  • Offer Profile
  • The umbrella brand Starrag unites the product ranges Berthiez, Bumotec, Dörries, Droop+Rein, Ecospeed, Heckert, Scharmann, SIP, Starrag andTTL. Headquartered in Rorschach/Switzerland, the Starrag Group operates manufacturing plants in Switzerland, Germany, France, the UK and India and has established a network of sales and services subsidiaries in the most important customer countries.
Product Portfolio
  • Horizontal machining centers

      • Heckert H Series

      • Large workspace, small footprint

        These four-axis horizontal machining centres are space-saving miracles, but they remain true to our stringent quality standards in every respect. They guarantee maximum precision for your work processes thanks to our guiding values of accuracy and rigidity. These are values embodied by Heckert machining centres throughout their decades-long history on the market.

        Heckert H40 / H50: Designed to your benefit

        The basic modular concept of the new Heckert machining centres offers maximum efficiency even with a standard configuration. And that's no coincidence, since a consistent increase in added value for the customer was essential for the development of each individual assembly.

      • Heckert X Series

      • Large workspace, small footprint

        These five-axis horizontal machining centres are space-saving miracles, but they remain true to our stringent quality standards in every respect. They guarantee maximum precision for your work processes thanks to our guiding values of accuracy and rigidity. These are values embodied by Heckert machining centres throughout their decades-long history on the market.

        Heckert X40: Designed to your benefit

        The basic modular concept of the new Heckert machining centres offers maximum efficiency even with a standard configuration. And that's no coincidence, since a consistent increase in added value for the customer was essential for the development of each individual assembly.

      • Heckert T Series

      • Large workspace, small footprint

        These five-axis horizontal machining centres are space-saving miracles, but they remain true to our stringent quality standards in every respect. They guarantee maximum precision for your work processes thanks to our guiding values of accuracy and rigidity. These are values embodied by Heckert machining centres throughout their decades-long history on the market.

        Maximum productivity in minimum space
        Five-axis complete machining

        This five-axis horizontal machining centre with fast-rotating trunnion table is designed for the complete production of complex workpieces in a single clamping position. The trunnion table is positioned and driven on both sides, enabling highly dynamic simultaneous machining that achieves excellent surface quality on workpieces with freeform surfaces and multi angle operations. You will receive a machine that is unique on the market in terms of dynamics, stability and precision.
        You will also benefit from the minimized footprint. The modular design allows for flexible configuration of your machines so you can meet your specific technology requirements. The fast-rotating table expands your machining capabilities compared to a conventional five-axis machine with rotationally symmetrical methods such as turning, turn-milling and hobbing. This process density in one machine saves you investment and production costs and increases your process reliability.

      • Bumotec s128

      • 5-Axis Mill / Turn center

        The 5-axis Mill / Turn center model s128 is a perfect combination of maximum performance and minimum footprint. On less than 2m², the s128 is a concentrate of high technology; Milling, Turning, Drilling, Engraving, Setting preparation and Diamond cutting processes are possible to produce parts as single unit or as serial manufacturing. The machining of miscellaneous parts from bar or blank and demanding perfect surface quality can be achieved with very short changeover time.

        Features

        • Compact machine less than 2m²
        • Flexible manufacturing solution
        • Production from bar or blank
        • 5-Axis simultaneously
      • Bumotec s181

      • Mill-turn machining center from bar stock

        With more than 10 years of experience acquired on our s191 model, the benchmark on the market, Bumotec launches the new series of s181, which combines the best of Swiss made know-how and a high degree of innovation.
        With twin machining stations , a milling spindle capable to reach up to 40'000 rpm's and a high availability of tooling in the automatic tool magazine, Bumotec s181 has the capability to produce complex components from bar stock up to 32 mm diameter.
        The machine mineral casting bed, the latest CNC technology and the linear motor drives ensure uncompromised thermic stability and performances.
        Suitable for Watch, surgical instruments, medical implants and complex micro-mechanical components, the s181 is a major asset to help you to take on the actual and future industry challenges.

        Key features

        • 2 machining stations
        • 5 axes simultaneous machining
        • Combines milling and turning
        • Up to 90 positions for tooling the automatic toll changer
        • CNC FANUC 31i panel
      • Bumotec s191H (32mm / 50mm / 65 mm)

      • 7-axis machining center

        The machines of the s191H series are suitable for turning, milling and grinding of individual parts or from bar (diameters: 32, 50 and 65 mm) in a single setting. The series has an extremely versatile modular structure, which means that it is possible to build any kind of machines from standardised modules for various machining tasks – including a machining center with seven axes and three spindles.

        The CNC Bumotec s191H Linear turnmill center is suitable for complete machining of very complex six sided parts. Linear motors ensure maximum precision and reliable repeatability in the machining of parts. Thanks to the combination of the rapid linear drive (acceleration: 1.1 g; speed: 50 m/min) with a high-resolution Renishaw measurement system (resolution: 1/100 µm) and a stabilised cooling circuit for all heat-generating elements, the s191H Linear achieves excellent productivity. A unique feature is the high-speed spindle (150,000 rpm), on which it is possible not only to turn and mill ceramic parts but, using different grinding discs (measuring 0.5 to 80 mm), they can also be dry-ground.

        Features:

        • Linear driven motors and direct-driven rotation axis
        • Extensive features with a maximum of 7 axes and 3 spindles
        • Unique spindle with high torque
        • Universal bar machining (bar passage: 32, 50 or 65 mm)
        • Large tool changer for 90 HSK40 tools
        • High thermal stability
        • Automatic in/out loading unit for blanks
        • High finish quality
        • Multiple configurations available
        • Simple clamping concept
        • Large choice of clamping systems
        • From Bar to finished part, in one single production cycle
        • Multiple processes (turning / milling / grinding / drilling / gear hobbing / …) and large range of machine configurations and options
        • A multi-tasks machine fully equipped instead of multiple production units
      • Bumotec 191neo

        • Extremely stable during production with a minimum of operator intervention
        • New intuitive and user friendly man-machine interface
        • Focussed on digital transformation

        High-precision multi-task production center

        Extremely stable during production with a minimum of operator intervention, the 191neo offers a formidable level of productivity. Its responsive tool change, the high torque of the Starrag milling spindle, and its thermal signature inherited from the original s191 model, ensure it maintains the programmed production rate and obtains a high finish quality, regardless of the material and complexity of the part to be machined.

        The s191 model has evolved...:

        • Complete machining solution
        • Production from bars or blanks
        • New generation linear motors
        • Up to 7 axes and 3 spindles
        • 5 simultaneous axes
        • Up to 90 tools
        • Peripherals include high-pressure equipment, chip conveyors and bar stock loaders
        • New MMI touchscreen with Windows-based PC
      • Heckert Athletic Series

      • High efficiency and precision - Available in 4- and 5-axis versions

        The medium-sized all round machining centers guarantee maximum efficiency, high machining quality and reliability. The Heckert Athletic series are perfect for a wide field of application in all areas of the metalworking industry.

      • Heckert Large Athletic Series

      • Huge, modular and flexible

        The flexible and modular-designed Heckert Large Athletic Series guarantee optimum results in the economic processing of large-sized and heavy workpieces with an edge length of up to 3,400 mm and up to 13,000 kg in all material qualities.

        Available in 4- and 5-axis versions

      • Heckert DBF Series

      • Turning, drilling, milling

        Thanks to the integrated DBF spindle head, the complex production in the processes turning, drilling and milling can be realized in one single workspace.

        Available in 5- and 6-axis versions

      • SIP 7000/7 4A

      • Ultra precise horizontal machining center

        Ever since it was founded in 1862, the Geneva-based Société d’Instruments de Précision (SIP) has been a benchmark for precision machine tool engineering. The basic design of SIP machines can still be found today in all traditional machining centers, both for vertical and horizontal models.

        SIP 7000/7 (4 and 5 axis)

        The horizontal SIP machining centers are living proof that ultra-precision is by no means a myth. Gearbox housings, spindle heads and two-axis turntables can be machined with significantly higher levels of precision than with conventional machining centers, making them the obvious choice for customers.

      • SIP SPC

      • Super precision machining center

        The SIP SPC Series not only provides the user with the ultimate in precision but also with tried and tested sophisticated automation. Investment in SIP technology produces returns, thanks to above-average long-term precision and many years of durability.

      • WMW IWK Series

      • IWK 4000/5000/600/7000 Series - High Dynamic 4 axis horizontal machining centers

        Benefits

        • Reduction in setup times: workpiece setup on separate loadunload station during processing
        • Perfect cutting conditions for maximum tool life
        • Roughing and finishing operations on one machine
    • Vertical machining centers

        • Bumotec s191V

        • High performances machining center

          The Bumotec s191V is the combination of proven Swiss made mechanics and state-of-the-art CNC control and drive technology. With the CNC Bumotec s191V mill / turn center, precise and complex components can be produced via 5-axis machining. Thanks to its stable mechanical concept and its linear drive technology, accuracies of just a few microns can be achieved. The integration of an individually adaptable automatic workpiece change unit, allows the machine to be used for one off prototypes or to run so called «unmanned shifts» without personnel. Many different configurations are available with three to five axes of machining capacity. The thermal stabilization unit almost eliminates warm-up cycles when starting or after machining interruptions.

          Features

          • Linear driven motors and direct-driven rotation axis
          • High speed spindles (maximum 40,000 rpm)
          • Smart combination of turning and 5-axis machining
          • High thermal stability
          • Automatic tool changer for 90 HSK40 tools
          • Automatic load/unload unit for blanks
          • High surface finish quality
          • Multiple configurations available
          • Easy clamping concept
          • Large choice of clamping systems
        • Bumotec s100 mono

        • 3-axis machining center

          A standalone mono-station machine
          A compact industrial concept for maximum performance taking up minimum floor space
          With its dual spindle concept enabling concurrent tool change operations, its high dynamic acceleration, its powered spindles capable of a rotation speed of up to 60.000 min-1, its high number of tools, the s100 is a modern production tool pushing back the boundaries of high-precision machining.
          The s100 range makes it possible to produce highly complex parts. Ideal for 3 axis machining of watch movement parts, it has also proven itself unbeatable in a whole host of fields, such as mobile telephony, electronics or nanotechnologies.

          Features

          • Unique dual spindle concept
          • Highly dynamic acceleration, up to 3g
          • 1 machining station
          • Up to 36 tools integrated into the machine
          • Chip to Chip in 0.5 sec
          • 60.000min-1 on the tool
          • Linear motors
        • SIP 5000/6

        • Ultra precise vertical machining center

          Ever since it was founded in 1862, the Geneva-based Société d’Instruments de Précision (SIP) has been a benchmark for precision machine tool engineering. The basic design of SIP machines can still be found today in all traditional machining centers, both for vertical and horizontal models.

          SIP 5000/6 / 5000/7

          The SIP vertical range is a must for all producers of parts with high levels of value creations. It enables ultraprecision positioning and the closest of dimensional tolerances for drilling and milled surfaces.

      • Blade and Blisk machining centers

          • NB 151

          • Blisk machining center

            No matter if it is called a «Blisk» (bladed disk) or an «IBR» (integrally bladed rotor), no matter if it is single stage or multi stage, Starrag’s dedicated machine concept of the NB series provides the best solution for efficiently machining these parts. Blisks made from Titanium, Nickel-based superalloys and the Blisks made of blade steels for stationary gas turbines triggered the development of the NB series. For all the necessary manufacturing operations Starrag provides the benchmark: Efficient roughing for Blisks machined from solid, adaptive machining for friction welded Blisks, high dynamic finishing of the airfoils in point contact. Shortest cycle times and zero scrap rate production are achievable on the Starrag NB series. The NB series is based on the very successful Starrag LX series.

            Number of Spindles 1
            Max. Blisk Diameter mm 600

          • NB 251

          • Blisk machining center

            No matter if it is called a «Blisk» (bladed disk) or an «IBR» (integrally bladed rotor), no matter if it is single stage or multi stage, Starrag’s dedicated machine concept of the NB series provides the best solution for efficiently machining these parts. Blisks made from Titanium, Nickel-based superalloys and the Blisks made of blade steels for stationary gas turbines triggered the development of the NB series. For all the necessary manufacturing operations Starrag provides the benchmark: Efficient roughing for Blisks machined from solid, adaptive machining for friction welded Blisks, high dynamic finishing of the airfoils in point contact. Shortest cycle times and zero scrap rate production are achievable on the Starrag NB series. The NB series is based on the very successful Starrag LX series.

            Number of Spindles 1
            Max. Blisk Diameter mm 750

          • NB 351

          • Blisk machining center

            No matter if it is called a «Blisk» (bladed disk) or an «IBR» (integrally bladed rotor), no matter if it is single stage or multi stage, Starrag’s dedicated machine concept of the NB series provides the best solution for efficiently machining these parts. Blisks made from Titanium, Nickel-based superalloys and the Blisks made of blade steels for stationary gas turbines triggered the development of the NB series. For all the necessary manufacturing operations Starrag provides the benchmark: Efficient roughing for Blisks machined from solid, adaptive machining for friction welded Blisks, high dynamic finishing of the airfoils in point contact. Shortest cycle times and zero scrap rate production are achievable on the Starrag NB series. The NB series is based on the very successful Starrag LX series.

            Number of Spindles 1
            Max. Blisk Diameter mm 1100

          • LX 021

          • Turbine blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.

            Max. distance between centers mm 440
            Swing Diameter mm 200

          • LX 051

          • Turbine Blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.

            Max. distance between centers mm 565
            Swing Diameter mm 400

          • LX 151

          • Turbine Blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.


            Max. distance between centers mm 995
            Swing Diameter mm 400

          • LX 251

          • Turbine Blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.

            Max. distance between centers mm 1495
            Swing Diameter mm 400

          • LX 351

          • Turbine Blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.

            Max. distance between centers mm 1805
            Swing Diameter mm 650

          • LX 451

          • Turbine Blade machining center

            The LX series was specifically designed for the high-precision, efficient five-axis machining of turbine blades. This ultra-modern machining platform is the result of decades of experience in the development of machine tools, CAM systems and special tools combined with our in-house expertise in the prototype and series production of turbine blades.

            Max. distance between centers mm 2805
            Swing Diameter mm 650

        • Portal and Gantry machining centers

            • Droop+Rein TS/TFS NEO

            • 6-axis machining center

              Flexibility, efficiency and precision play a very important role for machine manufacturers and tool builders, especially when dealing with large components. These three requirements led to the development of the gantry machining centre TS/TFS NEO with a fixed and movable crossbeam, whereby the customer chooses the table designs, controls and milling units suitable for them on a modular basis. The TS/TFS NEO features a new milling unit and a modified C-axis (±400°) which, thanks to its enormous flexibility, can be used for efficient production of highly precise machine parts.

              The large number of automatically changeable milling heads increases the machine's flexibility within its scope of application.
              The TFS also allows automatic tool or spindle changing and tool or workpiece measurement.

              Table size
              Length mm 2,000 - 5,000 mm + 1,000 mm steps
              Width mm 2,000 - 3,000 mm + 500 mm steps

            • Droop+Rein T/TF

            • 6-axis machining center

              With the T/TF series, Droop+Rein offers gantry machining centres for heavy-duty machining in many sectors: Applications range from tool and mould making, aircraft component manufacturing and engine manufacturing to general mechanical engineering. Based on the robust, highly accurate and powerful basic machines, the T/TF series offers an extensive system of innovative automation and expansion stages that enable the machines to be adapted flexibly to each machining task.

              The optional automatically changing fork-type milling head makes complex and demanding machining possible. Through extensive application know-how, a variety of different milling heads are available -including vertical milling heads, angle milling heads, and fork-type milling heads for positional or simultaneously controlled applications.

              Table dimensions
              Length mm 3,000 - 10,000 mm + 1,000 mm steps
              Width mm 2,000 - 4,500 mm + 500 mm steps

            • Droop+Rein G/GF

            • 6-axis machining center

              How can large, heavy-duty and bulky workpieces be processed without adversely affecting the weight and size of the machining result? The Droop+Rein G/GF series has been specifically developed to tackle this difficult task. The gantry machines reliably prevent dynamic losses through the table and workpiece. The G/GF series has many technical highlights to meet the requirements of complex machining tasks, such as the hydrostatic guide in all linear axes or the thermo-symmetrical design of the spool milling unit with an integrated C-axis. Milling heads can be changed automatically via a head change interface.

              Droop+Rein has developed over 300 different milling heads for a variety of applications - such as machining large diesel engines. The option to set up in a second working area during the machining time allows increased productivity.

              Clamping plate size
              Length mm from 8,000 + 1,000 mm steps
              Width mm 3,000 - 12,000 (+ 500 mm steps)

            • Droop+Rein GS / GFS NEO

            • Large, precise, economic

              Gantry design - For machining of largest and heaviest workpieces Droop+Rein offers a floor guided gantry machine line. Best accessibility and utilisation of floor space for largest workpieces combined with highest flexibility in size and configuration.

              Cross rail, moveable (GS) or fixed (GFS)
              Economic machining of largest components – flexible, dynamic and precise
              Floor space savings compared to table moving machines
              In line with the modular principle – various controls, table configurations, milling head/spindles and tool changer configurations

              Clamping plate size
              Length mm 3,000 – 30,000
              Width mm 2,000 – 3,000

            • Droop+Rein FOGS NEO

            • 6-axis machining center

              With the FOGS NEO series, Droop+Rein has developed a powerful machine concept for complex machining. The range of services covers processes from machining standard geometries and pre-finishing contours to final finishing. For dynamic machining with the highest feed rates, the concept caters for the movement and acceleration of constant masses, regardless of workpiece size and weight. Dynamic and flexible: With its new, highly flexible and fast C-axis (±400°), the Droop+Rein FOGS NEO high-speed machining centre is ideal for the complete multi-functional machining of very large workpieces.

              Of course, the series also features automatic pallet or tool change, tool diameter and length measurement and automatic billing of contour deviations. Thanks to a variety of components and peripheral devices from their modular system, Droop+Rein can create an efficient and process-oriented overall system that is tailored to the customer.

              Clamping plate size
              Length mm 3,000 - 30,000 + 1,000 mm steps
              Width mm 2,000 - 6,000 + 500 mm steps

            • Droop+Rein FOGS HD

            • 6-axis machining center

              In order to produce heavy workpieces with limited available space, Droop+Rein combined the FOGS and TF machine types - which are already established on the market - into a new machine concept. With the FOGS HD, Droop+Rein offers a machining centre for heavy-duty machining, which features high quality and precision at the same time.

              The constant dynamic dimensions of the Droop+Rein FOGS HD enables the user to use the machine for unmanned finishing - e.g. at night or at the weekend.

              The Droop+Rein FOGS HD is designed for large components, as the traverse paths show (X-axis: 3,000 to 31,000 mm; Y-axis: 3,000 to 6,000 mm; Z-axis: 1,500 to 2,500 mm). It covers all machining operations within typical toolmaking. The FOGS HD is an efficient (50 to 100 kW (S1 operation)), precise machining high-gantry machine with fast and dynamical axes and extreme high torque (2,400 to 7,500 Nm).

              Clamping plate size
              Length mm 2,000 - 30,000 + 1,000 mm steps
              Width mm 2,000 - 5,000 + 500 mm steps

          • Vertical turning lathes

              • Berthiez TVU Series

              • Vertical turning lathe

                The vertical lathes of the TVU product line of Berthiez are especially suited for machining engine and turbine components, which are primarily used in the aerospace industry as well as for alternative and classical power generation. The TVU vertical lathes are characterized by a complete cast design, high-precision static and dynamic positioning as well as long-lasting reliability.

                Advantages of the TVU vertical turning lathes are, completely cast iron construction, high static and dynamic axis stability, high accuracies and long term reliability. For higher flexibility the machine can be equipped with several pallet change systems and adaptable milling heads. The optional Y-axis table traverse will permit the turning, milling and grinding of complex components in a single clamping.

              • Dörries CONTUMAT VCE Series

              • Vertical turning lathe

                The compact single column vertical lathe (swing diameters of 1,400 to 2,800 mm) is appropriate not only for turning, but, with additional units, can also be used for drilling, milling and grinding. It means that it is possible, in a single clamping, to carry out a full machining operation on the CONTUMAT VCE and not simply turning.
                The rigid cast construction on this lathe ensures low vibration and accurate cutting; hydrostatic guide rails damp vibrations even further. The technical design and numerous fitting options mean that Dörries is able to configure an individual machine to every customer.

              • Dörries CONTUMAT VC Series

              • Vertical turning lathe

                The Dörries CONTUMAT VC series, designed as a double column portal system, is ideal for larger swing diameters of 3,500 to 12,000 mm. The VC range combines all of the advantages of the VCE range with the ability to machine large scale components just as effectively. The positive construction properties of the smaller range are taken over here in correspondingly dimensioned main components. The range also provides high levels of flexibility by combining standard modules, providing the customer with a solution tailored to suit their individual needs.

                The closed portal construction of the double column vertical lathe guarantees high intrinsic rigidity, while the proven cast construction ensures excellent damping and thermo-stability. Thanks to these characteristics customers obtain a lathe that provides high machining accuracy, with a long service life.

              • Dörries CONTUMAT VC-V Series

              • Vertical turning lathe

                With the addition of a moveable table, traversing through the twin column portal design of the VC machine range, the VC-V provides the ultimate flexibility for machining large components. In addition to the «on center» machining capability of a standard lathe the VC-V machines are able to machine eccentric features. With the use of our extensive range of standard milling and drilling attachments, the VC-V machine range is capable of full 5 sided machining of components up to 12,000 mm in diameter and 350 tons in weight.

                On machines with a Y-axis the component can be machined in any position. The turning table is set on a sliding bed. The default Y-axis travel corresponds to the swing diameter of the machine size, but can be tailored to suit any application.

            • Vertical grinding machines

                  • Berthiez RVU Series

                  • Vertical grinding machine

                    The RVU grinding machines set new standards in high-precision machining and are especially suitable for high precision grinding applications in the bearing and aerospace industries. The range can be equipped with up to four water-cooled grinding spindles which can achieve a performance of 45 kW at 18,000 rev/min. (according to the type of grinding wheel selected)

                    The RVU facilitates a complete machining processing without interruption as optional dressing units, grinding wheel changers and workpiece measurement are available. Additional options for hard metal machining boring and workpiece measurement increase the possible applications of the machine series considerably.

              • Faceting machines

                  • Bumotec s210 / s220 / s230 Series

                  • Faceting and diamond finishing center for dials index

                    s230 is an automatic solution for faceting and diamond finishing dials index. s230 production center allows the production of a wide variety on index in various metals. Contrasts of different visual effects are performed by the use of diamond tools or solid carbide tools. The complete solution for small and medium series for finishing index combines multiple operations on a single machine.

                    Features

                    • Optical recognition and origin definition of blanks
                    • Diamond with the revolver toolholder
                    • Machining of LuniNova pockets and micromilling
                    • Simple programming interface on Windows
                    • A variety of automation systems are available to ensure a high level of autonomy in production
                • Transfer machines

                    • Bumotec s1000C

                    • 4-axis horizontal transfer machine

                      The Bumotec s1000 C horizontal transfer machine was designed to manufacture prismatic parts from round or profiled bar stock. Small and complex components can be efficiently machined in medium to large batch sizes.

                      The machine is configured with seven 4-axis machining stations, each equipped with 4 machining spindles (2 horizontal and 2 vertical). The eight stations comprise a 4-axis cut off station with a single spindle. An optional ninth station allows the component to be re-clamped to allow the sixth side of the component to be machined with an additional 3-axis, 3 or 4 spindle machining unit. The machine is equipped with an automatic bar feed and quick change tool clamping system for optimum production rates.

                      Features:

                      • 9 machining stations
                      • Up to 36 tools integrated into the machine
                      • Chip to Chip in 0.5 sec
                      • 10.000min-1 on the tool
                      • High autonomy
                    • Bumotec s100multi

                    • Multi stations production center

                      A 4-station transfer machine
                      A compact industrial concept for maximum performance taking up minimum floor space
                      With its dual spindle concept enabling concurrent tool change operations, its high dynamic acceleration, its powered spindles capable of a rotation speed of up to 60.000 min-1, its high number of tools, the s100 is a modern production tool pushing back the boundaries of high-precision machining.
                      The s100 range makes it possible to produce highly complex parts. Ideal for 3 axis machining of watch movement parts, it has also proven itself unbeatable in a whole host of fields, such as mobile telephony, electronics or nanotechnologies.

                      Features:

                      • Unique dual spindle concept
                      • Highly dynamic acceleration, up to 3g
                      • 4 machining stations
                      • Up to 36 tools integrated into the machine
                      • Chip to Chip in 0.5 sec
                      • 60.000min-1 on the tool
                      • Linear motors
                      • Pallet change transfer system
                      • High autonomy
                  • Aerostructures machining centers

                      • Scharmann ECOFORCE Ti 9 / Ti 13

                      • 5-axis machining center

                        The ECOFORCE Ti 9/13 is the modular solution leading in machining titanium structures

                        • Full range of pallet sizes from the ECOSPEED series available between 1 x 4 m up to 2.5 x 8 m
                        • 2D head made for Ti-machining with 8,000 rpm / 940 Nm (S1) or 5,600 rpm / 1,300 Nm (S1) known
                        • 100 bar coolant supply for longer tool life
                        • Modular concept with multitude of options for all customer needs
                      • ECOSPEED / ECOLINER Series

                      • 5-axis machining center

                        Ecospeed is the synonym for the most economic method of machining complex aluminium structural components in the aerospace industry. Based around its’ unique parallel kinematics Sprint Z3 machining head, Ecospeed represents by far the most productive solution for the high performance cutting of monolithic aluminium aerostructures. The Ecospeed family has been continuously developed to meet market demands. New challenges imposed by the market are implemented within a team framework, by maintaining intensive contact with end users.
                        Yet another recent customer-driven requirement placed on the Starrag Technology GmbH management board was to supply an optimized economic Ecospeed variant for machining long and narrow structural components at high cutting rates and using complex 5-axis geometries with 5-side access to the work piece.

                      • STC Series

                      • High performance simultaneous 5 axis mill turn center

                        The STC series has been designed to provide unrivalled economy in the machining of the most demanding structural parts, multi-blades and casings with long cycle times, and provide the customer with a whole host of practical options. These machining centers have excellent static and dynamic properties as well as a tried and tested rotatable head, making them the benchmark for heavy chip removal in titanium and Inconel part for the aerospace and power generation industries.
