Offer Profile
ALWAYS
A GOOD CONNECTION!
ARMATUREN-ARNDT GmbH is a family tradition for valve manufacturing company,
based in Troisdorf, near Cologne.
For over 55 years we manufacture industrial valves of the measuring and
control technology from the materials steel, brass and stainless steel.
|
|
|
|
Product Line Up
Valves for the measuring and control technology
|
|
|
Cocks PN 6 and PN 16
Manometer gauge cocks find application for liquids, gas
and steam. Temperature range of -10° C until 50° C.
Material: brass and stainless steel 1.4571
Handle: Polypropylene
|
 |
Manometer push button cocks
For liquids, steam and gases.
Material: brass, surface nickel-plated and stainless steel
1.4571
Temperature: 80° C / with Viton O-ring seal 110° C
Pressure range: 25 bar / gas 4 bar DVGW-certificate
|
|
Manometer-controll-three-way cocks
Manometer gauge cocks find application for liquids, gas
and steam. Temperature range of -10° C until 50° C.
Material: brass and stainless steel 1.4571
Handle: Polypropylene
Control port: test flange or test stud
|
|
Manometer gauge valves
Manometer gauge valves are used for liquids, gas and
steams in a temperature range of -10° C until 120° C in
pressure measuring systems. The pressure range close by
250 bar for material brass and by 400 bar for material steel
and stainless steel.
Packing brass and steel: graphit, stainless
steel: teflon
Material: brass, steel 1.0460 C22.8, stainless steel 1.4571
Hand wheel: molded plastic compound
|
|
Manometer gauge valves DIN 16270
Manometer gauge valves are used for liquids, gas and
steams in a temperature range of -10° C until 120° C in
pressure measuring systems. The pressure range close by
250 bar for material brass and by 400 bar for material steel
and stainless steel.
Packing brass and steel: graphit, stainless
steel: teflon
Material: brass, steel 1.0460 C22.8, stainless steel 1.4571
Hand wheel: molded plastic compound
|
|
|
|
Manometer gauge valves DIN 16271
Manometer gauge valves are used for liquids, gas and
steams
in a temperature range of
-10° C until 120° C in pressure
measuring systems.
The pressure range close by 250 bar for material brass and by 400 bar for
material steel and stainless
steel.
Packing brass and steel: graphit, stainless steel: tefl on
Material: brass, steel 1.0460 C22.8, stainless steel 1.4571
Hand wheel: molded plastic compound
|
|
Manometer gauge valves DIN 16272
Manometer gauge valves are used for liquids, gas and
steams
in a temperature range of -10° C until 120° C in pressure
measuring systems. The pressure range close by 250 bar for
material brass and by 400 bar for material steel and stainless
steel Packing brass and steel: graphit, stainless steel: teflon.
Material: brass, steel 1.0460 C22.8, stainless steel 1.4571
Hand wheel: molded plastic compound
|
|
Manometer gauge valves with approval DVGW
Manometer gauge valves are used for liquids, gas and
steams
in a temperature range of -10° C until 120° C in pressure
measuring systems. The pressure range close by 250 bar for
material brass and by 400 bar for material steel and stainless
steel.
Material: brass, steel 1.0460 C22.8, stainless steel 1.4571
Hand wheel: molded plastic compound
|
|
Manometer accessories
Manometer accessories are used for liquids, gas and
steams in a temperature range of -10° C until 120° C in
pressure measuring systems. The pressure range close by
250 bar for material brass and by 400 bar for material
steel and stainless steel.
|
|
Pressure reducers
Material: brass, steel and stainless steel 1.4571
Temperature:
brass 120° C
steel 200° C
1.4571 200° C
|
|
|
|
Adapter DIN 16281
Adapter for instrument holder to mount the pressure gauge
and to ft to the measurement connection.
Material: brass, steel, stainless steel 1.4571
Temperature:
brass 120° C
steel 200° C
1.4571 200° C
|
|
Instrument holders DIN 16281
Wall fastening for shut off valves and measuring
instruments.
|
|
Siphons PN 25
Material: steel, 1.4571
|
|
Siphons DIN 16282
For cooling of liquids, steam and gases. Pressure
connection
only horizontal.
Clamping sleeve acc. to DIN 16283
Operating pressure:
- max.160 bar by 120° C operating temperature before
the siphon
- max.120 bar by 300° C operating temperature before
the siphon
- max.100 bar by 400° C operating temperature before
the siphon
|
|
High pressure shut off valves
Material:
steel 1.0460 C22.8,
stainless steel 1.4571
and 1.4104, 1.7335 13CrMo44
Hand wheel: sheet steel
Temperature:
- steel 1.0460 C22.8 max.400° C
-stainless steel 1.4104 max. 400° C
-stainless steel 1.4571 max. 250° C with special gaskets max. 400° C
-steel 1.7335 13CrMo44 max.540C
|
|
|
|
Needle valves
Material:
brass, steel, stainless steel 1.4571
Hand wheel: moulded plastic compound
Temperature:
- brass max. 100° C
- steel max. 350° C
- stainless steel 1.4571 max. 250° C with special gaskets max. 400° C
Pressure range: 100 - 400 bar
according to design.
Pressure drop to be considered for more
than 50° C.
|
|
Shut off valves
Material: steel 1.0460 C22.8, stainless steel
1.4571 and
1.4104, 1.7335 13CrMo44
Hand wheel: moulded plastic compound
Temperature:
- steel 1.0460 C22.8
max. 350° C
- stainless steel max. 250° C,
- with special gaskets
max. 400° C
- Steel 1.7335 max. 540° C
Pressure range: 250 - 640 bar according to design
Pressure drop to be considered for more
than 50° C.
|
|
High pressure shut off valves
Material:
steel 1.0460 C22.8, stainless steel 1.4571 and
1.4104, 1.7335 13CrMo44
Hand wheel: sheet steel
Temperature:
- steel 1.0460 C22.8
max. 400° C
- stainl. steel 1.4104 max. 400° C
- stainl. steel 1.4571 max. 250° C
- with special gaskets max. 400° C
-steel 1.733 13CrMo44 max.540° C
Pressure range: 160 - 640 bar according to design.
Pressure drop to be considered for more
than 50° C.
|
|
Y-type globe valves
Inclined seat form with integrated header.
Material: stainless steel 1.4408/1.4401
Hand wheel: sheet steel
Temperature: 200° C
Nominal pressure: 16 bar
Pressure drop to be considered for more than
50° C.
|
|
Gate valves
With compact one-piece shift cone and not increasing
spindle.
Material: stainless steel 1.4408/1.4401
Hand wheel: sheet steel
Temperature: 180° C
Nominal pressure: 16 bar
Pressure drop to be considered for more
than 50° C.
|
|
|
|
Bushing gate valves
Material: stainless steel 1.4408/1.4401
Hand wheel: sheet steel
Temperature: 200° C
Nominal pressure: 16 bar
|
|
Fluid level-indicator
For glasses with diameter of 13, 16, 20 and 25 mm.
Material: brass and stainless steel 1.4571
Temperature: brass 200° C
stainless steel 1.4571 200° C
Pressure range: PN 25
Length of glass tube: center distance minus 30 mm
|
|
Valve fluid level indicators
for glasses with diameter of 13, 16, 20 and 25 mm.
Material: brass, stainless steel 1.4571
Temperature: 200° C
Pressure range: PN 10 - 25 according to design
Length of glas tube: center distance minus 30 mm
|
|
Accessories for fluid level indicators
|
|
Sight glasses
Material: AR-glass, DURAN-glass, Plexiglas
Temperature:
- AR-glass water resistance class 3 for short time to 200° C
- DURAN-glass water resistance class 1 for short time to 500° C
- Plexiglas max. 70° C
|
|
|
|
Drain cocks
Material: stainless steel 1.4571
Handle: Polypropylene
Temperature: max. 50° C
Pressure range: max. 6 bar
|
|
Strainer
Screen loop strength:
G 3/8“ - G 1 1/2“ = 0,6 mm
G2“ = 1,0mm
Material: stainless steel 1.4408 / 1.4401
Temperature: 180° C
|
|
Swing-check valves
Material:
- steel 1.0460 C22.8
- High quality steel 1.4104
- 1.4571, 1.7335 13CrMo44
Temperature:
- up to 200° C with PTFE seal
- from 200° C metallic sealing
Opening pressure standard: 0,5 - 1 bar
|
|
|
|
|
|
CUTTING RING FITTINGS DIN EN ISO 8434-1 (DIN 2353)
|
|
|
Straight, elbow and tee-couplings
|
|
Straight male stud couplings
|
|
Elbow male stud couplings
|
|
T-male stud couplings
|
|
L-male stud couplings
|
|
|
|
Straight female couplings
|
|
Gauge couplings
|
|
Bulkhead couplings
|
|
Welding couplings
|
|
Straight reducer couplings
|
|
|
|
Male stud couplings with union adjustable
|
|
Reducing couplings with union adjustable
|
|
Couplings with sealing head
|
|
Banjo couplings
|
|
Non return valves
|
|
|
|
Accessories for couplings
|
|
Thread reducers
|
|
|
|
|
|
|
|
|
Hose fittings
|
|
|
Ferrules for hydraulic hose 1, 2 + 4-layers
EN 853, 854, 855, 856, 857
Material: 1.4571
|
|
Pressnipples for hydraulic hose 1, 2 + 4-layers
EN 853, 854, 855, 856, 857
Material: 1.4571
Viton O-Ring
|
|
Hose fittings for hydraulic hose with 4- and
6-spiral wire
With 4- and 6-spiral wire interlock.
Material: 1.4571
|
|
Adapter and accessories
Material: 1.4571
|
|
Connections
Flat sealing connections with PTFE-seal. Turned execution
for high pressure.
Material: stainless steel 1.4571
|
|
|
|
SPECIAL DESIGN - CUSTOMIZED SOLUTIONS
Our engineers design for you each individual piece to
your specifications, drawings or samples. Give us a call if you find your
valve is not in the standard.
- Dimensions: From 8-150mm, bar stock, round and Mehrkantmaterial and dies,
raw and forgings
- Material: aluminum, brass, steel, Teflon, PTFE, all stainless steel
alloys, and many special materials
- Acceptance: inspection certificates 3.1B or 3.1C, 3.1A TÜV acceptance,
Germanischer Lloyd, Det Norske Veritas, Lloyd's Register of Shipping and
other
- Connections: e.g. Whitworth Pipe threads, ISO metric threads, metric fine
thread taper, NPT, UNF / UNC thread, steel conduit thread and more
- One off, small, large series.
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
