  • Offer Profile
  • We have been involved in metal working processes for more than 100 years. Our core products: the QUICK and FIX shelving systems, the MINI-RACK and SPEED-RACK widespan racks, and the MULTIPAL pallet rack, are produced here and successfully marketed far across the borders of Europe. Our team in Arnsberg knows their products and meets the high quality standards.
Product Portfolio

  • Racking & Shelving

      • Shelving

      • Shelving systems are ideal for storing ordinary goods and small parts. With its core products the boltless META QUICK shelving and bolted META FIX shelving, META can offer innumerable customised warehousing solutions.

        With just two building blocks (frame and shelf), complex rows of racks can be constructed for all small parts storage applications (e.g. in spare parts storerooms in industry and small trades, or sales stores in production-linked trade).

        META FIX bolted shelving provides classic cost-effective shelving systems for fixed installations. These shelves are robust and durable, and can be accessed from both sides.

        META QUICK boltless shelving systems can be set up quickly without tools. They can be extended or converted at any time to meet the requirements,
        and can therefore adapt optimally to the stored goods.

        The extensive range of accessories can be used to create innumerable variants, and a series of special solutions such as inclined shelves, racks with storage bins, tyre and wheel racks, and hazardous goods racks.

        Whether it is in the form of small rows of shelves or multi-tier shelving systems, META QUICK provides the optimal solution for any size of warehouse or storeroom.

        All META shelving comes with a 5 year quality guarantee.

        The shelving is available with galvanised surface or with additional plastic coating in RAL 7035 light grey.

          • META FIX bolted shelving

          • META FIX bolted shelving – the classic shelving for fixed installations

            Screw shelving is the classic solution for permanent installation of individual shelving units or rows. The screw connection is carried out completely from the outside using an angle screwdriver.

            • double-sided operation
            • Shelves with system perforation Sin 50 mm increments to accommodate dividers or dividers (exception: 80 kg shelves)
            • Easy installation due to fixed bracket with integrated thread and lens flange head screws with hexagon socket
            • Bottom shelf: Nominal length + 4 mm - Nominal depth + 4 mm
            • Add-on shelf: Nominal length + 2 mm - Nominal depth + 4 mm
            • Bay load: up to 1,460 kg Shelf load: from 80 to max. 230 kg
            • Dimension variants:
              Standard shelf height:2,000, 2,500, 3,000 mm
            • Standard shelf depth:300, 400, 500, 600, 800 mm
            • Standard length: 1,000 mm
            • Single compartment loads: up to 230 kg1)
            • Bay loads: up to 1,460 kg1) 2)
            • Surface: sendzimir galvanised or additionally plastic-coated RAL 7035 light grey

          • META boltless shelving

          • META QUICK boltless shelving – multiple possibilities built from two components

            Consisting of only two system modules (frames and shelves), complex shelf rows are created for all applications of small parts storage (e.g. spare parts magazine in industry and trade, sales warehouse in production-connection trade). Two frame variants are available - completely disassembled (META QUICK S3) or pre-assembled (META QUICK).

            • easy plug-in assembly: quick assembly without tools
            • extensive system accessories
            • Shelves height-adjustable in 25 mm increments for variable adaptation to the stored goods
            • Shelves with system perforation in 50 mm increments to accommodate dividers or dividers (exception: 80 kg shelves)
              Bottom shelf:
              Nominal length + 56 mm - Nominal depth + 36 mm
            • Add-on shelf: Nominal length + 6 mm - Nominal depth + 36 mm
            • Dimension variants:
              Standard shelf height: 2,000, 2,200, 2,500, 3,000, 3,500, 4,000, 4,300, 4,500 mm
            • Standard shelf depth: 300, 400, 500, 600, 800 mm
            • Standard lengths: 750, 1,000, 1,250, 1,300, 1,500, 1,700 mm
            • Single compartment loads: up to 330 kg 1)
            • Bay loads: up to 3,700 kg ( S3 up to 1,380 kg) 1) 2)
            • Surface: sendzimir galvanised or additionally plastic-coated RAL 7035 light grey



          • High bay racking

          • META HIGH-CLIP - UP TO 15 M HEIGHT

            Uprights combined with the tried and tested META shelves are the building blocks for the META HIGH-CLIP high bay shelving system.

            • Flexible, economical modular system
            • Can be used as highbay racking, wide span and wheel racking
            • Shelves + tyre beams: boltless
            • Height adjustable in 25 mm increments
            • Convertible without tools
            • Extensive range of accessories and numerous extension options for a wide range of stored goods
            • Simple, cost-effective assembly
            • Wide range of connection options, e.g. for for automatic small parts store and shuttle racking
            • High stability due to truss framing and diagonal braces
            • Easy attachment of sprinkler systems and lighting
            • Standard equipment and standard heights and lengths for economical applications
            • Shelf includes base plate and screw anchors
            • Equipment: META MULTIFLOOR upright section P60/1.5
            • Extensive accessories possible, e.g.: Additional shelves
            • Rear walls as wire element or solid sheet metal/trapezoidal sheet metal element
            • Side walls as wire- or solid wall element
            • Aisle bridges as optional accessories (e.g. for shelving heights greater than 5 metres between single and double shelving rows)

          • META FIX SET bolted shelving

          • ready-packed units (basic or add-on shelving units) for easy handling and transport
            • Order & clarity at a low price shelving for fixed installations
            • Universal application e.g. in the warehouse, workshop, storeroom, sales room, cellar, office, etc.
            • Shelves ready for attaching accessories such as shelf dividers etc. using the 50 mm pitch punch holes
            • Shelf height adjustable in 25 mm steps
            • Starter bay: Nominal length + 4 mm Nominal depth + 4 mm
              Add-on bay: Nominal length + 2 mm · Nominal depth + 4 mm
              Shelf load: 150 kg
              Bay load: 900 kg
            • Surface RAL 7035 light grey available on request
            • Tip for dealers: Use the take away effect: display META SET at your sales outlet using META product carriers
            • Starter bay: 4 ML 35 uprights, 4 shelves, mounting accessories
            • Add-on bay: 2 ML 35 uprights, 4 shelves, mounting accessories

        • Office shelving

        • META COMPACT office shelving has all-round applications in offices, archives or businesses. It is available with cost-effective galvanised surface or also with shock-proof powder coating in RAL 7035 light grey.

          META office shelving is available both as boltless and bolted shelves. META also offers a series of special office shelves, such as boltless cabinets, hanging file and folder racks, archive shelves, and mobile office shelving.

          The extensive range of accessories allows customised solutions to be created.

          META COMPACT office shelving consists of shelves with 80 kg load capacity. It is therefore optimal for storing document folders. But not just for them - these durable shelves can also store any office utensils tidily and safely.

          The length and depth of the shelves are also perfectly dimensioned for files and folders. For example, 105 folders would fit millimetre-perfect into a 2500 mm high, 1250 mm long and 300 mm deep shelving unit with 7 shelves.

          The bolted and boltless shelving is available in different dimensional variants; in heights 1850, 2200 and 2500 mm, lengths 750, 1000 and 1250, and in the single-sided (300 mm) or double-sided (600 mm) versions.

          As the classic office shelf, META COMPACT bolted shelving is available at particularly reasonable prices. The screwed-on corner brackets are easy to assemble from outside and ensure a high degree of stability.

          They are designed for long-term installation and ensure long useful life.

          META COMPACT boltless shelving can be easily set up without tools. The extensive range of accessories, with side panels, back panels, doors, and much more, mean that the shelves can have cabinet versions and numerous possible applications in very many different areas.

              • META COMPACT office boltless shelving

              • META boltless shelving – just stick them together - and they're ready! The extensive accessories, with side and back panels, doors, and much more, mean that the shelves have numerous possible applications in very many different areas.
                • Quality: the shelves are made of strip-galvanised quality steel sheet for constant use and high holding capacity, available with competitively priced galvanised surface or additionally with impact-resistant powder coating in light grey (RAL 7035)
                • Shelf height adjustable in steps of 25 mm
                  for variable adaptation to the size of stored goods
                • Individually adaptable to your office environment with various shelf heights and widths
                • Starter bay: Nominal length + 56 mm · Nominal depth + 36 mm
                • Add-on bay: Nominal length + 6 mm · Nominal depth + 36 mm
                • Shelf load: from 70 to 100 kg
                • Dimensional variants:
                  Standard shelf height: 1,850, 2,200, 2,500 mm
                  Standard shelf depth: 300, 600 mm
                  Standard width: 1,000 mm
                • Individual shelf loads: 80 to 100 kg
                • Surface: galvanised or with additional powder coating in RAL 7035 light grey

          • Special racks

          • META QUICK shelving systems are ideal for storing ordinary goods and small parts. Besides their extensive range of accessories, META also offers various special shelving based on their core products.

            META has a few interesting solutions for the motor vehicle sector, for example specially constructed tyre and wheel racks. For long-term storage of summer and winter tyres, META can also provide a mobile "tyre hotel", which can hold more than double the number of tyres accommodated by stationary tyre racks.

            For the motor vehicle sector, wide-span racks also provide space for awkwardly shaped parts such as exhaust pipes, bumpers and windscreens.

            Hazardous goods shelves with drip trays or trough shelves are suitable for storing WGK 1-3 water-hazardous fluids and F / F+ combustible fluids.

            Protective equipment racks, corner shelves, parcel shelves with split supports, inclined shelves, and boltless shelves with storage bins find applications across many sectors.

            META QUICK special shelving is suitable for all small parts storage applications, where they bring good order and so make a considerable contribution to storage efficiency.

              • META CLIP Tires & Rim Racks

              • Through combinations of standard parts and special parts, META can provide practical and cost-effective solutions for storing vehicle tyres and wheels. There are two frame variants: can be supplied fully disassembled (META QUICK S3) or preassembled (META QUICK).

                META CLIP S3

                • Tyre / wheel storage: Frame depth 400 mm / 300 mm
                • Height: 2,000 mm; 2,500 mm
                • Length: 1,000 mm; 1,150 mm; 1,300 mm
                • Starter bay: Nominal length + 56 mm · Nominal depth + 36 mm
                • Add-on bay: Nominal length + 6 mm · Nominal depth + 36 mm
                • Shelf load: from 150 to 200 kg

              • META QUICK corner shelving

              • Built up with just two building blocks (frame and shelf) to create complex rack rows for any storage application
                • Easy boltless assembly: rapid set-up without tools
                • Extensive system accessories
                • Shelf height adjustable in steps of 25 mm for variable adaptation to the size of stored goods
                • Length 1: Nominal length + 56 mm
                • Length 2: Nominal length + 11 mm
                • Length 3: Nominal length + 6 mm
                • Depth : Nominal depth + 36 mm
                • Boltless rack with clinched (pre-assembled) frame
                • Reinforcement of the basic unit by bracing beams
                • Dimensional variants:
                  Standard shelving height: 2,000, 2,500 mm
                  Standard shelving depth: 300, 400, 500, 600 mm
                  Standard length: 1,000 mm
                • Individual shelf loads: up to 100 kg
                • Bay loads: up to 2,020 kg
                • Surface: galvanised or with additional powder coating in RAL 7035 light grey

              • META CLIP S3 inclined shelving

              • Boltless inclined shelving with mesh dividers - particularly suitable for carton packed goods, e.g. packets of screws or small parts packed in small storage boxes
                • META QUICK S3 rack system with disassembled frames, provides particularly high stability and load capacity, shelf load 200 kg per level
                • Quick boltless assembly without tools
                • 6 mesh dividers per inclined shelf are included in the delivery: these can be used to set tracks in steps of 50 mm depending on the size of the stored goods, and adjust the track width at any time (no lateral end stops)
                • Shelf height adjustable in 25 mm steps
                • Single-row shelving:
                  Starter bay:                   Nominal length + 56 mm · Nominal depth + 36 mm
                  Add-on bay: Nominal length + 6 mm · Nominal depth + 36 mm
                • Double-row shelving:
                  Starter bay:                   Nominal length + 56 mm 2x nominal depth + 75 mm
                  Add-on bay: Nominal length + 6 mm 2x nominal depth + 75 mm
                • Shelf load: 200 kg · Bay load: 1,400 kg or 1,800 kg

              • META MINI-RACK Order picking solutions

                • Good price-quality ratio
                • 8 roller tracks per tier – adjustable in 6 mm steps
                • Roller tracks can be separated flexibly using the available additional guide rails, to adapt them to the size of goods
                • All of the top tier can be used, as there are no cross-braces
                • Starter bay: Nominal length + 107 mm
                • Add-on bay: Nominal length + 51 mm
                • Frame depth: 1,300 mm overall
                • Shelf load: 200 kg
                • Bay load: 1,200 kg
                • Goods slide automatically over the roller tracks down to the retrieval side
                • Shelf heights are adjustable in 50 mm steps
                • The small front stop bar allows crates and cartons to be taken out easily

              • META QUICK S3 hazardous goods racks

              • Hazardous goods racks for environmentally correct storage of fluids of WGK class 1-3
                • Sturdy META QUICK S3 rack system with disassembled frame
                • Trough shelves with manufacturer's declaration of conformity, suitable for storing WGK class 1-3 water-hazardous fluids and F / F+ combustible fluids
                • Capacity 28 litres per shelf, type
                • Spillage tray with manufacturer's declaration of conformity, type suitable for storing WGK class 1-3 water-hazardous fluids and F / F+ combustible fluids, capacity 45 litres
                • Starter bay: Nominal length + 56 mm · Nominal depth + 36 mm
                • Add-on bay: Nominal length + 6 mm · Nominal depth + 36 mm (dimensional data apply without spillage tray)
                • Shelf load: 150 kg
                • Bay load: 800 and 1,100 kg
                • Quick boltless mounting without tools
                • Shelves with 50 mm pitch punch holes for attaching accessories (applies to rack 3 only)
                • Shelf height adjustable in 25 mm steps

              • META MINI-RACK wide-span racks

              • Suitable for combustible fluids with the F / F+ hazard symbols, and water-polluting fluids of WGK class 1-3. Maximum density of fluids 1.9 kg/l
                • Each consisting of disassembled frame and 2 pairs of beams
                • The beam pairs can be adjusted in steps of 50 mm
                • Suitable for indoor installation only
                • Manufacturer's declaration of conformity (ÜHP) as described in Building Regulations List A Part 1, DIBt
                • Spillage tray capacity 230 litres
                • Collecting pan design: 3 mm steel sheet, hot-dip galvanised as described in DIN EN ISO 1461, with support stands, ground clearance 100 mm
                • Starter bay: Nominal length + 107 mm
                • Add-on bay: Nominal length + 51 mm
                • Scope of supply of starter bay/add-on bay: 2 frames/1 frame (disassembled), 2 pairs of beams, 4 drum holders, 1 oil spillage tray, 1 can holder

              • META A-FRAME Racks

              • FOR VERTICAL STORAGE OF LONG GOODS
                Optimal for vertical storage of light goods such as profiled timbers, strips, panels etc.
                • Clip-on holders (separating arms)/depth: 400 mm
                • Angle of inclination of uprights: 6°
                  max. lateral load supported: 50 kg
                  max. Vertical load: 475 kg per bay
                • Starter bay: Nominal length + 107 mm
                • Add-on bay: Nominal length + 51 mm
                • Surface: Frame RAL 7035, light grey
                  bracing galvanised, beams RAL 7035 light grey,
                  clip-on holders (separating arms) galvanised
                • Important! Clip-on holders are not included in the supply.

              • META MULTIPAL A-FRAME Racks

              • Optimal for vertical storage of heavy profiled timbers, strips, panels, rod materials etc.
                • Uprights and beams support high loads
                • Angle of inclination of uprights: 10°
                  max. lateral load supported: 200 kg max.
                  vertical load: up to 1135 kg per bay
                • Surface:
                  uprights: galvanized
                  beams: RAL 2001 red-orange
                • Starter bay: Nominal length + 170 mm
                • Add-on bay: Nominal length + 85 mm
                • Surface of accessories: separating arms: galvanised dividers: RAL 2001 red-orange
                • Scope of supply of starter bay:
                  2 uprights
                  5 beams
                  small parts + mounting material
                  without separating arms/dividers
                • Scope of supply of add-on bay: as for basic rack but with 1 upright

              • META MULTIPAL pallet racking storage of hazardous materials

              • Based on the proven range of shelving META META MULTIPAL ® S 2000 provides a system for the storage of water-hazardous and inflammable substances with galvanized drip trays. Supplemented with grating floor or drum supports the shelf can be adjusted to the respective requirements.
                • Collectin pan with ÜHP sign
                • Suitable for combustible fluids with F/F+ hazard symbols and WGK 1-3 class water-hazardous fluids
                • Pan collecting capacity depends on dimensions
                • Dimensional Variants:
                  Standard rack height: 2.200, 2.700, 3.300, 3.800, 4.400, 4.900, 5.500 mm
                  Standard rack depth: 800 oder 1100 mm
                  Standard with: 1.800, 2.200, 2.700, 3.300, 3.600 mm
                • Surface: Pre-galvanised od additional plastic coating in RAL 5010 gentian-blue (bracing always galvanised)

              • META MULTIPAL cable reel racks

              • The META cable reel system provides the perfect solution for clear, space-saving storage of all kinds of cable reels.
                • META cable reel racks with A-frames are particularly suitable for clearly arranged storage and attractive presentation at electrical goods wholesalers.
                • These bolted racks can be adapted flexibly to the widest variety of different requirements. Add-ons and extensions can be added easily at a later time whenever required.
                • Quick and easy mounting of system accessories
                • Frame heights: 2,200 to 5,500 mm
                • Frame depth: 1,100 mm
                • Shelf widths: 900, 1,100, 1,300 mm
                • Surface: Uprights powder coated RAL 5010 gentian blue, diagonals and horizontals galvanized, beams RAL 2001 red-orange
                • Accessories such as beams, reel axle mountings and floor anchors are all included. The real axle must be selected

            • Wide-span racks

            • META offers two solutions for wide span shelving - the inserted META SPEED-RACK and the bolted META MINI-RACK shelving. They are versatile and can be used in a wide range of industries.

              Wide span shelving units offer large storage areas for bulky parts and particularly large and/or heavy items.

              META Wide Span Racks - the plugged META SPEED-RACK or the screwed META MINI-RACK rack - are ideal for storing bulky goods with light to medium loads in trade, industry and crafts. It can be used in a wide variety of industries. Both systems are optionally available with chipboard floors or steel panels.

              The plug-in META SPEED-RACK wide span shelving offers very variable positioning options due to its simple basic design and is easy and user-friendly to plan and set up.

              The bolted META MINI-RACK wide span rack is the alternative to pallet racking. The stable shelving offers large storage areas for bulky parts and particularly large and / or heavy items. Storage can be horizontal or vertical.

                • META SPEED-RACK wide-span rack - quick and secure

                • The META SPEED-RACK boltless wide-span rack is perfect for trade, industry and small businesses that need to stock bulky goods of light to medium weight. The simple basic design allows different setup possibilities and optimal serviceability. And the all-round edge protection and optional floor anchoring ensure the utmost security.
                  • Simple design wide-span rack with equal-sided, symmetrical angle sections
                  • Simple to assemble with boltless mounting
                  • Variable positioning due to the basic design, which is particularly user-friendly at the planning and development stage
                  • All-round edge protection of the shelves, which are countersunk in the stepped beam
                  • Shelf heights-adjustable in 50 mm steps
                  • Stepped beam in longitudinal and depth directions
                  • Two supports under each deck
                  • Floor anchoring possible with clip-in metal foot plates
                  • Dimensional variants:
                    Standard rack height: 1,970, 2,470, 2,970 mm
                    Standard shelf depth: 400, 600, 800 mm
                    Standard width: 1,700, 2,000, 2,500 mm
                  • Individual shelf loads: up to 500 kg
                    Bay loads up to 3,000 kg
                  • Profile and beam surfaces: galvanized
                  • Planning dimensions: Nominal dimensions = Actual dimensions
                  • Assembled as basic rack unit only

                • META MINI-RACK wide-span rack – the all-purpose rack with multiple applications

                • META MINI-RACK are best for storing large, bulky and heavy items. Shelf loads up to 600 kg and bay loads up to 4,600 kg are performance data that speak for themselves. The large storage spaces allow objects to be placed and removed easily. This and many other possible combinations make the MINI-RACK an all-purpose rack that is used in many different sectors.
                  • An alternative to the pallet rack
                  • Generous storage space for bulky objects, and particularly large and/or heavy items
                  • Storage position horizontal or vertical
                  • All-purpose rack – with multiple applications across different goods sectors
                  • Shelves adjustable in 50 mm steps
                  • Stepped beams with 200 mm pitch holes for attaching dividers
                  • Dimensional variants:
                    Standard rack height: 2,200, 2,500, 3,000 mm
                    Standard shelf depth: 650, 800, 1,050 mm
                    Standard width: 1,400, 1,800, 2,200, 2,600 mm
                  • Individual shelf loads: up to 600 kg
                  • Bay loads: up to 4,600 kg
                  • Surface: galvanised or with additional plastic coating in RAL 7035 light grey (on request)

              • Pallet racks

                    • META MULTIPAL pallet racks

                    • Easily adaptable to the current goods volume and the required weights of the load carriers, the META MULTIPAL pallet rack is the optimal storage system for all standard loading aids such as Euro pallets and mesh box pallets. Other loading aids can also be stored using our extensive range of accessories.
                      All META pallet racks carry the RAL-RG 614/2 quality mark. META MULTIPAL is the perfect solution for rationalised, well-arranged and adaptable pallet storage.
                      • The optimal solution for rational, well-arranged, and adaptable pallet and piece goods storage
                      • 4 hook-agraffes with height-adjustable in 50 mm steps
                      • Allows either lengthwise or crosswise storage
                      • Closed box sections ensure high stability
                      • Frames are made of cold-worked sections, which are bolted together with the cross-bracing on site
                      • The META MULTIPAL system is a product certified to RAL-RG 614/2 and bears the GS symbol
                      • Static testing: based on the DIN EN 15512 standard
                      • Dimensional variants:
                        standard frame height:
                        galvanized version: from 2,200 mm to 12,000 mm
                        powder-coated version: from 2,200 mm to 6,000 mm (continuous uprights above 6,000 mm as extension frame)
                      • Standard rack depth: 800, 1,100 mm
                      • Standard beam length: 1,800, 2,200, 2,700, 3,300, 3,600 mm
                        other dimensions on request
                      • Individual shelf loads: up to 5.5 t
                      • Bay loads: up to 25 t
                      • Surface:
                        frames galvanized, alternatively with powder coating in RAL 5010 gentian blue (at extra cost)
                      • Cross-bracing galvanized
                      • Beams with plastic coating in RAL 2001 red-orange

                • Cantilever Racks

                • Cantilever racks are the optimal solution for storing all kinds of long goods horizontally or vertically, and for storing sheet goods and panels. META offers two cantilever rack solutions: META ATLAS ST and META MULTISTRONG. These can be used to construct small compact rows of racks for light to medium-heavy long goods, or anything up to cantilever rack towers for heavy timber sections and strips.

                  The cost-effective META ATLAS ST is available in two variants. The cantilever rack is fitted with cantilever arms of equal length. On the long goods rack, however, the cantilever arms are of different lengths, becoming shorter towards the top.
                  The welded cantilever uprights are made of hot-rolled and cold-rolled steel sections. The cantilever rack and long goods rack have a height of 2000 mm and depth of 500 mm, and are available in the lengths 2700, 4050, 5400 and 6750 mm. The spacing, i.e. the distance between the centres of the cantilever arm uprights, is 1350 mm. The load capacity for single-sided uprights is 900 – 1000 kg.

                  The boltless META MULTISTRONG rack comes in two versions: Light and Medium. The META MULTISTRONG Heavy rack is the bolted version.
                  The three versions differ in their cantilever arm loads: Light = up to 220 kg, Medium = up to 535 kg and Heavy = up to 1960 kg.
                  The height of the cantilever arms can be adjusted at any time in steps of 100 mm. The racks are made with solid brand quality hot-rolled IPE 120 sections (Light), IPE 140 sections (Medium) and IPE 180-270 sections (Heavy).
                  This professional system allows the customer to choose from numerous dimensional variants. The Light version is available with frame heights 2000, 2500, 3000 mm, and cantilever arm depths 400, 500, 600 mm, and upright spacings 1030, 1330; the Medium version is available with the same dimensions, plus the additional height 3500 mm and depth 800 mm. The Heavy version is available in heights 3000, 4000 and 5000 mm, depths 800, 1000 and 1250 mm and upright spacings 1000, 1250 and 1500 mm.

                  The surfaces of uprights, arms, foot sections and horizontals are in RAL 5010 gentian blue; diagonals, end stops and small parts of the different racks are galvanised.

                    • META ATLAS ST cantilever rack with welded arms

                    • As cantilever rack with arms of equal length and as long goods rack with arms of different lengths. The flexible solution for horizontal storage of long and heavy goods. The welded cantilever uprights are made of hot-rolled and cold-rolled steel sections.

                      META ATLAS ST cantilever racks

                      • Cantilever arms with the same arm length
                      • Surface RAL 5010 gentian blue
                      • Spacing: 1350 mm (distance between centres of cantilever uprights)
                      • Overall length: length + 55 mm
                      • The indicated depth is the useful depth of the arms on each side
                      • Overall depth: 630 / 1150 mm

                      META ATLAS ST long goods racks

                      • Cantilever arms of different lengths (shortening towards the top)
                      • The whole structure is sandblasted before being lacquered
                      • Surface RAL 5010 gentian blue
                      • The useful arm depth on each side is 150 – -500 mm.
                      • Spacing: 1,350 mm (distance between centres of cantilever uprights)
                      • Overall length: Nominal length + 46 mm
                      • Overall depth: 590 / 1090 mm

                    • META MULTISTRONG Light & Medium cantilever rack

                    • The META MULTISTRONG cantilever rack has proven itself in all types of long goods storage:
                      from small compact rack rows to light and medium weight long goods through to high-rise cantilever racks for heavy sections and sheet goods. MULTISTRONG cantilever racks give you stable brand quality, numerous extension options and rapid access to goods. This will increase your warehouse productivity.

                      META MULTISTRONG L

                      • For horizontal/vertical storage of sheet goods and panels
                      • Hot-rolled IPE 120 sections; perforated on both sides for possible future retrofits
                      • Cantilever arm load up 220 kg, with load evenly distributed.
                      • Load on uprights up to 3,460 kg for cantilevered levels
                      • Foot level load up to 5 times the load capacity of the arms
                      • Cantilever arms can be attached at 100 mm intervals
                      • Cross-bracing in each bay for easiest possible assembly and secure stability
                      • Surface in RAL 5010 gentian blue
                      • Standard frame height: 2,000 mm, 2,500 mm, 3,000 mm
                      • Standard spacing: 1,030 mm, 1,330 mm
                      • Standard arm depth (single-sided and double-sided): 400 mm,
                      • 500 mm, 600 mm

                      META MULTISTRONG M

                      • For horizontal/vertical storage of sheet goods and panels
                      • Hot-rolled IPE 140 sections; perforated on both sides for possible future retrofits
                      • Cantilever arm load up 535 kg, with load evenly distributed.
                      • Load on uprights up to 5,760 kg for cantilevered levels
                      • Foot level load up to 5 times the load capacity of the arms
                      • Cantilever arms can be attached at 100 mm intervals
                      • Cross-bracing in each bay for easiest possible assembly and secure stability
                      • Surface in RAL 5010 gentian blue
                      • Standard frame height: 2000 mm, 2500 mm, 3000 mm, 3500 mm
                      • Standard spacing: 1030 mm, 1330 mm
                      • Standard arm depth (single-sided and double-sided): 400 mm,
                      • 500 mm, 600 mm, 800 mm

                    • META MULTISTRONG HEAVY For Higher Load Requirement

                    • Thanks to its high functionality and flexible application possibilities, MULTISTRONG cantilever racking is used in many industries for the storage of heavy long goods. MULTISTRONG Heavy is also available in combination with mobile trolleys.

                      • For horizontal storage of long goods, storage of sheet and plate goods
                      • Hot-rolled profiles IPE 160-300, upright and base profiles are screwed together
                      • Cantilever arms height adjustable in 100 mm increments (screwed)
                      • stand heights: 2000 - 7500 mm, (every 100mm possible)
                      • Cantilever arm lengths: 400, 600, 800, 1000, 1200, 1250, 1400, 1500, 1600, 1750, 2000 mm
                      • Cantilever arm load: max. 3,400 kg (Profile IPE 80-140)
                      • Structural analysis is carried out in accordance with the requirements of DGUV rule 108-007, RAL-RG614/5 and Eurocode 3.
                      • Cantilever arms with and without deflector (device for unrolling mandrel), effective height of unrolling mandrel 220 mm
                      • Stand incl. floor anchoring
                      • Finish: Uprights, arms, foot sections in RAL 5010 gentian blue, infill, rolling pins and small parts galvanized
                      • Only suitable for indoor installation
                      • Axle dimension: 1000, 1250 and 1500mm

                    • MULTISTRONG H OUTDOOR For Outdoor Applications

                    • Whether under an existing roof or on open spaces, the META MULTISTRONG HEAVY for outdoor use enables you to also efficiently use these storage areas. With this cantilever racking system in hot-dip galvanised design, we also offer you an optimum and individually planned storage solution for outdoor areas. This can also include a custom-fit canopy and side walls.
                      • Dimensions and load values: Individual planning according to your requirements
                      • Robust construction due to hot-rolled, hot-dip galvanised profiles
                      • Design based on our tried and tested META MULTISTRONG HEAVY, the cantilever racking system also for heavy load requirements
                      • Optional: Canopy and rear/side walls including static design for wind, snow and roof loads
                      • Cantilever arms height-adjustable in 100 mm increments (bolted)
                      • Single or double-sided version can be ordered
                      • Clear and safe storage
                      • Can be equipped with gratings, roll-off mandrels and deflectors
                      • Stable dowelling due to supplied ground anchors (foundation requirement on request)

                  • Multi-tier systems

                  • With multi-tier shelving systems, it is possible to make maximum use of the available space inside tall warehouses. Systems like these are often used to store small parts for manual order picking. For these purposes, we offer the META QUICK systems for up to 3 levels, and META HIGH-CLIP for up to 5 levels.

                    We can create tracks in the shelves with intelligent modern design and minimal steelwork. These are attached by brackets to the punch holes in the upright sections, and reinforced by supports according to the track width and/or loading. The simple and rapid assembly means an increased cost advantage compared with competitor systems.

                    The META QUICK multi-tier shelving solution is based on the proven QUICK system and is ready for up to 3 levels. The clinched (pre-assembled) frames are set up, the reinforcements are attached, the shelves are inserted in the clips, and the shelves are now up. Then only the tracks need to be mounted and the system is ready.

                    With the META HIGH-CLIP system, the frames are steel structures consisting of sections bolted together with horizontal and diagonal struts. This type of design ensures a high degree of rigidity and allows 5-tier structures to be created (up to 12m shelf height). Shelves are also attached to their supports by lateral clips, so that the full width of the shelves is available for use.

                      • META MULTIFLOOR The Innovative Shelf, Wide Span and Wheel Rack System

                      • Mezzanine racking connects multi-storey racking systems, covers large areas and can be used in a variety of applications thanks to a wide range of system accessories. Furthermore, strategically favourable traffic aisles can be set up and circulation areas integrated, thus enabling logistical processes to be optimised. This is how META mezzanine racking ensures short picking paths!

                        Various versions are possible:
                        • up to 5 storeys
                        • optimum use of room height up to 15 m
                        • compartment length: 1,000 or 1,300 mm
                        • compartment depth: 300 to 800 mm
                        • wide beams and special tyre beams: 1,000, 1,300, 1,600, 2,000 mm
                        • three column widths (40, 60, 80 mm) each in three different material thicknesses
                        • shelf loads from 80 to 330 kg,
                        • bay loads up to 8.5 t
                        • 100% shelf width utilisation
                        • galvanised surface

                        BENEFITS
                        • economical modular system
                        • can be used as multi-storey racking, highbay racking, wide span and wheel racking
                        • shelves + tyre beams: height adjustable in 25 mm increments, tool-free conversion
                        • direct connection of aisles – thereby reducing component diversity
                        • aisle solutions up to 2.3 m with 500 kg/m2 load capacity
                        • extensive accessories and numerous expansion options for a wide range of stored goods
                        • simple, cost-efficient assembly
                        • wide range of connection options, e.g. for automatic small parts store and shuttle racking
                        • high stability due to truss framing and diagonal braces
                        • easy attachment of sprinkler systems and lighting

                      • META CLIP FLOOR SYSTEMS Up to 3 Floors

                      • Multi-tier rack systems are made up of multi-tier racks built up on large areas, and have flexible application due to the extensive range of accessories. Strategic service aisles can also be arranged and integrated with traffic areas, thus optimising the logistical processes. In this way, META multi-tier racking can shorten your order-picking routes!

                        Different variants are available:
                        • 1 tier: with platform for block storage
                        • 2-tier double the storage space 3-tier
                        • let some air out of your warehouse and make use of the available height
                        • Dimensional variants:
                        • Standard rack height: 2.000, 2.200, 2.500, 3.000, 3.500, 4.000, 4.300, 4.500 mm
                        • Standard rack depth: 300, 400, 500, 600, 800 mm
                        • Standard length: 750, 1,000, 1,250. 1,300 mm
                        • Individual shelf loads: up to 300 kg 1)
                        • Bay loads: up to 3,700 kg 1) 2)
                        • Surface: Galvanised or with additional plastic coating in RAL 7035 light grey

                    • Dynamic warehousing systems

                    • Dynamic storage systems are shelving systems on which goods can move, or which themselves move.

                      META MULTIBLOC is a mobile shelving system which can be used for light archiving applications as a mobile shelving unit based on the proven META QUICK or META COMPACT boltless shelves. For heavier items, the version based on the META MULTIPAL pallet rack system is available, and for long goods there are structures based on the well-known MULTISTRONG range.

                      For items that are to move over the shelves, META offers the MULTILINE range. This range includes a light version for crates and cartons, and a heavy version for pallets which slide down the racks on roller tracks. The heavy versions are fitted with an automatic pallet stop that prevents the pallets from accidentally sliding off the rack.

                      These racks are suitable for cases where numerous items of the same kind have to be stored in limited space. They can be adapted to meet the particular requirements of industrial or trade applications. Our experts will be pleased to advise you if you have any questions regarding dynamic storage.

                          • Mobile racks

                            • META MULTIBLOC shelving
                              for plastic crates, small load carriers, cartons etc.
                            • META MULTIBLOC cantilever racks
                              allow operator aisles to be used as storage space
                            • META MULTIBLOC pallet rack
                              allow operator aisles to be used as storage space

                      • META STEEL STRUCTURES & SYSTEM PLATFORMS

                        • With META's expertise in steel structures, you can make rational use of your space resources; large areas can be built over, and multi-tier shelving systems can be constructed and integrated with traffic areas
                        • Surface areas can be effectively doubled or tripled by building over existing storage areas, workshops and machine rooms
                        • With staircases and elevator systems you can get to any location in your extended warehouse safely, quickly and comfortably
                        • Additional surface area gained by building upward means costs are covered effectively
                        • META structural steel platforms are order-specific – i.e. constructed to your specific requirements
                        • Please include with your inquiry a drawing with the following details:
                          • – location of wall fixing
                          • – layout of loading station
                          • – handrail arrangement
                          • – layout of stairs
                          • – colour (standard colour RAL 5010 gentian blue)
                      • Structural requirements: The static load requirements of the steel platforms meet the guidelines of the national building regulations. Otherwise, the guidelines of the trade associations apply as described in BGR 234 (previously ZH 1/428).
