- Offer Profile
- The quality and performance
of KEB solutions is continuously proving itself in the equipment and systems
of our customers. We create movement. And we are also always on the move.
Always with the target in sight: To create the optimum drive and control
technology solution that is tailored to your requirements. Trust is not a
gift, but rather the result of hard word, ambition and reliability - "Made
Automation & Controls
- KEB COMBICONTROL C6 - the automation platform
dedicated to dynamic transmission applications in machine and plant
engineering. The KEB product portfolio is scalable and tailored to your
requirements, offering a wide platform for all kind of automation jobs.
Hardware - with the embedded control C6-COMPACT and the IPC-based
control series C6-HMI, C6-VISU, C6-ECON and C6-PERFORM KEB offers different
controller platforms with scalable processing power for decentralized
architecture or central machine control.
Software - KEB offers automation tools for to handle effective
control jobs, high-class visualization and cost optimized remote
KEB COMBICONTROL C6
- KEB COMBICONTROL C6 is the automation platform that
focuses on dynamic and drive-oriented applications with motion control in
the machine and equipment building sector. Scalable and tailored to your
requirements, this control technology, which was designed with embedded and
IPC versions, offers a broad platform for a variety of tasks.
The KEB COMBIVIS studio 6 automation tool is the new software environment,
freely programmable pursuant IEC 61131-3.
- C6 COMPACT is a compact control whose functionality and
performance are designed to coordinate and synchronise the motion processes
of multiple axes.
The integrated EtherCAT Master provides a rapid real-time bus system that in
combination with computing performance and software functionalities
represents a truly powerful and cost-effective system.
Equipped with all possible options, the C6 COMPACT can assume control of
your entire system or merely look after the motion processes of your
application as a subordinate system with numerous interfaces such as
Profibus, CAN, Interbus and Ethernet.
This efficient concept without a superimposed operating system uses the
entire computing performance for the application of Soft PLC and motion
tasks and allows for cycle times starting at 1 ms. The C6 COMPACT is full of
possibilities, and offers a cost-effective system for solving your
requirements notwithstanding its flexibility and high performance.
C6 HMI - Embedded Panel PC
- The C6 HMI was designed using the latest graphic and
communication technologies typically found in modern day smart devices such
as tablets and smartphones. As a result, the C6 HMI provides the user a high
quality Human Machine Interface experience while providing the user a
competitive "right-price" edge.
"Right-price" does not mean the C6 HMI wasn’t designed for an industrial
environment! The front bezel is aluminum and meets IP66/Nema 4X Indoor
ratings. There are no moving parts: no fans, no hard drives. A fanless
cooling design and flash mass storage maximize reliability.
- The C6 VISU series has been prepared for the specific
requirements that apply to visualisation tasks, and it forms the
human-machine interface in a variety of applications.
An attractive design, high-quality materials combined with extensive
functionality at a reasonable cost.
In combination with realtime software the IPC serves typical control and
motion tasks in smaller machines.
- The C6 ECON was built with the power for processing
tasks. On-board RAM provides a good balance between cost and visualisation
performance. Designed for economy and built with an Intel chip set, the user
can easily use the C6 ECON as a panel PC for both a Human machine interface
(HMI) and for motion control.
To maximize up-time, the C6 ECON was designed as a fanless system. Data
storage is achieved with hardware options such as Compact Flash (CF), hard
drives or newer solid-state drives.
- The C6 PERFORM is KEB’s top end of product performance.
Based on the Intel® Celeron Dual Core and Core® 2 Duo processors, the user
can expect high performance visualisation. With the on-board processing
power, the C6 PERFORM can easily be the Human Machine Interface AND the
machine motion control.
- The C6 MONITOR series complements the BOX PCs with an
industry monitor for visualisation and operation of the application.
Sizes based on latest technologies complement the program offered by KEB
appealing design and various monitor sizes.
A front USB port, and two more on the back with integrated HUB belong to the
C6 REMOTE I/O
- Analog or digital - the acceptance and output of signals
in the periphery of a system requires the decentralisation of joining
technology and a suitable medium of signal transmission to central
intelligence. The KEB REMOTE I/O system is based on the economically optimal
Ethernet hardware and transfers the proven characteristics of real-time
communication into each element of the input/output level using the EtherCAT
COMBIVIS studio 6
- KEB COMBIVIS studio 6 combines drive parametrisation,
IEC 61131-3 application development and HMI designer into a flexible tool
that allows for highly efficient and customised application designs in the
automation technology sector.
KEB COMBIVIS studio 6 is the entry-level option for programming pursuant to
the international standard IEC 61131-3, which can be used for the
independent and future-proof creation of your source code using a flexible
selection of programming languages. Benefit from the comfortable „SmartCoding"
programming tools for declaration, error diagnostic, debugging and on-line
data analysis purposes.
COMBIVIS studio HMI
- KEB COMBIVIS studio HMI is a powerful extension of the
The special feature of this platform is the universality and portability of
visualisation projects, which can be used both with WinCE as well as Win32
systems, and also support automatic scaling for different display sizes.
Two run-time versions, BASIC and ADVANCED, are available for the WinCE
operating system. The Win32 operating system comes in three versions -
BASIC, PRO and ADVANCED - which guarantee an optimum functional scope for
- KEB COMBIVIS connect is the innovative software solution
for remote access and maintenance of computer based industrial machines with
Windows operating systems (WinCE and Win32 / 64 environment).
The new COMBIVIS connect product creates a VPN (Virtual Private Network)
between office computers and remote devices and guarantees access to remote
- COMBIVIS connect Client: application on the office computer (supervisor)
COMBIVIS connect Runtime: software component on the remote computer
- KEB COMBIVERT - Digital drive technology with 15 years of production experience
The program for controlled and regulated applications for synchronous and asynchronous motor technology in demanding applications up to 900 kW.
Innovation and continuity form the foundation for our powerful series, for which logistics and production have been configured so as to ensure the long-term and parallel availability of current and new product generations:
- Using the "as much as required" principle, we provide
graduated power ranges that offer features and equipment that have been
optimised for each application.
In this context, integrated operation, identical handling and the same tools
assist with the practical work for installation, start-up and service
The drive generation KEB COMBIVERT F5 offers the following features:
Power range 0,37 ... 900 kW
- "High Performance Inverter" stands as synonym for a range
of devices from 0,75 kW up to 30 kW / 400 V whereby all requirements can be
fulfilled for the open-loop operation of three phase motors.
Some highlights of this model range:
• STO-integrated safety according toDIN ISO
13849-1, PLe or rather IEC 62061, SIL3
• Innovative EMC solution by the use of novel core materials for long motor
cables up to 100 m for the environments C1 and C2
• Variable support by future-oriented field bus systems like CAN, EtherCAT
and projected Profinet
- The new entry-level inverters with the proven features of
KEB drive controllers!
KEB COMBIVERT B6 - comprises the new entry-class at KEB, available in
0.37 kW / 0.75 kW / 1.5 kW and 2.2 kW -
1 ph. 230 V AC and
0.74 kW / 1.5 kW / 2.2 kW and 4 kW -
3 ph. 400 V AC
- KEB COMBIVERT F6-K - Single Axis Drives
KEB COMBIVERT F6-K is controlled and regulated drive technology ready for
the networked world - designed 13849-performance level 62061-SIL 3 in a kit,
consisting of seven physical sizes with integrated security STO ISO e / IEC.
The devices are highly compact designed and optimized for use in single axis
applications in machinery and equipment. The entire series uses a power
range from 1,5 up to 900 kW in the voltage range 230, 400 and 690 V AC.
- Top of the line products in equipment and machinery
building are based on dynamic drives that are increasingly being designed as
closed-loop systems. Depending on the physical requirements, these
requirements are met by particularly robust and low-maintenance alternating
current or brushless synchronous or asynchronous motors.
Single axis or multi axis solutions are the ideal solution depending on
power range, number of axis and load profile. KEB COMBIVERT offers both!
- The new servo solution
COMBIVERT S6 is the new integrated servo drive controller in book size
format for high dynamic machine solutions up to 5,5kW.
It offers following highlights:
Moreover, it offers an integrated two channel multi encoder interface, a
GTR7 braking transistor and an integrated brake controller for direct
connection of a PM brake.
integrated EtherCAT and CAN interface for highspeed connection to control
onboard Safety Functionality and an integrated EMI filter class C2 with low
leakage current for residual current detectors.
The high overload capacity of 250% for 3s and 200% for 60s is especially
designed for high dynamic applications like packaging, food processing, tool
machinery, spindles, lift or woodworking applications and special machinery.
Servo Drive KEB COMBIVERT F5 Multi
- Closed-loop drive controller for synchronous and
asynchronous motors up to 900 kW with modular pluggable sensor systems.
Basis for distributed, decentralized control architecture in the drive with
internal functionalities such as:
- Speed and torque regulation
Positioning control with train mode
Synchronous run control, electronic transmission
Simple positioning, round table positioning, register function
All drives support the isolated serial interfaces Profibus, CAN, Sercos,
InterBus, DeviceNet, Modbus, Ethernet, EtherCAT, Powerlink, Profinet and
KEB-HSP5 / DIN 66019-II.
KEB COMBIVERT F6-K
- KEB COMBIVERT F6-K is controlled and regulated drive
technology ready for the networked world - designed 13849-performance level
62061-SIL 3 in a kit, consisting of seven physical sizes with integrated
security STO ISO e / IEC.
The devices are highly compact designed and optimized for use in single axis
applications in machinery and equipment. The entire series uses a power
range from 1,5 up to 900 kW in the voltage range 230, 400 and 690 V AC.
KEB COMBIVERT H6
COMBIVERT H6 is a modular drive system for synchronous- and asynchronous
motors up to 160 kW with DC coupling of links. It implements a universal
system for the simplest applications such as u/f controlled ASM all the way
to sophisticated NC axes.
All axis modules have been designed with an identical compact installation
height of 400 mm and 200 mm module depth for space-optimised system
integration. Designed for variable centralised cooling concepts based on
water or air.
Cooling concepts electronics
- The KEB COMBIVERT F5 modular system provides
mechanical solutions for particularly thermal loads with respect to
inverters and servo controllers, with the aim of optimising heat removal
from the classic control box.
Convection Heat Sink
- ... are particularly compact and the basic version, often
with supporting ventilation, for conventional control box installations of
IP20 protection type devices.
Push Through Heat Sink
- .... reduce heat in the panel by up to 80%, i.e. forms
the basis for compact and tightly sealed cabinets. With the thermal
separation of the heat sink and the installation of the devices in a
two-part panel, heat is shifted to the outside, which leads to better
ambient conditions for the electronic components.
Flat Rear Heat Sinks
- ... create an interface for using existing environments,
e.g. thermal connection to the machine or a master heat sink.
Liquid Cooled Heat Sink
- This is a closed cooling system for the design of
hermetically sealed enclosures for challenging ambient conditions. Liquid
cooled heat sinks guarantee the cooling of large power stages also in
conjunction with liquid cooled motors.
Supply and regenerative units
- All moving systems have kinetic energy when in
operation. When the motor slows down it acts as a generator and converts the
mechanical energy back into electrical energy, which then is shunted into a
braking resistor that results in heat. The power supply and line
regeneration control R6 provides a solution to balance energy or return
energy to the utility grid.
- The kinetic energy of AC motor drives is often an
unutilized energy source.
The compact new product KEB COMBIVERT R6 is designed for power supply and
regenerative operation for inverters and servo systems.
KEB COMBIVERT R6 can be operated at line voltage from 200 - 500 VAC. The
design is modular with a compact commutation choke and EMI filter. In
conjunction with the KEB COMBILINE harmonic filter solutions a sinusoidal
regeneration to the utility grid is achieved.
KEB COMBIVERT R6 has a display to show the energy savings while regenerating
to the grid.
- Designed for temporary and continuous feedback
operations, COMBIVERT F5-AFE offers the basis for system solutions for
permanent feed and others as applied in trigeneration and block heat and
power plants, biogas facilities and also small wind power facilities.
The production of other types of grids represents another application area;
they are also used for test facilities or test stands.
At present, power ranges of 7.5 kW to 250 kW are available based on
industrial device hardware.
- The connection of electrical drives makes it possible to
internally balance motor and regenerative energy loads.
KEB COMBIVERT R5 comprises central feed modules for DC-bus coupled frequency
inverters and servo drives.
The integrated braking transistor and the central DC fuse reduce the
complexity of the system installation.
The centrally supplied machine features lower power consumption and higher
resistance in case of line-voltage drops.
- We connect drives to controls.
Based on the modular structure of fieldbus operators, all KEB COMBIVERT
drive controllers can be operated in all commonly used serial fieldbus
You choose the right networking platform for your application!
Ethernet, EtherCAT, Powerlink, ProfiNET
- Ethernet-based solutions…
use the worldwide expansion of the IT network technology for industrial
It begins with powerful EtherCAT master implementations in the embedded and
IPC-based controls, continues with the integrated EtherCAT slave versions in
the COMBIVERT H6 multi-axis system, or the current COMBIVERT G6 inverters,
and is rounded off with fieldbus solutions for decentralised I/Os with the
module KEB Remote I/O system for complete automation.
Ethernet TCP/IP is a cost-effective way of connecting the drive level to the
IT level, and allows for easy start-up and diagnostics.
Powerlink and Varan also lend real-time properties to the drives, which are
thus made available for highly dynamic applications and motion operation.
The extensive market penetration of Ethernet IP is supported in the US by
our local subsidiary KEB America.
Profinet RT and IRT are additional solutions currently serviced by KEB for
pluggable operators for COMBIVERT F5, and which are planned with further
integrated versions in the future.
Profibus, CAN, Sercos, InterBus, DeviceNet, Modbus
- Established Fieldbus Connections...
... have long been the "motor" for advanced concepts of systems and machines
in conjunction with sensors and actuators in the process chain.
With the modular operator system, KEB supports all recognised standards for
the entire bandwidth of inverters and servo systems.
Pluggable functional components make initial equipment and later
retrofitting in the field very easy and flexible.
- As the amount of electronics increases, EMC loading and
EMC compatibility is becoming an increasingly important factor for the
operational reliability of machinery and equipment.
European norms and standards require manufacturers and operators to comply
with a set of EMC limitations.
KEB designs, manufactures and supplies a comprehensive programme for
limiting noise levels created by the mains and motors, and for optimising
Competent advice and mobile EMC measurement devices support onsite selection
and optimisation - i.e. they warrant reliable compliance with statutory
requirements in a variety of applications.
KEB COMBILINE HF Filter
- Variable speed drives with uncontrolled rectifier input
can cause low or high frequency interference on the line that are limited by
the EMC regulations.
Adherence to the standards is ensured with the use of universal EMC filters
for individual interference suppression at the drive controller or as a
central filter, designed for complete installation in a panel.
KEB COMBILINE interference suppression filters are designed for industrial
or residential areas and can be supplied with currents rated up to 1000 A.
Segments: single filter IT line filter, filter for small leakage currents,
3-phase central filter, central filter with neutral (4-phase system),
combined input/output filters.
KEB COMBILINE Harmonic Filter
- The low-frequency harmonics resulting from B6 rectifier
switches pose an increasing burden on public grids and must be limited with
expensive and cumbersome compensation facilities.
The KEB COMBILINE harmonic filter is a patented passive component which
provides a connection-ready alternative for original equipment or the
retrofitting of production facilities. Two models of these compact filters
- standard series with THD (total harmonic distortion) smaller than or equal
to 8%, PWHD smaller or equal to 15% in power settings 4 - 460 A.
economy series with THD smaller than or equal to 15%, PWHD smaller or equal
to 38%. According to standard EN 12015 (European elevator/escalator norm) in
power settings 2 - 63 A.
Larger power settings can be covered with connecting filters in parallel.
Sinusoidal Output Filter
- The cyclical output voltages of frequency inverters
produce additional losses in motor leads and windings which can
significantly affect the reliability and longevity of motor insulation.
KEB COMBILINE sinusoidal output filters limit stresses to admissible limits
and provide the required protection of lacquer insulation and end
connections particularly for long motor leads and special motors.
The protection offered by sinus filters is particularly important for the
retrofitting of already installed older motors with frequency inverters to
optimise the efficiency of existing systems.
The sinus filter range includes the following versions:
- sinusoidal output filter fmax = 100 Hz
sinusoidal output filter fmax = 200 Hz
sinusoidal output filter fmax = 400 Hz
and customer-specific versions for output frequencies up to 1600 Hz.
- With respect to the specific requirements of machine
building, we supply a comprehensive accessories programme that has been 100%
designed for KEB drive controllers.
The free PC tool KEB COMBIVIS provides software that can be used for all
devices, and which simplifies handling, diagnostics and optimisation
Power and motor chokes reduce the reactions from the pulse-shaped subsequent
loading and additional stress of the motor winding from cyclical output
voltage. Both units also represent an effective measure to extend the
service life of components in the equipment.
The braking resistors, which are designed for different duty cycles,
economically convert short-term energy peaks from regenerative loads into
- KEB COMBIVIS is the universal and effective tool for all
former and current KEB drives.
The new version KEB COMBIVIS 6 in .net-based structure is ready for the
needs of the future and supports the controls and drive controllers as of
KEB COMBIVIS 6 is factory-tested with operating systems Windows 2000, XP,
Vista and Windows 7, and has been designed as a free too for the complete
administration of all device adjustments, amongst others:
- display and adjustment of all parameters up to 8 parameter sets
display of units and monitoring of operating data
configuration of customer-specific parameters in the "CP level"
analysis of communication between drive and control
The established KEB COMBIVIS 5 version continues to support all former
device series such as Type KEB COMBIVERT 56 / F0 / F1 / F2 / F4/S4 and all
current generation KEB COMBIVERT F5 / G6 / B6 devices.
It can be run on all PCs with serial interface and systems software Windows
95, 98, NT, XP, Vista and Windows 7.
KEB COMBILINE Mains Input and Motor Chokes
- The B6 rectifier input circuit in the input of variable
speed drives causes current ripples that strain the DC-bus capacitors in the
inverter and generate harmonic distortions in the utility grid.
The power choke (50/60 Hz) flattens the charging current and reduces
harmonics - both are important factors for the reliability and lifetime of
The modulated output voltage of the inverter creates additional stress for
the insulation and can result in functional problems in the device in the
case of long motor leads.
KEB COMBILINE power chokes flatten the output currents, reduce the strain on
the insulation and are available for output frequencies...50 Hz, ...100 Hz
and ...200 Hz.
- The DC-bus capacitors of inverters can only partially
absorb regenerative energy and must be guided from the system to the
outside. KEB COMBIVERT are available with internal brake transistors (GTR7),
which transmit "excess" energy to external resistors.
The OHM-A and OHM-B resistors offer high pulse capacity at a small
installation space and
- feature thermal monitoring through break contacts (series feature)
work without additional noise during braking
Universally prepared for global use and UL/ cUL approved.
universal ancillary components Ohm-A and Ohm-B for high pulse performance
compact substructure module for absorbing smaller pulse energies.
- For more than 40 years, we have used electro-magnetic
forces for starting, stopping, holding and positioning motion axes in
machines and systems.
Electromagnetic clutches will create locking connections both today and in
the future. A wide variety of electromagnetic brakes brings dynamic motion
axes into a secure holding position.
In addition to universal standard solutions, we also offer an experienced
team of application engineers and modern design and calculation tools for a
customised adaption to your application.
Spring Applied Brake KEB COMBISTOP
- KEB COMBISTOP are electro-magnetically operated two-part
spring-set brakes for dry operations, whose brake force is generated by
springs and cancelled by electromagnetic forces. The proven spring applied
brake is used in applications where rotating masses must be slowed down or
shafts need to be held in position.
Our standard program consists of:
we also offer special designs for your specific application needs.
- Minibrake KEB COMBISTOP M
Holding brakes for dynamic applications KEB COMBISTOP N
Holding brakes for static applications KEB COMBISTOP H
Holding brakes for protection class IP 66 KEB COMBISTOP P
Holding brakes for mounting of tachometers KEB COMBISTOP T
Double brakes for theatres, lifts and elevators KEB COMBISTOP D
Elevator brakes D8 KEB COMBISTOP L
KEB COMBIPERM Permanent Magnet Brakes and Clutches
- KEB Combiperm P1 brakes provide power-off brake
engagement with electromagnetic release. KEB P1 brakes are designed using
rare earth magnets which allow for very high torque densities in small
P1 permanent magnet brakes have zero backlash and operate across a wide
range of operating temperatures and voltages — this makes them ideal for the
most precise and demanding applications.
- KEB COMBINORM offers a complete program of brakes,
clutches and combinations as installation and mounting components for
applications in machines and systems. The torque range is 0.5 up to 500 Nm.
Following models also available:
- Electromagnetic Actuated Brake KEB COMBINORM B:
The KEB COMBINORM brake is the most economical solution for slowing down
and holding loads for flange- and shaft-mounted installation in
equipment and systems.
- Electromagnetic Actuated Clutch KEB COMBINORM C:
The KEB COMBINORM clutch uses the force of an electro magnet focused on
two pole faces for the locking connection of shafts and connected loads.
A locking design with tooth rotors and anchoring pieces makes it
possible to transfer maximum torque in small installation spaces.
We have the ability to customize KEB COMBINORM for your structural and
KEB COMBIBOX Clutch/Brake Modules
- KEB COMBIBOX is an integral clutch-brake combination for
start – stop applications in the enclosure, which allows for wear
adjustments without having to dismount the unit thanks to the patented
adjustment of the air gap.
The following models are available:
• COMBIBOX Type 10
• COMBIBOX Type 09
• COMBIBOX Type 06
COMBITRON Rectifiers and Switches
- for the supply and control of KEB COMBINORM series
electromagnetic clutches and brakes.
The product program includes half and full wave rectifiers for AC or DC side
switching as well as rapid switches for optimized starting and stopping. All
products are designed according to the low voltage directive 73/231/EWG.
The following models are available:
• COMBITRON 92
• COMBITRON 94
• COMBITRON 91
• COMBITRON 98
Motors and gears
- Optimal interaction between motor and electronic drive
is the foundation of excellent machine functionality.
Servo motors are the ideal drives for dynamic applications with low inertias
and high peak torques. Asynchronous motors are preferred in applications
with high external load inertias must be safely controlled (in relation to
the motor shaft in the control).
The addition of a sensor system that is right for the application and the
mechanical adjustment of torque and speed characteristics through the
transmissions of the systems results in all-in-one solutions for a variety
of different requirements in machine and equipment building (optionally also
available with brakes).
Ready-made connections provide pre-tested, connection-ready systems with
easy installation for quick start-up.
- TORQUE LINE asynchronous motors are specially designed
for closed-loop operation with KEB COMBIVERT F5 – Multi. These systems offer
an economical alternative for demanding applications with speeds as low as 0
- B3 or B5 motor design
External ventilation IP 55 (optional)
Thermal winding cover 3 PTC resistor
Incremental encoder 2500 ppr / RS 422, 5V DC, 12 pole connector
Spring-set brake KEB COMBISTOP (optional)
KEB Synchronous Servo Motors
- KEB synchronous servo motors are permanent magnet,
electronically commutated synchronous motors - Made in Germany - for
applications with demanding requirements for quality and positioning
accuracy with minimum installation volume and weight.
TA series made by KEB in Schneeberg
TA Series - 5 installation sizes which are optimised and configured for
direct mounting of combigear, helical bevel, helical worm and shaft-mounted
helical systems with nominal torque of 0.8 to 80 Nm.
KEB DYNAMIC LINE
The series for machine building in new design with short mechanics, either
with a smooth or finned surface and high torque characteristics with nominal
torque of 0.2 to 70 Nm.
Inline helical gears
- KEB COMBIGEAR G and ZG Helical Geared Motors...
...are available in 2 series and 10 sizes from 0.12 to 45 kW with a 2- and
3-level assembly and drive torques up to 13,000Nm as flange- or foot-mounted
versions. A refined speed gradient to a minimum of 1.2 rpm provides optimum
torque adjustments on the output side.
The universal installation position, life cycle lubrication and minimal
backlash ensure long-lasting use. IEC mounting flanges are used to adapt any
number of special motors to special requirements.
Directly mounted servo motors provide dynamic solutions with especially high
effectiveness and compact design forms.
All KEB COMBIGEAR can be combined with spring-set brakes, tachometer – and
feedback systems and forced ventilation cooling fans (optional).
Helical bevel gears
- KEB COMBIGEAR K Helical Bevel Geared Motors
...in power ranges 0.12 to 45 kW form 8 mechanical parameters that create a
powerful basis for applications with the highest efficiency for lateral
The gear unit sizes, which can be combined with asynchronous and synchronous
motors, feature a stiff mounting of shaft or hollow shaft, therefore
transmit extensive radial forces even during alternating stresses in
repetitive and reverse systems, and allow for output torque of up to 12,000
Nm for the different sizes.
- KEB COMBIGEAR F Shaft Mounted Helical Geared Motors
Seven installation sizes can be combined with power ranges from 1.5 to 45
kW, and provide an ideal connection to the machine and hence robust and
long-lasting drives due to their space-saving construction and simple
Combined with asynchronous or synchronous motors, output torque up to 8,900
Nm and a minimum output speed of 1.3 rpm is possible, covering a wide range
of application requirements.
- KEB COMBIGEAR S Helical Worm Geared Motors...
...in the power range 0.12…11kW represent the “better standard drive" for
machines and systems due to their superior economic efficiency.
Lifetime lubrication, universal mounting construction and varied output
options (solid shaft, hollow shaft) make this geared motor extremely
- KEB SERVOGEAR AL Planetary Gear
The KEB planetary gears are available in four sizes with output torques in
the range of 5 … 2,000 Nm offering low backlash operation.
With the advantages of planetary gears, including high torsional/axial
stiffness, low backlash, efficiency greater than 95%, thermal length
compensation and compact design, the gearbox is well suited for dynamic
The mechanical connection to the motor is an “assembly and service friendly"
clamp connection that allows for the replacement of individual components
during service, and is also ready for the DYNAMIC LINE motor series.
- Always innovative, KEB is at the forefront supplying
components into the wind turbine industry. Whether you need drive solutions
or brake solutions, KEB can offer the right solution for your application.
KEB sells over 150,000 industrial drives and controls annually. Through the
years, KEB has built a reputation for supplying the best possible solution
for specific applications. This philosophy has led to the development of a
revolutionary pitch drive system and powerful yaw drive solution…
- A pitch drive is used to adjust the rotor blades and regulate the power
transmitted to the mechanical system. A more responsive pitch system allows
the turbine to better react to constantly changing conditions. This puts
less stress on the mechanical system and ultimately provides a better
performing, longer-lasting wind turbine.
- Here are a few examples why KEB’s pitch drive system is superior:
- Small footprint – Innovative heatsink allows for smaller cabinet and cost
- Rugged design – Wide temperature ranges, special shock resistant features,
- Dynamic response – Latest control technology provides the best pitch
- Powerful programming environment – Programmed in accordance to IEC 61131-3.
- Flexible communication – RS232 serial(user defined), ModbusTCP, option
cards: Profibus, CANopen supported
- Integral RFI filter – Robust electrical system
- Precise Position Control – Flexible feedback interfaces; Including absolute
- Single source – System components are optimized to operate together
- Integrated safety features – e.g. switchover to encoderless operation in
case of encoder loss.
- Features as required – Braking resistor, fieldbus communications, 24VDC
supply, battery monitoring, ect.
For decades, KEB has been the leader in supplying electro-mechanical
spring-set brakes. Building on this success, KEB has developed robust and
innovative solutions which the wind turbine application demands.
- Here are a few examples why KEB’s pitch brake solutions are superior:
- Low Maintenance – No bleeding of the lines or failed tubing/fittings
commonly associated with hydraulic brakes.
- Clean Solution – No potential fluid leaks. This makes KEB ideal for offshore
- Easily Assembled – Flexible mounting configurations as required.
- “Fail-safe” Design – Redundant springs provide true power-off
- Rugged IP65 Protection – Designed to withstand the harshest environments
- Features as required – Service hand release, microswitch indicator, special
power/control connectors, and many more…
