Our strength is not only the production of standard products but also the development and manufacturing of special products acc. to customers’ specifications. Every year we manufacture more than 1500 special products on our customers' requests. Every single product is a challenge for our technical team.
Halogen-free cables & wires are applicable in delicate areas as, for example, public buildings and institutions or railway vehicles and in areas where the general safety requirements for cables are very high.
Besides being halogen free, the used cables have to be flame retardant and self extinguishing and are not allowed to enhance flame propagation. All those characteristics are combined in our halogen-free SABIX®cables & wires. Halogen-free SABIX® cables can be fully recycled and in separate components newly supplied to there source cycle. Cables with FRNC outer sheath avoid flame propagation in case of local flaming and are flame retardant and self-extinguishing acc. to VDE, EN, and IEC. They fulfil the smoke density acc. to IEC, EN, VDE, and BS.
In the following overview we would like to give you a survey of different construction types of shielded cables & wires that are often used for industrial applications. If you don´t find an appropriate LSZH cable for your special application please get in contact with our cable experts. As a leading special cable manufacturer we are able to design and to produce a special cable that meet your special requirements.
Flexible cables for cable tracks are especially designed for use with high reversed bending stress as for example in production lines, high rack storage areas or pacing machines. They show a very good durability with very small bending radius.
Cable track cables are produced especially for applications with highly flexible bending stress. One of our top products within this product range is our type S 980 P. With UL recognition, CSA and VDE approval this cable reflects the high quality standard of our cable track cables.
Our highly flexible cables are suitable for constant use with extremely high bending stress during multiple-shift operation. You can use our advanced cable technology in order to enhance the efficiency of your machines and appliances and, therefore, always be one step ahead of your competitors.
Extreme harsh environments demand highly resistant materials. These requirements are fulfilled by our cables made of ETFE, FEP or PFA. These cables can be used for a temperature range from -90°C up to + 260°C. Furthermore, our ETFE, FEP and /or PFA insulated cables are resistant against many chemical influences with high mechanical resistance at the same time. Possible application fields are for example chemical industry, furnace construction and telecommunication.
In the following overview we would like to give you a survey of different construction types of resistant cables & wires that are often used for industrial applications. If you don´t find an appropriate cable for your special application please get in contact with our cable experts. As a leading special cable manufacturer we are able to design and to produce a special cable that meet your special requirements.
Bus Cables are used for the digital signal transmission between for example sensors and the corresponding display units. Due to the high transmission rate and data flow, standard data cables are not sufficient any more. For applications as for example parcel conveyor belts, sorting units in recycling plants and waste glass sorting a very quick transmission , evalutation and reaction are of greatest importance. We manufacture cables for nearly all standard bus systems as for example Interbus-S and loop, CAN bus, Profibus, DeviceNet and Safety Bus.
In the following overview we would like to give you a survey of bus & ethernet cables for the different bus systems that are often used for industrial applications. If you don´t find an appropriate cable for your bus system please get in contact with our cable experts. As a leading special cable manufacturer we are able to design and to produce a special bus cable that meet your requirements.
Control & connection cables are used for the current supply for any electric motor. In general, they have a green/yellow earth conductor in the outer layer of the twisted assembly. In order to avoid the spreading of occuring electromagnetic fields, we often produce control cables with tinned copper braiding. Furthermore, we produce cables with an outer sheath made of PUR which are appropriate for an application under harsh environmental conditions as, for example, in glass manufacturing or in metal chipping industries.
In the following overview we would like to give you a survey of different construction types of control cables & wires that are often used for industrial applications. If you don´t find an appropriate cable for your special application please get in contact with our cable experts. As a leading special cable manufacturer we are able to design and to produce a control cable that meet your special requirements.
Data cables are used for the trouble-free transmission of signals. The small currents can be protected by aluminium coated PETP-foils, copper braidings and/or wrappings to 100 % coverage. The signal decoupling is additionally achieved by pairwise twisted cores. Our data cables are for example used for the transmission of measuring, control and voice signals in electronic control appliances or in switchboards.
Modern electronics and miniaturized appliances require data cables with smallest cross sections, best screenings and highest flexibility. SAB data cables meet these requirements to a high degree. Different types of screenings, i.e. single or double screens, tinned copper wrappings or braids, protect the cables against outer high-frequency interference. Different types of strandings (in layers or pair-wise) can prevent mutual interference of adjoining circuits. Especially in the computer era data cables have become essential and they must continously to the latest technical developments. The colour code with reference to DIN 47100 guarantees a perfect assignment of the cores for the connection of the cable. The cables are produced with reference to the usual DIN VDE regulations.
Compensating cables & thermocouple extension wires are used for the transmission of thermoelectric voltage from thermocouple to cold junction, the so called "black box".
Due to the different applications as for example in smelteries, cold stores or in liquid gas systems where always a reliable and safe transmission of the occuring thermoelectric voltage in mV must be ensured, the compensating cables & thermocouple extension wires manufactured by us are insulated with different materials respectiveley the thermoelectric voltage and cable are protected by braidings, foils and/or armouring.
With our subsidiary “KANSA Kabeltechnik“, we at SAB BRÖCKSKES have enlarged our product range by cable harnessing products. It does not matter if it is a standard or special product, we design and produce high quality cables as well as ready-made cables with plug. We offer a broad product range from harnessed single cores, cables, or complete cable sets according to your special prescriptions and requirements.
Our harnessed cables are used for the most different industrial applications. They are, for example, used in automobile industry, machine, plant, and drive construction as well as in industries for household appliances. The varied combination possibilities of plug types and terminals offer economic solutions together with the numerous application possibilities of the different materials treated by SAB.
Please contact us. – We will find your individual solution!
From the manufacturing of the cable to the UL approved cable harness
Since 70 years the cable manufacturer SAB delivers special and harnessed cables to national and international industries.The advantage for the industry of such complete solutions is not only that we develop and produce special cables according to customer´s requirements but also the delivery of the pre-harnessed cable to the immediate connection at the final place of installation.
The SAB BRÖCKSKES GmbH & Co. KG has completed its range of harnessed cables with the certification acc. to UL Standard Wiring Harness“ category ZPFW2 (UL)” and “ZPFW8 (Canada) and herewith strengthens its position as cable specialist for cable harness acc. to customer´s specification.
Good results are not by luck and chance, rather belong to years of experience, sophisticated technology, expertise, and the ability to develop the new, to examine and improve the existing. Our innovative strength is the basic prerequisite to successfully meet the challenges of existing and future market developments. As always, a new and further development of our products takes place to complete our range of services and to consolidate our position in the market and to expand.
The varied combination possibilities of plug types and terminals offer economic solutions as well as the numerous application possibilities of the different materials that we process.
In all product ranges we are certified acc. to ISO 9001:2008. Besides, we established an environmental management system for our company acc. to ISO 14001:2004, an occupational health and safety management acc. to NLF/ILO-OSH 2001 and OHSAS 18001:2007 as well as an energy management system acc. to DIN EN 50001:2011.
Our harnessed cables are used in many different industrial branches, for example, the automotive industry, machine, plant, and control system construction as well as in household appliance industries. We offer a broad programme especially according to your requirements and specifications. The varied combinations of the plug types and the stop parts offer rational and economic solutions. Here, we follow a high quality standard by a continuous quality control.
We produce harnessed cables with moulded plugs on request also for your special application.
We manufacture cable assemblies according to your special requirements. The varied combination possibilities of plug types and terminals as well as the different basic and sheath materials of our cables offer economic solutions for the most different applications.
Manufacturer of thermocouples & resistance thermmometers
For centuries people were only able to grasp temperatures subjectively as cold or hot. The invention of the first objective temperature measuring device based on the expansion of air goes back to Galileo Galilei approx. in 1592. Today, temperature measurement technique disposes of a great number of highly specialized sensors and methods that allow to determine exactly and reproduce the thermodynamic state of the matter and thus, its temperature almost between 0°K and, for example, the temperature of the sun.
Electric thermometers turn the physical value of temperature into a dependent signal. They are self-contained constructive components that deliver an output signal for further treatment. Dependent on the sensor principle, in most cases an auxiliary energy source is necessary. An important advantage results out of the good transferability of those electric symbols over far distances. The transducer and indicator of temperature can be situated far away from each other. The measuring signals can be integrated and treated with small effort into control respectively process guiding systems.
As a leading manufacturer of electric thermometers for many different applications we would like to support you to choose the suitable thermocouple for your individual application. On the corresponding product page you will find the technical data and characteristics. In case that you don´t find the appropriate thermocouple, we are always prepared to assist you. We design and produce thermocouples and resistant thermometers due to customers request that is tailor-made to your requirements and application field.
HV Temperature Sensor - The measurement system is especially designed for safe temperature measurement on HV components and is excellently suited for mobile and stationary use in the field of electric mobility: electric and hybrid vehicles.
Tested safety from measuring point to data logging
✓ temperature measurement on HV components
✓ suitable for mobile and stationary use in the field of e-mobility
✓ it can be used in close proximity to the measuring point
✓ type test of the complete system by an accredited laboratory
The temperature measurement with resistance thermometers (RTD) is based on the characteristic of conducting materials to change their electrical resistance with temperature. For metals, the resistance increases with rising temperature. If the relation between temperature and resistance is known, you can determine the temperature by measuring the resistance.
Resistance thermometers change their electrical resistance in dependence on the temperature or, in other words, resistance thermometers use the fact that the electrical resistance of an electrical conductor varies with changing temperature. In order to collect the output signal, the resistance is fed with a constant measuring current and the created voltage drop is measured. Platinum RTDs Pt 100, Pt 500 and Pt 1000 are used as measuring probes. They are standardized acc. to DIN EN 60751. Their resistance is 100 Ω at 0°C. The most different construction types of platinum resistance thermometers are applied in industrial measuring technique.
SAB BRÖCKSKES offers a broad range of thermocouples for industrial applications. It does not matter if the temperatures of exhaust gases, fuel, at live parts or air conditioning have to be measured or if the tyre temperature must be controlled, our products can be used for the most different temperature measurements.
In the following overview we would like to give you a survey of different construction types of thermocouples & RTD´s that are often used for industrial applications. If you don´t find an appropriate temperature measurement system for your special application please get in contact with our experts. As a leading manufacturer of temperature sensors we are able to design and to produce a customized thermocouple that meet your requirements.
The optical 3D measurement technique offers a lot of advantages as for example a contactless and quick measurement and replaces more and more the classic and mechanical measuring methods. Moreover, the tactile measuring technique not only takes a lot of time but also bears a high source of error. The optical and contactless measurement processes are 10 to 1000 times quicker and the error rate is comparatively low.
The demands on the measuring devices and the corresponding accessories are respectively high. SAB Bröckskes accepts this challenge and offers a highly flexible CATLine cable range for a combined power supply that is suitable for highly dynamic movements in 3D scanners and measurement devices. The Ethernet and hybrid Ethernet cables of this range guarantee a reliable signal transmission of 3D measuring data, geometrical dimensions of components and surface characteristics in 3D sensors, cameras, lasers and quality assurance systems.
The application range of this 3D measurement technique are for example production and inline measurements, quality assurance as well as development and design.
Robust ISOBUS cables in agricultural engineering according to ISO 11783-2
The control and monitoring of machines and equipment in agricultural engineering places high demands on communication interfaces and bus systems. Harsh environmental conditions such as those caused by weather, dirt, ammonia or microbes require robust solutions for reliable operation. Cables are particularly exposed to these adverse environmental influences. SAB offers reliable ISOBUS cables and systems according to ISO 11783-2 for installation in tractors, working machines and attachments. In addition to the standard dimensions and cross-sections available on the market, SAB also offers customer-specific designs, even for small production sizes from 100 m, for prototypes and sampling.
