  • Offer Profile
  • Experts in navigation

    15+ years of experience

    Since its foundation in 2001, BlueBotics develops and commercializes the ANT® natural feature navigation, which turns any kind of system into an autonomous vehicle.

    500+ ANT® driven vehicles in operation

    300+ installations, 25+ countries, 4 continents

    Suitable for any application and environment

Product Portfolio
  • PRODUCTS

  • Simple and robust

    ANT® uses natural structures in the environment as reference for localization thus requiring no infrastructure (no need for inductive wires, magnets, or reflectors for triangulation). ANT® can also use simple reflectors either in combination with natural structures, or even alone, providing the best solution for your setup.

    Quick to install

    ANT® driven vehicles are quickly installed with the ANT® lab tool suite, modification are even simpler. This makes all setups simple and economical to install and to maintain, no matter if it is a single vehicle or a large fleet.

    Industrial

    ANT® combines information from industrial encoders and laser scanners to reach an accuracy of ±1 cm and ±1°. ANT® even uses the data from the safety laser scanners available on your vehicle.

    Handles obstacles

    ANT® autonomously handles obstacles by either moving around them (obstacle avoidance), or adapting the speed to avoid emergency situations (path following).

      • ANT® lite+

      • Localization, control & mission management for your vehicle

        ANT® lite+ is a compact solution based on years of experience in the automation of industrial vehicles. It provides an autonomous navigation system for compact vehicles calculating its position, driving the vehicle, interfacing the safety sensors and including mission management (i.e. start here, go there, wait the door to be opened, etc.).

        The product provides the most standard and reliable interfaces combined with a set of I/Os enabling the automation of typical forklifts and AGVs.

        Ideal use: simple AGVs and automated forklifts

        Our features

        • Complete navigation solution
        • Simple and robust localization
        • Optimal control of the vehicle
        • Embedded management of simple missions
        • No inductive wires, magnets, triangulation reflectors
        • Use of safety laser scanners
        • Compatible with ANT® server

        Your benefits

        • Ideal for simple AGVs and automated forklifts
        • Proven in different markets around the world
        • Quick installation and modification
        • Easy industrial integration
        • Compatible with hybrid manual/automatic use
        • Economical from single vehicle to large fleet
        • Integrated mission management
        Functionality
        Functionality localization, control, missioning lite
        Compatible vehicles
        Kinematics differential drive, tricycle, car-like
        Maximal speed up to 2.0 m/s
        Localization
        Accuracy ± 1 cm and ± 1°
        Localization rate 5 Hz
        Control
        Obstacle avoidance rate 10 Hz
        Path following rate 10 Hz
        Interfaces
        Encoders CANopen (absolute & incremental)
        Laser scanners HOKUYO UAM-05LP, LEUZE RLS4XX, OMRON OS32C-DM, P+F OMD30M-R2000, SICK Expert S300, SICK Expert S3000, SICK LMS1xx/LMS5xx
        Motor drives CANopen, EtherNet/IP
        User configurable I/Os 8 digitals inputs/ 6 digital outputs
        Hardware
        Embedded computer industrial PowerPC
        Operating voltage 24 VDC (20 VDC…30VDC)
        Power consumption <20 W
        Operating temperature 0°C to 60°C
        Storage temperature -25°C to 85°C
        Relative humidity 5% to 95% (non-condensing)
        IP rating IP20
        Dimensions 182 x 60 x 190 mm (WxHxL)
        Weight 1.1 kg



      • ANT® lite

      • Localization & control for your vehicle

        ANT® lite is born to enable service robotics applications. It delivers an autonomous navigation system for compact vehicles calculating its position and driving it.

        The product is designed to bring the vehicle or mobile robot from point A to point B. It works as client of the customer’s application, which can therefore concentrate on the value delivery to the end customer while ANT® lite is in charge of the navigation.

        Ideal use: service robotics

        Our features

        • Complete navigation solution
        • Simple and robust localization
        • Optimal control of the vehicle
        • No inductive wires, magnets, triangulation reflectors
        • Use of measurement laser scanners

        Your benefits

        • Ideal for service robotics
        • Proven in different markets around the world
        • Quick installation and modification
        • Compatible with hybrid manual/automatic use
        • Economical from single vehicle to large fleet
        Functionality
        Functionality localization & control
        Compatible vehicles
        Kinematics differential drive
        Maximal speed up to 2.0 m/s
        Localization
        Accuracy ± 1 cm and ± 1°
        Localization rate 5 Hz
        Control
        Obstacle avoidance rate 10 Hz
        Path following rate 10 Hz
        Interfaces
        Encoders CANopen (incremental)
        Laser scanners P+F OMD30M-R2000, SICK LMS1xx/LMS5xx
        Motor drives CANopen, EtherNet/IP
        User configurable I/Os 8 digital inputs/ 6 digital outputs
        Hardware
        Embedded computer industrial PowerPC
        Operating voltage 24 VDC (20 VDC…30VDC)
        Power consumption <20 W
        Operating temperature 0°C to 60°C
        Storage temperature -25°C to 85°C
        Relative humidity 5% to 95% (non-condensing)
        IP rating IP20
        Dimensions 182 x 60 x 190 mm (WxHxL)
        Weight 1.1 kg





      • ANT® localization+

      • Localization & emulation of line following

        ANT® localization+ is born as retrofitting solution for line following AGVs.
        It offers localization based on features (lines and reflectors) with emulation of line following directly replacing the real antenna used by inductive wires, magnetic tapes, etc.

        This results in a line following AGV, which behaves as usual, but without any line on the floor. In the same way, ANT® localization+ provides virtual tags making the line following AGV seamlessly installed.

        Ideal use: retrofitting and substitution of line following

        Our features

        • Emulation of line following and tags
        • Simple and robust localization
        • No inductive wires, magnets, triangulation reflectors
        • Use of safety laser scanners

        Your benefits

        • Ideal for substitution or retrofitting of line following technologies
        • Proven in different markets around the world
        • Quick installation and modification
        • Easy industrial integration
        • Compatible with hybrid manual/automatic use
        • Economical from single vehicle to large fleet
        Functionality
        Functionality localization, emulation of line following
        Compatible vehicles
        Kinematics differential drive, tricycle, car-like
        Maximal speed up to 5.0 m/s
        Localization
        Localization accuracy ± 1 cm and ± 1°
        Localization rate up to 20 Hz
        Control
        Obstacle avoidance rate
        Path following rate 10 Hz (emulation)
        Interfaces
        Encoders RS232 (speed-vector)
        Laser scanners HOKUYO UAM-05LP, LEUZE RLS4XX, OMRON OS32C-DM, P+F OMD30M-R2000, SICK Expert S300, SICK Expert S3000, LMS1xx/LMS5xx
        Motor drives
        User configurable I/OS
        Hardware
        Embedded computer industrial PowerPC
        Operating voltage 24 VDC (20 VDC…30VDC)
        Power consumption <20 W
        Operating temperature 0°C to 60°C
        Storage temperature -25°C to 85°C
        Relative humidity 5% to 95% (non-condensing)
        IP rating IP30
        Dimensions 134 x 26 x 160 mm (WxHxL)
        Weight 0.6 kg





      • ANT® localization

      • Localization for your vehicle

        ANT® localization is designed for AGV suppliers having their own control system. It makes available the localization based on features (lines and reflectors) for the vehicle suppliers who just need to know the position of the vehicle.

        The product simply returns the position coordinates of the vehicle to the main controller providing natural feature navigation in the simplest way.

        Ideal use: AGV suppliers having their own control

        Our features

        • Simple and robust localization
        • No inductive wires, magnets, triangulation reflectors
        • Use of safety laser scanners

        Your benefits

        • Ideal for AGV suppliers having their own control
        • Proven in different markets around the world
        • Quick installation and modification
        • Easy industrial integration
        • Compatible with hybrid manual/automatic use
        • Economical from single vehicle to large fleet





        Functionality
        Functionality localization only
        Compatible vehicles
        Kinematics differential drive, tricycle, car-like, omni-directional
        Maximal speed up to 5.0 m/s
        Localization
        Accuracy ± 1 cm and ± 1°
        Localization rate up to 20 Hz
        Control
        Obstacle avoidance rate
        Path following rate
        Interfaces
        Encoders RS232 (speed-vector)
        Laser scanners HOKUYO UAM-05LP, LEUZE RLS4XX, OMRON OS32C-DM , P+F OMD30M-R2000, SICK Expert S300, SICK Expert S3000, LMS1xx/LMS5xx
        Motor drives
        User configurable I/OS
        Hardware
        Embedded computer industrial PowerPC
        Operating voltage 24 VDC (20 VDC…30VDC)
        Power consumption <20 W
        Operating temperature 0°C to 60°C
        Storage temperature -25°C to 85°C
        Relative humidity 5% to 95% (non-condensing)
        IP rating IP30
        Dimensions 134 x 26 x 160 mm (WxHxL)
        Weight 0.6 kg
      • ANT® navigation

      • Localization, control & mission management for your vehicle

        ANT® navigation is designed to fit any kind of AGV. It represents a complete autonomous navigation calculating the position of the vehicle, driving the vehicle, and playing the missions (i.e. start here, go there, wait the door to be opened, etc.).

        By using industrial remote I/Os, ANT® navigation provides any kind of interface thus becoming the most flexible and modular solution to automate your vehicle.

        Ideal use: complex AGVs

        Our features

        • Complete navigation solution with modular remote I/Os
        • Simple and robust localization
        • Optimal control of the vehicle
        • Embedded management of missions
        • No inductive wires, magnets, triangulation reflectors
        • Use of safety laser scanners
        • Compatible with ANT® server

        Your benefits

        • Ideal for complex AGVs
        • Proven in different markets around the world
        • Quick installation and modification
        • Easy and flexible industrial integration
        • Compatible with hybrid manual/automatic use
        • Economical from single vehicle to large fleet
        • Integrated mission management
        Functionality
        Functionality localization, control, missioning
        Compatible vehicles
        Kinematics differential drive, tricycle, car-like
        Maximal speed up to 2.0 m/s
        Localization
        Accuracy ± 1 cm and ± 1°
        Localization rate 5 Hz
        Control
        Obstacle avoidance rate 10 Hz
        Path following rate 10 Hz
        Interfaces
        Encoders CAN, RS422, Push-Pull, SSI,(absolute & incremental)
        Laser scanners SICK Expert S300, SICK Expert S3000
        Motor drives analog, CAN, EtherCAT, EtherNet/IP
        User configurable I/Os industrial remote I/Os
        Hardware
        Embedded computer industrial PowerPC
        Operating voltage 24 VDC (20 VDC…30VDC)
        Power consumption <50 W
        Operating temperature 0°C to 40°C
        Storage temperature -25°C to 85°C
        Relative humidity 5% to 95% (non-condensing)
        IP rating IP20
        Dimensions 340 x 310 x 147 mm (WxHxL)
        Weight 7.0 kg





      • ANT® server & ANT® monitor


      • Fleet management
        The ANT® server includes BlueBotics’ scheduler and traffic manager, the interface to the customer’s equipment, and the operator interface.The scheduler decides which vehicle has to execute a certain mission. The traffic manager takes advantage of the characteristics of ANT® to make the whole configuration process straight forward. Indeed, the graph defined for navigation is used to automatically generate the traffic rules.

        The ANT® server allows visualizing the fleet, while the monitoring application is available on many clients. Additionally, the server allows simulating a setup, which is very helpful to dimensioning a fleet of vehicles.

        Our features

        • Intelligent scheduling of missions
        • Deadlock-free traffic control
        • Battery charge management
        • Interface to the environment and equipment
        • Simulation of vehicles and missions
        • Monitoring of the complete system on PC, tablet, phone



      • ANT® lab

      • Configuration interfaceANT® lab is a completely integrated solution, which supports the installation process of our products. The process of configuring the vehicles, mapping the environment, creating the routes, handling traffic, and monitoring operation is extremely simplified in order to make the life of integrators and end-customers even easier.

        Our features

        • Configuration & calibration of vehicles
        • Mapping of the environment
        • Drawing of routes
        • Definition of the actions and missions
        • Interfacing of devices and equipment
        • Monitoring



    • Success Stories

        • AGV Scandinavia, 2016

        • Objective

          Automation of a standard forklift.

          Challenges

          • Integration of ANT® lite+ into a standard manual forklift
          • Integration of the AGV solution into an existing and running production site

          So why ANT?

          • ANT® lite+ provides a full navigation solution with standard interfaces at a competitive price. Together with the ANT® server, it provides a complete solution for the installation of an AGV system.
          • After the integration into the standard forklift, the installation at the customer site was then extremely easy and allowed AGV Scandinavia to profile itself as a key player in the Scandinavian region.
        • Stöcklin – Eagle-ANT, 2014

        • Objective

          Design and commercialize a simple and extremely competitive autonomous guided vehicle.

          Challenges

          • Integrate the new ANT lite+ into a simple vehicle
          • Implement point-to-point functionality
          • Make available a complete traffic management

          So why ANT?

          • Stöcklin has been convinced by the characteristics of ANT lite+, which combines the power of ANT with a simple package resulting in a competitive setup.
          • All ANT products take advantage of the ANT lab installation tools, which allow for extremely simple and fast installation.
          • Stöcklin has then designed a vehicle with the same philosophy: Simple to operate and extremely competitive on the market.
        • Kokeisl – KPR Forklift, 2011

        • Objective

          Transportation of pallets from palletizer to stock conveyor.

          Challenges

          • Narrow corridors and station entrances
          • One vehicle to cover 2800 sqm

          So why ANT?

          • The AGV equipped with ANT® was purchased after a three days demo. Installation as part of one day and two days operation demonstrated the performance of the system.
          • Installing reflectors, inductive lines or magnets on the 70 x 40 m surface area to be covered by a single vehicle was not cost efficient. ANT® requiring no additional infrastructure allowed the realization of the project within a tight budget.
        • Esatroll – Paquito Forklift, 2009

        • Objective

          Transportation of pallets from palletizer to stock buffer.

          Challenges

          • Very narrow racks to be driven in
          • 250 pick and place positions
          • One vehicle to cover 7500 sqm

          So why ANT?

          • Localization based on laser triangulation was impossible in the narrow racks. ANT®’s environment-based localization allowed traveling through the long and narrow racks with high precision.
          • Installing inductive lines or magnets on the 200 x 50 m surface area to be covered by a single vehicle was not cost efficient. ANT® requiring no additional infrastructure allowed the realization of the project within a tight budget.
      • CUSTOM SOLUTIONS

      • Since 2001, BlueBotics provides engineering services and custom solutions to support your product development and enable your application.

        From idea to product
        BlueBotics supports the development of new products from the feasibility study to the prototyping in a timely and costly effective manner. Once the prototype is validated, BlueBotics can provide additional support with product design, production and deployment.

        15+ years of experience
        Combining electronics, mechanics and software within mobile robots has been our day-to-day activity for more than 15 years. From concept to mass production, we put our expertise at your service.

        Experts in navigation
        Building robots is one thing, controlling them is another. At BlueBotics, we have developed the innovative ANT® solution, a proven navigation product line enabling the localization and control of any platform. S

        Swiss made
        Our robots are not only engineered in Switzerland, they are also built there. Together with our network of suppliers, we deliver solutions with the Swiss Made quality label, which guarantees that your application will perform perfectly both now and in the future.

          • Engineering services

              • From idea to product

              • From idea to product

                Based on the company’s mission to enable the mobility of vehicles for automation, BlueBotics provides robotics engineering services to build solutions tailored to your needs. BlueBotics’ approach is to perform a feasibility study before starting any cost intensive phase.

                The next phase is prototyping, which relies on standard mobile bases like mini and min lite, and/or proven components, allowing to provide a solution in a timely and costly effective manner.

                Once the prototype is validated, our team can support you with the final product design, production and deployment.

              • mini

              • Compact vehicle ready for cleanroom applications

                The mini vehicle has been designed to fulfill the increasing needs of new applications in cleanrooms, laboratories, light-load logistics, etc.The concept of mini is to provide the most compact and efficient mobile platform on which the customer can implement his own application.

                As for today, mini is available with two lift modules as well as a roller conveyor.
                BlueBotics’ engineering services allow to develop additional custom specific modules on demand.

                mini is the ideal mobile base to enable Your application in cleanrooms and laboratories!

                mini;
                Dimensions L x W x H 59 cm x 40 cm x 30 cm
                Weight platform 70 kg
                Weight module 15-25 kg
                Payload 150 kg
                Max speed 1.5 m/s
                Autonomy >6 hours
                Charging time 1.2 hours
                Automatic charge Included
                Safety 360° laser scanner view
                ISO5 Certification on demand



              • mini lite

              • Compact vehicle for your application

                The mini lite vehicle is an evolution of the mini; solution, similar in terms of functionality and modularity but more adapted to “standard” environments.
                mini lite also provides modules dedicated to a specific application, which are today available as two lift modules as well as a roller conveyor.
                Other modules can either be developed directly by the customer, or on demand with BlueBotics engineering services.
                mini lite is the ideal mobile base to enable Your application!

                mini lite
                Dimensions L x W x H 68 cm x 46 cm x 39 cm
                Weight platform 100kg
                Weight module 15-25 kg
                Payload 100 kg
                Max speed 1.5 m/s
                Autonomy >6 hours
                Charging time 1.2 hours
                Automatic charge Optional
                Safety 270° laser scanner view (360° with optional 2nd laser scanner)



            • Success stories

                • SITA – Kate, 2017

                • Objective

                  Design and produce three prototypes of autonomous checkin’ kiosk.

                  Challenges

                  • Design three new vehicles from scratch
                  • Integrate existing components from standard checkin’ kiosks
                  • Less than four months from specification to delivery

                  Solution

                  BlueBotics firstly worked with SITA to clearly define the use case, then teamed up with designers to define the aesthetics and ergonomics before developing and producing the 3 Kate prototypes in an extremely short time.

                • Cleanfix – RA 660 Navi, 2014

                • Objective

                  Create an autonomous professional cleaning machine for airports, hospitals, hotels, and shopping centers.

                  Challenges

                  • Design a compact navigation system
                  • Develop a coverage solution ready for real-world
                  • Integrate the control of the whole cleaning machine

                  Solution

                  BlueBotics redesigned the navigation system, developed a coverage algorithm, and automated the cleaning components together with Cleanfix to obtain a fully integrated solution.

                • Oppent – EVOcart, 2014

                • Objective

                  Design a new hospital vehicle with a complete software suite to easily integrate into the hospital’s infrastructure.

                  Challenges

                  • Design an industrial vehicle from scratch
                  • Develop a complete traffic management solution
                  • Provide flow management and infrastructure control

                  Solution

                  BlueBotics supported Oppent in the design of the vehicle, developed a complete traffic management solution and teamed up with a strategic partner for flow and infrastructure control.

                • Geneva Airport, 2013

                • Objective

                  Provide innovative and user-friendly services for the passengers at the Geneva airport.

                  Challenges

                  • Develop a robot guide for the airport
                  • Develop a suitable user interface
                  • Integrate in the airport environment

                  Solution

                  BlueBotics worked with Geneva Airport’s IT department, with their marketing department, as well as with external designers and interaction designers to develop and produce the complete solution.
