating water buffer cylinder with
stratification primary system and integral DHW heating
750 and 950 litres capacity
|
|
|
|
|
|
|
|
|
|
Gas fired boilers, 7 to 144 (432) kW
|
|
|
|
Vitopend 200-W
Wall mounted gas fired boiler
Rated output: 10.5 to 24 kW
The solution for affordable and convenient heat
With the Vitopend 200-W, Viessmann offers a wall mounted gas fired boiler
with a particularly advantageous price/performance ratio, excellent heating
and operating convenience, compact dimensions and a timeless, elegant
design.
Price and performance in perfect harmony
The Vitopend 200-W is one of the most affordable in its class, not only in
the purchase price, but also where running costs are concerned. After all,
it can achieve a high standard efficiency of up to 85 % (Hs) / 94 % (Hi).
|
|
Vitogas 200-F
Low temperature gas fired boiler
Rated output: 11 to 60 kW
Atmospheric low temperature gas fired boiler
The Vitogas 200-F up to 60 kW is the smallest model in the freestanding gas
fired boiler range from Viessmann. It is highlighted by its high
performance, operational reliability and long service life. Both its price
and dimensions make it an attractive choice: It fits most budgets and into
almost any space.
Higher output – lower emissions
The Vitogas 200-F is not only miserly in its space requirements, but also
where outlay and energy consumption are concerned. Its stainless steel
premix burner lets it perform better than required for the “Blue Angel”
certificate of environmental excellence and the Swiss Clean Air Act.
|
|
Vitogas 200-F
Low temperature gas fired boiler
Rated output: 72 to 144 (432) kW
The Vitogas 200-F has true stature – from 72 to 144 kW or as cascade up
to 432 kW
The Vitogas 200-F always does well – with a rated output of 72 to 144 kW or
as a multi-boiler system up to 432 kW. The standard components of the
powerful gas fired cascade are the proven Vitogas 200-F (up to 144 kW), the
matching flue gas header and the Vitotronic control unit. This makes the
Vitogas 200-F an ideal solution even in larger buildings, where quiet
operation and an optimum price/performance ratio are a must.
|
|
|
|
Gas fired condensing boilers
By using a condensing boiler to convert natural gas into heat, you are making an active
contribution towards protecting the climate and the environment, thanks to the boiler's
unbeatably high efficiency of 98 percent.
Our gas condensing boilers come with the future built in. Thanks to the Lambda Pro
Control combustion control, our gas condensing boilers adjust automatically to all gas
types – including biogas mixtures. This way, we will meet the many demands for heating
technologies across the whole product range that protect our resources.
The fact that no energy storage is necessary is also an argument in favour of a gas heating
system – especially if you want to use the space for other purposes.
You can even use free solar energy as part of your new heating system! All boilers are
designed for combination with Viessmann solar technology. Viessmann system technology
guarantees that everything will fit together beautifully and work in harmony, giving you
convenient control that meets all your needs.
|
|
|
|
Vitodens 222-F
Gas fired compact condensing boiler with integral DHW
primary cylinderSpecification:
- Gas fired compact condensing boiler with integral enamelled primary
cylinder, 4.8 to 35 kW
- Seasonal efficiency [to DIN]: 98% (Hs) / 109% (Hi)
- Cylinder capacity: 100 litres (35 kW: 130 litres)
- Performance factor: NL = 4.8 (35 kW)
- Dimensions (height x width x depth):
1 425 x 600 x 595 mm (19, 26 kW)
1 625 x 600 x 595 mm (35 kW)
Weight:
125 kg with 100 litre primary cylinder (up to 26 kW),
133 kg with 130 litres primary cylinder (35 kW)
|
|
Vitodens 333-F
Gas fired compact condensing boiler with integral DHW
cylinderSpecification:
- Gas fired compact condensing boiler with integral stainless steel primary
cylinder or enamelled DHW cylinder with indirect coil, 3.8 to 26 kW
- Seasonal efficiency [to DIN]: 98% (Hs) / 109% (Hi)
- Cylinder capacity: 100 or 130 litres
- Performance factor: NL = 2.0
- Dimensions (height x width x depth)
with stainless steel primary cylinder: 1 425 x 600 x 595 mm,
with DHW cylinder and indirect coil: 1 625 x 600 x 595 mm
Weight:
with integral stainless steel primary cylinder: 113 kg,
with DHW cylinder and indirect coil: 145 kg
|
|
Vitodens 343-F
Compact Energy Tower with integral solar cylinder,
solar control unit and Solar-DiviconSpecification:
- Gas fired compact condensing boiler with integral solar DHW heating, 3.8
to 19 kW
- Seasonal efficiency [to DIN]: 98% (Hs) / 109% (Hi)
- Cylinder capacity: 220 litres
- Performance factor: NL = 1.8 (19 kW)
- Dimensions (height x width x depth): 2 075 x 600 x 595 mm
Weight:
130 kg (heating module: 35 kg, DHW cylinder module: 95 kg)
|
|
|
|
Vitodens 200-W
Wall mounted gas fired condensing boiler with Inox-Radial
heat exchanger
Rated output: 4.8 to 105.0 kW. In cascades up to 420 kW.
The wall mounted gas fired condensing boiler Vitodens 200-W is the result of
the consistent development of the Vitodens 200 series with the proven
stainless steel Inox-Radial heat exchanger.
|
|
Vitodens 222-W
Wall mounted gas fired condensing boiler with integral
primary cylinderSpecification
Output: 4.8 to 35 kW
Standard efficiency: up to 98 % (Hs) / 109 % (Hi)
Dimensions: 900 x 600 x 480 mm (H x W x D) (kitchen unit sizes)
Weight: 70 kg
|
|
Vitodens 300-W
Wall mounted gas fired condensing boiler
Specification
Output: 3.8 to 35 kW
Standard efficiency: up to 98 % (Hs) / 109 % (Hi)
Dimensions: 480 x 380 x 850 mm (H x W x D)
Weight: 45 kg (26 kW) |
|
|
|
Vitocrossal 300
Gas fired condensing boiler
Rated output: 26 to 60 kW
Condensing technology for new build and modernisation
The Vitocrossal 300 is a top product amongst freestanding gas fired
condensing boilers. It is designed to utilise the condensing energy in its
hot gases with exceptional intensity. The balanced flue operation with an
output of up to 60 kW is particularly worth mentioning. This enables the
Vitocrossal 300 to be installed inside the thermally insulated building
envelope. This is especially advantageous for the EnEV [Germany]
calculation.
|
|
|
|
|
|
|
|
Heat exchangers
|
|
|
|
Vitotrans 100
Plate-type heat exchanger
For transfer stations from heat supply networks, for system separation in
heating systems with underfloor heating systems, for DHW heating and solar
heating systems.
- Heating side up to 130 °C or 200 °C
- Heat exchanger plates and connections made from stainless steel (1.4401)
- Incl. thermal insulation.
|
|
Vitotrans 200
Typ WTT / Heat exchanger with heating tube array made
from Turbotec pipes
Heat exchanger for swimming pool water heating.
Heating tube array made from high-alloy stainless steel
With fitted thermal insulation
|
|
Vitotrans 200
Typ WTD / Heat exchanger with heating tube array made
from Turbotec pipes
For generating heating energy in conjunction with steam district heating
systems.
Control through condensate backup or control of the steam side
Heating tube array made from high-alloy stainless steel
|
|
Vitotrans 300
Flue gas/water heat exchangers constructed from
stainless steel, for flue gas condensing
For boilers from 80 to 6.600 kWHighly reliable operation and long
service life due to their corrosion-resistant stainless steel construction.
1.4571 stainless steel is suitable for use on gas boilers and for brief
periods on oil-fired boilers. 1.4539 stainless steel is suitable for
continuous use on oil-fired boilers.
|
|
|
|
Heat pumps
Whether you want to use energy from the ground,
groundwater or the air, with a heat pump you will definitely reduce your
consumption of fossil fuels, protect valuable resources and lower emissions.
Your special benefit: Viessmann ground source heat pumps have an additional
"dual function" benefit. They provide heat in winter and ensure a pleasant
atmosphere in summer. With their active and natural cooling functions, they
bring a refreshing change of air into the house on hot days.
Our wide product range offers you the right heat pump, whatever your needs –
depending on your own particular plans, your heat demand, and structural and
geological conditions. What's more, this isn't just suitable for new build.
You can also use a Viessmann heat pump in a modernisation project, and
combine it with an oil or gas heating system if you wish.
|
|
|
|
Vitocal 160-A
Air source heat pump for DHW heating
Heating output: 1.52 kWSpecification
Heating output: 1.52 kW
COP (air 15 °C/water 45 °C): 3.54
Maximum flow temperature: 55 °C
Cylinder capacity: 285 litres
Dimensions (length ø x width x height):
660 x 700 x 1 847 mm (recirculating operation)
660 x 700 x 1 838 (extract air operation)
Weight: 105 kg (type WWK), 110 kg (type WWKS)
|
|
Vitocal 200-G
Brine/water heat pump
Heating output: 6.1 to 9.7 kW
Flow temperatures up to 60 °C
Heating with energy from the environment is not a matter of price
Viessmann makes the utilisation of renewables particularly attractive for
owners of detached homes, with the Vitocal 200-G brine/water heat pump. The
Vitocal 200-G brine/water heat pump offers all of the functions required for
using a heat pump in a new detached house. The available output sizes from
6.1 to 9.7 kW ensure a convenient heat supply in mono-mode all the year
round. The maximum flow temperature of 60 °C even allows for the use of
radiators.
|
|
Vitocal 222-G
Compact heat pump
Brine/water heat pump
Heating output: 5.9 to 10.0 kW
With integral 170 litre capacity DHW cylinder
Natural heat for modern detached houses
The new compact heat pump Vitocal 222-G is specifically for detached houses.
With its very modest dimensions of around 0.4 m² it takes up minimal space.
With integral DHW cylinder, brine and heating circuit pumps plus a three-way
diverter valve, this compact appliance is quick and easy to install. The
Vitocal 222-G includes a 170 litre cylinder and offers high DHW convenience.
|
|
|
|
Vitocal 242-G
Copact heat pump with solar connection
Brine/water heat pump
Heating output: 5.9 to 10.0 kW
With integral 220 litre capacity DHW cylinder
Natural heat for modern detached houses
The new compact heat pump Vitocal 242-G is specifically for detached houses.
With its very modest dimensions of around 0.4 m² it takes up minimal space.
With integral DHW cylinder, brine and heating circuit pumps plus a three-way
diverter valve, this compact appliance is quick and easy to install. The
Vitocal 242-G includes a 220 litre cylinder and offers high DHW convenience.
|
|
Vitocal 300-A
Air/water heat pump
3 to 9 kW, maximum flow temperature: 60 °CSpecification:
- Variable output selection from 3 to 9 kW
- Coefficient of Performance (air 2 °C / water 35 °C): Up to 3.7 to EN
14511 (5 K spread)
- Maximum flow temperature: 60 °C (at 0 °C outside temperature)
- Optional internal and external installation, minimum footprint of 863
x 777 mm
|
|
Vitocal 300-G
Heat pump
Brine/water heat pumpSpecification:
Heating output: 6.0 to 34.0 kW
Coefficient of Performance (brine 0 °C / water 35 °C): Up to 4.6 (EN
14511 at 5 K spread)
Maximum flow temperature: 60 °C
- Two-stage from 12 kW (available from 08/2008)
|
|
|
|
Vitocal 300-G (master/slave)
Two-stage heat pump (master/slave)
Brine/water heat pump
Specification:
Heating output:
Vitocal 300-G, type BW: 6.2 to 17.6 kW
Vitocal 300-G, type WW: 8.0 to 21.6 kW
Vitocal 300-G master/slave, type BW/ BWS: 6.2 to 35.2 kW
Vitocal 300-G master/slave, type WW/WWS: 8.0 to 43.2 kW
COP (brine 0 °C/water 35 °C): up to 4.7
Maximum flow temperature: 65 °C
Dimensions (height x width x depth): 970 x 600 x 1 065 mm
Weight: 2 x 168 kg (35.2 kW)
|
|
Vitocal 333-G
Compact heat pump
Compact brine/water heat pump
Heating output: 5.9 to 10.3 kW
With integral 170 litre capacity DHW cylinder
Subsidies through innovation bonus
These compact appliance is highly efficient thanks to the new refrigerant
circuit with electronic expansion valve (EEV) and the Viessmann-developed
RCD systems (Refrigerant Cycle Diagnostic) plus the standard power-saving
high efficiency pumps. As a result, in Germany, an innovation bonus (BAFA)
can be applied for as part of the Top incentive programme.
|
|
Vitocal 333-G NC
Compact heat pump with integral cooling function NC
(natural cooling)
Brine/water heat pump
Heating output: 5.9 to 10.3 kW
Integral 170 litre capacity DHW cylinderSubsidies through
innovation bonus
These compact appliance is highly efficient thanks to the new refrigerant
circuit with electronic expansion valve (EEV) and the Viessmann-developed
RCD systems (Refrigerant Cycle Diagnostic) plus the standard power-saving
high efficiency pumps. As a result, in Germany, an innovation bonus (BAFA)
can be applied for as part of the Top incentive programme.
|
|
|
|
Vitocal 343-G
Compact heat pump with solar connection
Compact heat pump
Brine/water heat pump
Heating output: 5.9 to 10.3 kW
Integral 220 litre capacity DHW cylinderSubsidies through
innovation bonus
These compact appliance is highly efficient thanks to the new refrigerant
circuit with electronic expansion valve (EEV) and the Viessmann-developed
RCD systems (Refrigerant Cycle Diagnostic) plus the standard power-saving
high efficiency pumps. As a result, in Germany, an innovation bonus (BAFA)
can be applied for as part of the Top incentive programme.
|
|
Vitocal 350-A
Air/water heat pump
Heating output: 10.6 to 18.5 kW
Flow temperatures up to 65 °CIdeal for modernisation
With the Vitocal 350-A air/water heat pump modernising is made easy. The
additional vapour injection in the compression process (EVI cycle) enables
flow temperatures of up to 65 °C. That makes it an ideal choice where older
heating systems with radiators are installed. The heat pump draws its energy
from the ambient air without the need for
drilling boreholes for geothermal probes.
|
|
NC-Box
Pleasant cooling by energy-conscious and affordable
means with the natural cooling boxHeat pumps can also be used for
cooling a building because on hot summer days, temperatures inside buildings
are generally higher than underground or in groundwater. With natural
cooling, the ground or groundwater are used to dissipate the heat from your
living space.
Specification:
Dimensions: 580 x 520 x 420 mm (W x D x H)
Weight: 25 kg
|
|
|
|
AC-Box
The efficient means of combining heating
with cooling using the active cooling boxThe active cooling box
combines the energyefficient natural cooling and the active cooling functions using
the compressor in a single system. With natural cooling, the compressor
circuit is bypassed – only the brine and heating circuit pumps are running.
As soon as the natural cooling capacity becomes inadequate, the system
automatically switches over to active cooling.
Specification:
Cooling capacity: Up to 13 kW
Dimensions: 350 x 720 x 970 mm
Weight: 80 kg
|
|
|
|
|
|
|
|
Air-conditioning technology
Fresh and pleasant air – particularly on hot heavy summer days – is pure
pleasure. For quite some time now, we have become used to advanced
technology enabling us to enjoy a pleasant atmosphere in our cars, in
hotels, as well as in offices and business premises. This has lead to
our desire to experience the same higher level of comfort produced by a
fresh atmosphere in our own homes.
There are good reasons for that. Not only do we value a pleasantly cool
atmosphere inside when it’s hot outside in summer, but there is also the
question of health and the ability to perform, for which air
conditioning is important. The optimum ambient climate is achieved on
average at a room temperature of approx. 21 °C. In addition, a relative
humidity around 50 % is also ideal. However, these values fluctuate
severely in the course of the day and thereby influence our performance,
concentration and our feeling of well-being. It is good to know then,
that advanced air conditioning systems provide the necessary balance by
enabling ideal control – day and night. Not only the temperature that
is, but also the relative humidity. A pleasant side effect that allergy
sufferers will appreciate is the multiple filtering of the ambient air
through dust and charcoal filters, as well as electrostatic filters.
What is also good to know is that this bonus of freshness and well-being
is delivered by technology that users will hardly perceive. No draughts
and with the lowest possible noise level – yet in a package that falls
into the highest energy efficiency category.
|
|
|
|
|
|
Vitoclima 300-S
Air-conditioning units for every need and every
comfort aspiration
The design of the Vitoclima 300-S split air-conditioning units: Heat is
expelled via the external unit; the internal device provides the ideal room
climate. Whether you wish to cool the bedroom or living room, one room or
several rooms: Viessmann supplies the right version for every aspiration and
every need.
Benefits at a glance:
- Vitoclima 300-S with 2.5 to 9 kW cooling capacity
- Single split units with one internal device, multi-split units with up to
three internal devices
- Extendable: More internal devices can be added to the multi-split
air-conditioning units, even at a later date
- Individual: Wall mounted, ceiling cassette or duct mounted devices
- Flexible: Ability to combine one external unit with various internal
devices
- Convenient: Simple, wireless operation via infrared remote control
|
|
|
|
Home ventilation systems
|
|
|
|
|
|
Vitovent 300
Domestic ventilation system with heat recovery
Air flow rates up to 180 m³/h
The Vitovent 300 constantly replaces the
ambient air, whilst simultaneously removing odours and noxious substances. A
remote control allows you to control your ventilation system with optimum
convenience.
|
|
|
|
Vitovent 300
Domestic ventilation system with heat recovery and
with bypass circuit
Air flow rates up to 300 and up to 400 m³/h
The Vitovent 300 constantly
replaces the ambient air, whilst simultaneously removing odours and noxious
substances. A remote control allows you to control your ventilation system
with optimum convenience.
|
|
|
|
Large boilers
Oil/gas boilers for medium and high output
Steam Boilers and Waste Heat Boilers
|
|
|
|
Vitomax 100-LW type M148
Type M148, oil/gas fired low pressure hot water boiler
Rated output: 0.65 to 6.0 MW. Permissible operating pressure:
6/10 bar. Permissible flow temperature: 110 °C
The Vitomax 100-LW is an oil/gas fired low pressure hot water boiler –
typical applications are local heating networks.
|
|
Vitomax 200-LW Typ M62A
Type M62A, Low pressure hot water boiler
Specification
Low pressure hot water boiler, 2.3 to 6.0 MW, 6/10/16 bar
Dimensions (height x width x depth): 2 720 x 2 400 x 5 850 mm (6 MW)
Weight: 12.1 t (6 MW, 10 bar)
|
|
Vitomax 200-LW Typ M64A
Type M64A, Low pressure hot water boiler
Specification
Low pressure hot water boiler, 8 to 20 MW, 6/10/16 bar
Dimensions (Length x width x heigt): 9.5 x 3.7 x 4.2 m (20 MW)
Weight: 48 t (20 MW, 10 bar)
|
|
|
|
Vitomax 200-WS type M250
Type M250, oil/gas fired low pressure hot water boiler
Rated output: 1.75 to 11.63 MW.
Permissible operating pressure: 3 bar.
Permissible flow temperature: 110/120 °C.
The Vitomax 200-WS is an oil/gas fired low pressure hot water boiler. It was
specifically developed for the demands of commercial nurseries.
|
|
Vitomax 300-LT type M343
Type M343, oil/gas-fired low pressure hot water
boiler that can bes used as a low temperature boiler.
Rated output: 1.86 to 5.9 MW.
Permissible operating pressure: 6 bar.
Permissible flow temperature: 110/120 °C The Vitomax 300-LT is a low
pressure hot water boiler that can be used as low temperature boiler. One
typical application would be an apartment block where the system is operated
in modulating mode, subject to outside temperature.
|
|
Vitomax 200-HW type M236
Type M236 / High-pressure hot water boiler
Rated output: 0,52 to 2,84 MW
The Vitomax 200-HW is an oil or gas fired high pressure hot water boiler for
permissible flow temperatures in excess of 120 °C, permissible operating
pressures of 6 to 25 bar – a typical boiler for district heating and
industrial operations.
|
|
|
|
Vitomax 200-HW type M238
Type M238 / High-pressure hot water boiler
Rated output: 4 to 18.2 MW
Vitomax 200 is an oil or gas fired high-pressure hot water boiler for
permissible flow temperatures in excess of 120°C, permissible operating
pressures of 6.5 to 25 bar – i.e. a standard boiler for district heating and
industrial applications.
|
|
Vitoplex 100 LS type SXD
Low pressure steam boiler
Output range: from 0.26 to 2.2 t/h
The Vitoplex 100-LS is a compact three-pass boiler for generating low
pressure steam in the output range from 0.26 to 2.2 t/h. The boiler is
designed for operation with 1 bar pressure. Subject to requirements, the
operating pressure can be reduced to 0.5 bar.
|
|
Vitomax 200-LS type M233
Type M233 / Low pressure steam boiler
Steam output: 2.9 to 5.0 t/h The Vitomax 200-LS (type M233) is a
low pressure steam boiler with permissible operating pressure up to 1 bar,
steam output: 2.9 to 5.0 t/h.
|
|
|
|
Vitomax 200-HS type M237
High pressure steam boiler with flue gas heat
utilisation
Type M237 with steam output of: 0.7 to 3.7 t/h The Vitomax 200-HS with
integral economiser is generally used in the same type of systems as boilers
without ECO. In a series steam output between 0.7 and 3.7 t/h is provided at
25 bar operating pressure.
|
|
Vitomax 200-HS Typ M75A
High pressure steam boiler
Type M75A, steam output: 5 to 26 t/h Specification:
High pressure steam boiler, 5 to 26 t/h, to 25 bar
Dimensions (height x width x depth): 4 340 x 3 900 x 8 664 mm (25.21
t/h without economiser)
Weight: 58.3 t (25.21 t/h, 18 bar)
|
|
Vitomax 200-RW/RS
Waste heat boiler for hot water and steam generation
Waste heat boilers utilise the heat from flue gases generated during
combustion processes or the heat in hot exhaust air from industrial
processes to generate hot water or saturated steam.
|
|
|
|
Large heat pumps up to 1500 kW
With technical expertise, high manufacturing ability and many years of experience, KWT is the heat pump manufacturer of choice for every special application.
KWT works together with its clients to develop solutions that are based on more than 30 years' experience, that will meet practical, everyday needs, and that will overcome any and every challenge.
All deadlines and costs arranged can be relied on, with no unexpected surprises. All systems are designed and built based on our customers' performance definitions.
All heat pumps and geothermal probes verify this performance on the test bed and in practice.
|
|
|
|
Geothermal probes
KWT brine/water heat pumps – designed with expertise
and built with quality.
Geothermal probes are durable, maintenancefree heat sources. In conjunction
with heat pumps, they provide energy for heating, but are also the ideal
heat exchanger for natural cooling. In both cases, KWT brine/water heat
pumps utilise the constant temperature in the ground.
DHW heating
DHW temperatures above 60 °C are often needed. However, especially with
larger heat pumps, the demand for DHW heating accounts for the lesser
proportion of total output. With multi-stage heat pumps or hot gas
decoupling, KWT heat pumps can provide the ideal solution to meet this
demand. The use of special safety heat exchangers guarantees global potable
water requirements are maintained.
|
|
Water/water heat pumps
High grade components make KWT water/water heat pumps
powerful and reliable in
borderline areas.
Groundwater at 8 to 12 °C is a very rich heat source for a heat pump, as the
temperature level is high all year round. However, fluctuating water
qualities usually require special heat exchangers (evaporators) if you wish
to avoid having intermediate circuits.
Stainless steel tubular evaporators
KWT heat pumps for groundwater or surface water are equipped with high grade
stainless steel tubular heat exchangers. The benefits are obvious – the
evaporator has a large volume and generously sized surface area, so the
border regions are not vulnerable to icing up. Light floating parts are
simply flushed through with the medium, and aggressive chemical fluids have
little destructive effect on the high grade stainless steel.
|
|
Air/water heat pumps
KWT air/water heat pumps for heating and cooling, in
conjunction with conventional heat sources, are an economical solution where
cooling is required.
Air is readily available as a source of heat. However, even when cooling is
required, air can easily absorb the extracted heat. KWT air/water heat pumps
make particularly efficient use of air temperatures down to about 5 °C, with
which they can cover up to 50 % of the annual heat demand.
Heating and cooling
Air/water solutions from KWT are suitable for heating and cooling. In both
cases, the
highest level of efficiency is guaranteed thanks to variable speed DC fans.
The special
design of the air heat exchangers, with gaps twice as wide as in
conventional chillers,
optimises heat transfer, lowers the pressure drop of the air flow rate,
reduces noise and
ensures a fast and efficient defrost process.
|
|
|
|
Special systems
KWT special systems are built precisely in accordance
with your requirements, they are reliable in operation, and have been used
successfully as system components for many years.
Waste water and waste heat from industrial processes contain a great deal of
energy, which is only seldom used. KWT has the right expertise to exploit
this energy. Even for extremely low outside temperatures of minus 40 °C up
to plus 35 °C, there is a matching heat pump in the KWT range.
DHW heating
Waste water from hotels and leisure complexes is usually at a residual
temperature
of 25 to 35 °C. At the same time, however, such complexes also require a
large amount of fresh hot water. KWT, with its ideally suited heat pumps is
best placed to make use of this waste heat and so is the perfect partner for
such projects. Their heat pumps are highly efficient and supply a water
temperature of 60 °C.
|
|
Engineering and service
KWT guarantees the components and assemblies in its
products will work seamlessly together – from individual support in
designing the system right through to maintenance.
Heat pumps from KWT guarantee efficient and reliable operation. Following
installation, KWT engineers or Viessmann service companies commission the
system, check its output and reliability, document all the work and tests
carried out, and instruct the future operators.
As the only heat pump manufacturer in Switzerland with a complete value
chain within its own company, KWT guarantees the components and assemblies
in its products will work seamlessly together – from individual support in
designing the system right through to maintenance. Outside Switzerland,
these services are provided by Viessmann.
|
|
|
|
|
|
Medium boilers, 80 to 1950 kW
Viessmann offers innovative heating solutions for residential complexes, municipal buildings,
and industrial/commercial buildings. Take a closer look at the many options available.
|
|
|
|
Vitoradial 300-T
Oil fired condensing boiler
Rated output: 101 to 335 kW
|
|
Vitoplex 200
Low temperature oil/gas fired boiler
Rated output: 90 to 1950 kW
|
|
Vitoplex 300
Low temperature oil/gas fired boiler
Rated output: 90 to 2000 kW
|
|
Vitorond 200
Low temperature oil and gas fired cast iron boiler
Rated output: 125 to 1080 kW
|
|
Vitocrossal 200 CM2
Condensing Unit with MatriX radiant burner
Rated output: 87 (29) to 311 kW, as twin-boiler system up to 622 kW
|
|
|
|
Vitocrossal 200 type CT2
Condensing Unit with MatriX cylinder burner
Rated output: 404 (135) to 628 kW, as twin-boiler system up to 1256 kW
|
|
Vitocrossal 300 CM3
Gas fired condensing boiler with MatriX radiant burner
Rated output: 87 (29) to 142 kW
|
|
Vitocrossal 300 type CT3
Gas condensing boiler
Rated output: 187 to 635 kW
|
|
Vitocrossal 300 CR3
Gas fired condensing boiler
Rated output: 787 and 978 kW
|
|
Vitoplex 100 LS SXD
Low pressure steam boiler
Output range: from 0.26 to 2.2 t/h
|
|
|
|
Oil fired boilers, 18 to 100 kW
On the following pages, you will find extensive information about the various technologies
available to you today to generate heat using oil in your house or apartment.
When using a condensing boiler to convert fuel oil into heat, you can make an active contribution
towards protecting the climate and the environment, thanks to the boiler‘s unbeatably
high efficiency of 98* percent.
Our oil condensing boilers come with the future built in. They are already set
up to change from using fossil oil to fuel oil with a proportion of bio-oil.
This way, we will meet the many demands for heating technologies across the
whole product range that protect our resources. You can even use free solar
energy with your new heating system! All boilers are designed for combination
with Viessmann solar technology. Viessmann system technology guarantees that
everything will fit together beautifully and work in harmony, giving you
convenient control that meets all your needs.
|
|
|
|
Vitorond 100
Cast iron low temperature oil fired boiler
Rated output: 18 to 100 kW
The attractively priced three-pass boiler
Vitorond 100 is an advanced cast iron three-pass boiler at an attractive
price. The optimised thermal insulation of the Vitorond 100, together with
the Vitotronic control unit fitted on top, further reduce the installation
time.
|
|
Vitorond 111
Cast iron low temperature oil fired boiler with
integral DHW cylinder
Rated output: 18 to 33 kW
The affordable and compact "heating panel"
The Vitorond 111 is a compact, fully fitted combination comprising an oil
fired cast iron low temperature boiler Vitorond 100 plus an integral DHW
cylinder with either 130 or 160 litre capacity (subject to boiler output).
|
|
Vitola 200
Ultra-low temperature oil fired boiler
Rated output: 18 to 63 kW
The compact classic with biferral composite heating surface
The biferral composite heating surface of the Vitola 200 has become a
benchmark for high quality and reliability. The Vitola 200 combines
convenience and economy at a reasonable price, and is a milestone in the
history of heating technology.
|
|
Vitola 222
Ultra-low temperature oil fired boiler with integral
DHW cylinder
Rated output: 18 to 27 kW
Compact integral: The DHW cylinder
Through its combination with the integral DHW cylinder, the Vitola 222 oil
fired combi boiler joins advanced heating technology with powerful DHW
heating.
|
|
|
|
Oil fired condensing boilers, 12.9 to 53.7 kW
|
|
|
|
Vitoladens 300-C
Oil fired compact condensing boiler
Rated output: 12.9 to 28.9 kW
Highly efficient and compact freestanding oil fired condensing boiler
The Vitoladens 300-C is a highly efficient oil fired condensing boiler with
a stainless steel Inox-Radial heat exchanger connected directly to the
biferral composite heating surface.
|
|
Vitoladens 300-T
Oil fired condensing boiler
Rated output: 20.2 to 53.7 kW. Suitable for all commercially available
EL-type fuel oils
Oil condensing technology for modernisation and new build
Vitoladens 300-T – the freestanding oil fired condensing Unit with an
attractive cost/performance ratio, high operational reliability and compact
design.
|
|
Vitoladens 300-W
Wall mounted, oil fired condensing boiler
Rated output: 12.9 bis 23.5 kW
Compact wall mounted, oil fired condensing boiler: Vitoladens 300-W
The wall mounted Vitoladens 300-W oil fired condensing boiler enables an
energy-efficient, reliable and safe utilisation of condensing technology
with fuel oil.
|
|
Vitoladens 333-F
Compact oil fired condensing boiler with integral DHW
cylinder
Rated output: 12.9 bis 23.5 kW
Efficiency in every detail
The new oil fired Vitoladens 333-F compact condensing boiler with a seasonal
efficiency [to DIN] of 98 percent now features an integral high effi ciency
DC pump that further enhances its energy-saving credentials.
|
|
|
|
Photovoltaic systems
If you produce your own power, you can
receive a guaranteed remuneration from your
power supply utility over 20 years. This is
governed by the Renewable Energy Sources
Act (EEG) [Germany], which states that
energy providers are obliged to accept the
renewable power and feed it into their grid.
Power for your own consumption continues to
be drawn from your local power supply utility
at the usual tariff. The feed-in remuneration
for environmentally friendly photovoltaic
power is higher than the consumption tariff.
This difference, together with the public
loans programmes, contribute to economic
finance for a photovoltaic system. In addition,
a number of regional subsidies are available.
For up-to-date information, see the subsidies
database at www.viessmann.de
|
|
|
|
|
|
Vitovolt 200
Single-glazed photovoltaic solar panel with an attractive
price/performance ratio
Vitovolt 200 photovoltaic panels are available with monocrystalline and
polycrystalline silicon cells.
The photovoltaic panels are designed as a glass laminate sandwich. The
individual solar cells are embedded between two plastic films. The back
cover is composed of a foil. Panes and foils are laminated together. This
protects the cells against outside weather conditions.
The fully wired panel is particularly easy to install on the roof thanks to
its low weight and the standard Viessmann assembly kits.
|
|
|
|
|
|
Vitovolt 100
Photovoltaic module with thin-layer technology.
|
|
|
|
Solar thermal systems
Solar thermal systems are ideally suited for DHW heating and central heating backup.
Thanks to the freely available solar energy, your investment will pay for itself within a few
years through high savings on fossil fuel.
|
|
|
|
Vitosol 200-F
Flat-plate collector
Powerful, durable and even easier to install
Vitosol 200-F flat-plate collectors make an impression with their high
efficiency and their attractive price/performance ratio. The Vitosol 200-F
flat-plate collector that has been successfully used for many years now, has
been further improved; its even lower weight makes it even more easy to
install. High quality ensures permanent operational reliability, a long
service life and high efficiency.
Long term efficiency
The highly selective Sol-titanium coating efficiently utilises the solar
irradiation and achieves a high efficiency. The Vitosol 200-F housing
comprises an all round folded aluminium frame without mitre cuts and sharp
edges. Together with the seamless weather and UV resistant pane seal and the
puncture proof back wall, these features ensure a long service life and
long-term high energy yields.
|
|
Vitosol 300-F
High performance flat-plate collector
The new Vitosol 300-F is a high performance flat-plate collector. It is
ideal for DHW heating and central heating backup. High quality ensures
permanent operational reliability and a long service life.
High solar energy utilisation
Through its anti-reflex glass, the highly selectively coated copper absorber
utilises the intensive solar irradiation particularly well. The meander
shape of the absorber ensures an even and reliable flow through the entire
collector. The result is the assurance of high solar energy utilisation and
efficiency.
Specification:
2.3 m² absorber surface
Dimensions: 2380 x 1056 x 90 mm (length x width x height)
Weight: 52 kg
|
|
Vitosol 300-T
Vacuum tube collector
First class high performance vacuum tube collector
The Vitosol 300-T high performance vacuum tube collector operates according
to the proven heat pipe principle. It consequently offers particularly high
operational reliability. One of the specific applications of the Vitosol
300-T is in systems with long phases of high solar irradiation without heat
transfer, so called stagnation phases. The dry connection of the heat pipe
tubes inside the header and the integral temperature limiter ensure
particularly high operational reliability.
Heat pipe principle for high operational reliability
In heat pipe systems, the solar medium does not flow directly through the
collector tube. Instead, a process medium, which circulates in the copper
pipe below the absorber, evaporates when subjected to solar irradiation, and
transfers the heat to the solar medium via a heat exchanger.
|
|
|
|
Vitosol 200-F large area collector
Large area collector
For quick handling with a crane
The new large area collector Vitosol 200-F is supplied as type XL5 with 4.7
m² and as type XL10 with 9.43 m² collector area. Lifting eyes are
factory-fitted on the collectors to make lifting by crane on site easier.
Array sections up to 110 m² can be achieved quickly and easily to capture
free solar energy.
The large collector areas mean little pipework when connecting several
modules. Suitable installation accessories for installation on flat roofs
and on rooftops are also available from Viessmann.
|
|
Vitosol 200-T
Direct flow vacuum tube collector
Highly efficient tube collectors with time saving and safe plug-in system
The Vitosol 200-T is a direct flow vacuum tube collector that is ideal for
installations in any location. The new design of the header casing enables
the Vitosol 200-T to blend harmoniously into the overall appearance of the
roof.
Effective use of the sun’s heat
The Sol-titanium coated absorbers collect a vast amount of solar energy and
thereby ensure high efficiency. The vacuum in the tubes guarantees very
effective thermal insulation. There are minimal losses between the glass
pipes and absorbers – and the collector is able to transform even a minimum
of sunlight into available heat.
|
|
|
|
|
|
Solid fuel-fired boilers
The rising costs of fossil fuel and growing environmental awareness are
resulting in an ever-increasing demand for renewable types of energy. On the
following pages, we will give you comprehensive information about burning wood,
as a regenerative fuel, efficiently in advanced boilers.
A wood boiler is a good alternative to heating with oil or gas. This natural
fuel has a lot to recommend it, and not only because it is environmentally
responsible; wood as an indigenous fuel is also very affordable and not subject
to wide price fluctuations. In addition, advanced Viessmann technology makes
heating with wood efficientand convenient. The Vitolig/Vitoligno range offers
flexible solutions, either as an auxiliary or complete heating system, subject
to boiler type, with logs or pellets.
|
|
|
|
Vitoligno 100-S
Log gasification boiler
Rated output: 20 kW
The ideal companion boiler
The Vitoligno 100-S is a very attractively priced log gasifi cation boiler
with rated output of 20 kW. This compact companion boiler is also an ideal
addition to an existing oil or gas fi red heating system.
Its large hopper can be easily fi lled from the front with logs up to 50 cm
long, thanks to its large charge door, and its large dimensions also enable
long combustion times. The gasification technology enables the Vitoligno
100-S to achieve a high level of effi ciency.
The solid hopper, constructed from 8 mm thick steel plates, and the reliable
vacuum fan ensure a long service life.
|
|
Vitolig 200
High grade wood gasification boiler
Rated output: 13 to 40 kW
High grade high performance wood gasification boiler
The Vitolig 200 is a high grade wood gasification boiler in the rated output
range from 13 to 40 kW with output modulating infinitely between 50 to 100 %
of rated output. 50 cm long logs, chippings and wood briquettes are easily
handled by the large stainless steel hopper. Combustion times up to 12 hours
guarantee long intervals between recharging.
The unique automatic heat-up system ensures that the combustion chamber
temperature required for optimum combustion is reached within three minutes
of start-up.
|
|
Vitoligno 300-P
Fully automatic pellet boiler
4 to 48 kW
- Automatic cleaning of the heating surfaces for permanently high efficiency
- Automatic ash removal from the burner bowl for long cleaning intervals
- Charge unit, comprising a rotary lock valve and supply auger for precise,
economical fuel dosing and 100% safe backburn reliability
- Best energy utilisation through automatic matching of the three-pass
heating surface to the actual heat demand with the patented Variopass
principle
- Automatic and energy-saving ignition with heater elements
- Digital control unit with full text display with user prompts and
automatic function monitoring plus solar and buffer cylinder control
- Extensive accessories for pellet supply and storage
|
|
|
|
Wood combustion systems & Wood heating systems
Wood heating systems from 35 to 170 kW
Wood heating systems from 100 to 1250 kW
Wood combustion systems up to 13 000 kW
|
|
|
|
Pyromat ECO
Wood boiler
For logs, wood briquettes, waste wood, woodchips and pellets from 40 to 170
kWSpecification:
Rated output range: 40 to 170 kW
Log boiler (0.5 m logs) (hopper width: 550 mm), 6 types from 40 to 95
kW
Log boiler (1 m logs) (hopper width: 1080 mm), 4 types from 85 to 170
kW
Efficiency up to 92 %
Permissible flow temperature up to 100 °C
Permissible operating pressure 3 bar
CE designation according to current Directive
|
|
Pyromat DYN
Wood boiler
For logs, wood briquettes, waste wood, woodchips and pellets from 35 to 100
kWSpecification:
Rated output range: 35 to 100 kW
Efficiency up to 92 %
Permissible flow temperature up to 100 °C
Permissible operating pressure 3 bar
CE designation according to current Directive
|
|
Pyrot
Innovative wood boiler
With rotation combustion from 100 to 540 kWSpecification:
Fully automatic wood boiler with rotation combustion
Rated output range: 100 to 540 kW
For dry wood fuels with a maximum water content of 35 %
Efficiency up to 92 %
Permissible flow temperatures up to 100 °C
Permissible operating pressure 3 bar
|
|
Pyrotec, 390 - 1250 kW
Wood boiler
With state of the art grate combustion,
from 390 to 1250 kWSpecification:
Fully automatic wood boiler with grate combustion
Rated output range: 390 to 1250 kW
Universal application for all types of wood fuel from dry (W10) to moist
(W50)
Efficiency up to 92 %
Permissible flow temperatures up to 100 °C
Maximum operating pressure 6 bar
|
|
|
|
Pyrotec, 110 - 4200 kW
Wood combustion system
Double grate underfeed combustion
110 to 4 000 kW
A proven combustion system for the automatic combustion of dry to moist (W =
50%) fuel from commerce, industry and forestry with a size of up to P63.
Every single day, over 3 000 Mawera systems of this type supply energy from
biomass to heat buildings or for process heat.
|
|
Pyroflex
Wood combustion system
Flat moving grate combustion
110 to 13 000 kW
Mawera flat moving grate combustion is suitable for obtaining energy from
dry to moist wood fuel (W = 60%). Depending on the fuel type, the flat
moving grate can be charged either with an auger, chain delivery or
hydraulic supply system.
|
|
Pyrovent
Wood combustion system
Direct combustion system
850 to 13 000 kW
For the combustion of very powdery, dry (W = 15%) fuels from industrial wood
processing, Mawera direct combustion is the optimum solution. More than 1
000 installed systems are further proof of the unique quality of our
products.
|
|
|
|
|
|
Vitoset heating system components
|
|
|
|
Heating system components
Vitoset - Everything from one source
The Vitoset range offers heating contractors all of the components required
for domestic heating equipment. Every Vitoset product meets the high quality
demands with which Viessmann has always been synonymous. The Vitoset range
is perfectly matched to all other Viessmann products. Further evidence of
the technical expertise offered by Viessmann.
Heating contractors, however, profit not only from the high quality
standards. Vitoset lightens the load and saves money, even where ordering,
delivery and service are concerned.
Ordering is quick and easy by phone, fax or the internet. Everything from a
single source and from one partner. Complete sets, e.g. an oil fired boiler
with matching system components, such as an oil filter, an expansion vessel
and a filling & drain valve
are all offered under one part number.
|
|
Universal radiators
Universal radiators: Attractive and space-saving
design
High output, modern technology: radiators from Viessmann’s Vitoset range
meet the highest of expectations and perfectly complement the Vitotec range.
Universal radiators, visually elegant, with a high quality finish
That ths radiator is a cut above the average can be seen by its high
quality, long-life, powdercoated finish. On account of their understated
appearance, these high output, universal radiators are equally suited to the
living space or to offices. Considering investment outlay, they make an
interesting alternative to flat panel radiators. Whether rooms are freshly
renovated or not, the white radiators (RAL 9016) will blend in harmoniously.
These universal radiators are easy to clean, making them an attractive
choice for those suffering from allergies. For thorough cleaning, simply
remove the top grille
|
|
Flat panel radiators
Flat panel radiators: Smooth and elegant
Their brilliant, completely smooth design make flat panel radiators an
exceptionally aesthetic design feature which is subtle yet effective. Their
technical design is optimised for the demands of energy-efficient heating.
All welds on these flat panel radiators are applied by lasers in a new
production facility. After welding, all edges are chamfered to precise
tolerances.
The resistant, plastic-coated surface is easy to clean and gleams in RAL
9016 (commercial white). The flat panel radiators are easy to clean, making
them an attractive choice for those suffering from allergies.
|
|
|
|
Bathroom radiators
Bathroom radiators: Elegant design features
The innovative and attractively designed Vitoset bathroom radiators offer
real scope for imaginative design ideas in your bathroom. Slim pipe elements
lend these models an elegant, light and harmonious appearance.
Bathrooms have been more than purely functional places for a long time. They
are essential to a good quality of life, providing a place to recover and
relax. Feel-good warmth is exuded by these stylish bathroom radiators: The
Komfort radiator with its straight and the Nobless with its curved
horizontal round section tubes, offer you cosy warm towels.
Both radiators can also be used as room dividers, opening up a whole host of
design ideas for your bathroom according to your individual taste; for
example, by separating the toilet from the washbasin area. Installation in
your cloakroom or in hallways is an attractive option.
|
|
Fuel oil tank range
Vitoset fuel oil tanks: Experience and competence for
your safety
Oil fired heating systems represent economical and environmentally
responsible domestic heating technology. A heating system is not complete
without economical, space-efficient and easy fuel storage. Vitoset fuel oil
tanks are designed to deliver just that.
Today, dual-wall solutions in steel/plastic and plastic/plastic versions
have firmly established themselves for centralised oil fired heating
systems. Single-wall plastic tanks, which require the on-site construction
of secondary protection, are becoming increasingly redundant.
|
|
Apartment stations for the utilisation of local heating
networks
Functionality and quality in perfect harmony
Local heating networks from Viessmann are efficient complete solutions that
offer many benefits for heating systems in modernisation projects or new
build alike. The simplified installation with ready-to-connect 3 riser
system saves time. The integral consumption capturing with only one heat
meter and a cold water meter also reduces the administration and billing
effort. Furthermore, the advanced heating system makes do without additional
energy costs.
Powerful and affordable:The complete station as replacement for wall
mounted water heaters
The decentralised compact complete station as replacement for wall mounted
water heaters with casing is a perfect match for existing connections of
wall mounted heaters. That makes installation quick and easy without need to
change existing lines. The heating output can reach up to 10 kW; the DHW
output reaches 35 kW or 12 l/min.
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
6
|
|
A
