  • Offer Profile
  • Welcome to METALLUX AG, a technological leader in linear and rotary sensors, resistors, pressure sensors and industrial joysticks in thick-film technology. For more than three decades, we have been dedicated to the needs of our customers from around the entire world. The METALLUX guiding principle defines our actions: a fair partnership for a long-term business connection, combined with personalised and individual consultation for every business partner. Our high-quality products and innovative system solutions are held in high regard in the automotive field, medical technology, industry, wind and solar energy and many other fields. This is due in no small part to our consistent alignment of all developments with the needs of our customers. The Metallux team looks forward to collaborating with you in developing a customised solution for your needs.
Product Portfolio
  • Pressure Sensors

  • Monolithic Pressure Sensors in ceramic and stainless steel for long lasting and trouble-free function. High quality sensors in thickfilm-technology.

    Quality sensors from Metallux, guarantee a long lifetime and fault-free function. The configuration of our pressure sensors, in thick film technology and with directly applied Wheatstone bridge circuit, ensures a reliable operation. A specially designed sensor body together with laser trimming, results in unmatched precision. This technology allows us to supply high quality sensors, working reliably for many years with their characteristics still remaining in the specified range. Typical applications are in materials handling, air conditioning, fluidics, hydraulics and automotive.

      • Pressure Sensors in steel

          • Pressure Sensor Stainless Steel monolithic SPS 1000

          • The stainless steel pressure sensors from the SPS 1000 series offer good overload capacity and high burst pressure characteristics.

            Increased long term stability and ideal in harsh operating conditions.


            Applications
            Brake systems, Forklift trucks, Hydraulic cooling systems, Pressure transmitters, Pressure switches

          • Pressure Sensor Stainless Steel monolithic, 0,5- 4-5 V ratiometric SPS 1000 Z

          • Sensors in stainless steel provide high overload capacity and feature a high burst pressure rating. The 0.5 V to 4.5 V output of the SPS 1000 Z amplifier make further processing of the sensor signal easy.

            As with the pressure sensor SPS 1000 our "Z" version achieves optimal operation even in harsh conditions.


            Applications
            Pneumatic, Hydraulic, Electronic pressure switches, Pressure transmitters

          • Pressure Sensor Stainless Steel integrated pressure connector SPS 3003

          • The SPS 3003 series of stainless steel pressure sensors with integrated pressure connector provides reliable operation in applications with aggressive media. There is no need for a seal between the sensor measuring cell and pressure connection.One piece stainless steel pressure sensor with integrated connection thread ensures media will remain in the system and cannot leak. The high overload capacity and very high burst pressure rating are additional advantages of this sensor.

            Applications
            Brake systems, Forklift trucks, Hydraulic, Cooling systems, Pressure transmitters, Pressure switches

          • Pressure Sensor Stainless Steel integrated pressure connector 0,5 - 4,5 V ratiometric SPS 3003 Z

          • The SPS 3003 Z series combines a stainless steel pressure sensor with an integrated pressure connection and an amplifier circuit. The 0.5 V ... 4.5 V output is proportional to the applied pressure. No seal is required between the sensor and pressure connection, which makes the sensor particularly resistant to aggressive media. Its high burst pressure and overload capacity also makes it ideal for hydraulic applications.

            Applications
            Brake systems, Forklift trucks, Hydraulic, Cooling systems, Pressure transmitters, Pressure switches

        • Pressure Sensors in ceramic

            • Ceramic Pressure Sensors monolitic 1,6 to 400 bar relativ CPS 1184

            • Metallux monolithic pressure sensors are manufactured in large series and are in use in a range of applications in machinery production, the automotive industry, and ventilation and climate control equipment. The easy installation and calibration of the sensors simplifies the customer's production processes.

              The CPS 1184 features a compact design, high media compatibility and excellent long-term stability.


              Applications
              Brake systems, Printing machines, Forklift trucks, Pneumatic, Hydraulic, Electronic pressure switches, Pressure transmitters

            • Pressure Sensor (standard) monolitic, ceramic, 1,6 - 400 bar relativ 0,5 - 4,5V ratiometric CPS 1184 Z

            • The ceramic pressure sensors of the CPS 1184 Z series are integrated with an amplifier are supplied calibrated to an output signal of 0.5 V to 4.5 V. Customers in automation systems or medical engineering regard the easy processing of the signal a great advantage.

              The excellent long-term stability and high resistance against a wide range of media are additional features of this sensor series.


              Applications
              Pneumatic, Hydraulic, Electronic pressure switches, Pressure transmitters

            • Ceramic Pressure Sensor with flush mounted membrane CPS 2184

            • The CPS 2184 sensors with flush mounted diaphragm seal are suitable for measurement of relative as well as absolute pressures. The flush-front diaphragms makes for easy cleaning an important requirement for sensors used in the medical- or the food industry.

              For applications in extreme aggressive media, the pressure sensors are also available with diaphragms consisting of 99,6 % aluminium oxide.

              Applications
              Brake systems, Printing machines, Forklift trucks, Pneumatic, Hydraulic, Electronic pressure switches, Food industry, Pharma industry

            • Pressure Sensor, ceramic, standard, ,5 - 600 bar with flush mounted membrane 0,5- 4,5 V CPS 2184 Z

            • Ceramic pressure sensors CPS 2184 Z with integrated amplifier are ideal for the food-pharma-medical and chemical industries. The sensors are calibrated to an output signal of 0,5 V to 4,5 V. Excellent long term stability. The pressure sensor is well suited to operate in a harsh environment.

              Applications
              Pneumatic, Hydraulic, Electronic pressure switches, Electronic pressure transmitters

          • Linear Sensors

          • Conductive Plastic Linear and Rotary Position Sensors from Metallux are manufactured and designed to specific customer requirements. Our Linear and Rotary Potentiometer elements are manufactured, using substrate materials like polymers, moulded profiles-, or insulated metals. Our potentiometer elements can be fitted into the available space, thus offering excellent value-for-money. Versatile application options: Drive- and control technology, conveyor technique, medical engineering, transport systems, automotive- and heavy duty industry.

              • Potentiometric Position Sensor

                  • Position Sensor Potentiometric Conductive Plastic Linear with housing WPL-OS (without push rod)

                  • Our Metallux linear position sensor WPL-OS without push rod and using conductive plastic technology offers a wide range of integration possibilities as well as an easy installation. The electrical measuring range runs from 30 mm to 300 mm. With linearisation, it is possible

                    to achieve a linearity of up to ±0,25%.

                    Applications
                    Medical technology, Cylinder stroke measurement, Flap control, Valve control

                    Features

                    • Wide range of possibilities for integration
                    • Easy mounting
                  • Positions Sensor Potentiometric Conductive Plastic Linear WPL

                  • As an absolute linear position sensor with robust design and a 3 or 4 mm push rod, the Metallux linear position sensor features conductive plastic technology, a long lifetime and easy installation. The mechanical coupling is by threaded connectors. The measuring range is from 25 mm to 300 mm. Customised versions according to customer specific requirements can be offered.


                    Applications
                    Displacement probes, Cylinder stroke measurement, Foot pedal position, Valve Control

                    Features

                    • Long service life
                    • Easy mounting
                • Linear Membrane Sensor

                    • Membrane Sensor Positions Sensor Linear MTP-L

                    • The linear membrane sensors are well suited for precision position sensing applications in a variety of industries. The MTP-L membrane sensors are non-wearing, easy to install and offer wide possibilities for integration, as well as an IP65 protection class.


                      Applications

                      Medical technology, Cylinder stroke measurement, Flap control, Valve control


                      Features

                      • Wide range of possibilities for integration
                      • Simple mounting
                      • Electrical measuring range of 30-500 mm
                    • Membrane Sensor Positions Sensor linear MTP-LX

                    • Together with the long lifetime, special features of the Metallux MTP-LX membrane sensors include excellent linearity of up to < ±0.3% and temperature resistance up to 105 °C. They are very robust, feature a flat shape and also offer resistance to dust, soiling and liquids.

                      Applications
                      Mirror systems, Adjustment systems in car and truck seats, Controls for car windows and roofs, Medical technology, Solar panel positioning, Robotic systems

                      Features

                      • Protection class IP 67
                      • Resistant to dust, soiling and liquids
                  • Contactless Linear Membrane Sensor

                        • Membrane Sensor Contactless Linear Magnetic MMP

                        • The technology of the MMP series is based on the MTP series. The linear, contactless Metallux membrane sensors can be used for position sensing in a wide range of applications. The contactless measurement is performed by means of a layer of metal foil integrated in the sensor and a magnet positioned at a set distance from the sensor.

                          Applications
                          Linear position sensing for instance in cylinders, Servo systems, Industrial applications

                          Features

                          • Contactless magnetic coupling
                          • Flat design
                          • IP 65, electrical connection and plug excluded
                          • Long service life
                    • Position Sensing LinearPotentiometric

                          • Potentiometer-Element for linear position sensing

                          • Our Metallux potentiometer elements are ideal for position sensing. We custom manufacture these elements according to the customer's specific requirements. They are also easy to integrate into existing installation spaces and feature an extremely long lifetime. Linearisation with accuracy of up to ±0,25% is possible.

                            Applications
                            Linear Position Sensing, Automotive, Industrial applications

                            Features

                            • Customised designs
                            • Various materials
                      • Custom solutions

                            • Membrane Sensors customized

                            • Membrane Sensors whether linear or rotary - sizes and shapes are nearly unlimited. Space requirements for integration are minimal.

                              Metallux develops and manufactures membrane potentiometers in standard as well as in customer specific designs. Variations in lengths or angless are almost unlimited and can be made to suit your specific requirements to this membran sensor. Hich accuracy and repeatibility as well as competetive pricing are just some of their many attractive features.We offer customized solutions.

                              Applications
                              Level measurement in vessels, Position measurements in cylinders, Positioning drives, Use in power tools, Positioning of robot systems, Alignment of antennas, Use in medical technology, Use in automotive industry

                        • Rotary Sensors with Hall Effect

                        • The Rotary sensors with Hall Effect technology allow to programm the rotary angle yourself. The robust Sensor is designed and manufactured to operate in harsh conditions.

                          The conductive plastic rotary Sensors in various custumer specific design is optimized in high linearity and high reliability.

                          More information about our linear and rotary sensors please find in our latest sensor overview; download our latest catalogue.

                            • Rotary Sensors with Hall Effect

                                • Hall Potentiometer POH 120

                                • The POH 120 is small and robust and features a freely programmable rotary angle. The measurement principle is via Hall effect as absolute measuring rotary sensor even after blackout. The POH series is available with a decoupled axis or integrated axis.

                                  Special Features

                                  • Hall sensor
                                  • Compensation for play and tolerance by decoupled axis possible
                                  • Freely programmable angles possible

                                  Features

                                  • Long service life
                                  • Size Ø 13 mm
                                • Contactless Rotary Sensor HMS 220

                                • These contactless, absolute measuring rotary sensors based on the Hall effect are designed with robust housings. The Metallux series of rotary sensors HMS 220 features a long lifetime, excellent linearity and a robust design.


                                  Special Features

                                  Hall sensor
                                  Freely programmable angles possible


                                  Features

                                  • Long service life
                                  • Good linearity
                                  • Robust design
                                  • Excellent value
                              • Rotary Sensors Membrane

                                    • Membrane Sensor rotary MTP-R

                                    • MetaPot membrane sensors are flat, non-wearing and with an IP 65 protection class, offer a favourably priced alternative to other sensor systems. The rotary membrane sensors are ideal for use in precision positioning applications in many applications.

                                      Applications
                                      Rotary position sensing, Servo systems, Industrial applications, Automotive

                                      Features

                                      • Extremly flat
                                      • IP 65
                                      • Adhesive backing
                                      • Long service life
                                • Conductive Plastic with metal case

                                    • Conductive Plastic Potentiometer POL 220

                                    • The Metallux single-turn precision potentiometer POL 220 is housed in robust aluminum housing with slide bearings; the cable or wires of the potentiometer are sealed. The potentiometer shaft is available in diameters of 3 – 6.35 mm. The POL 220 excels with a long lifetime and good linearity



                                      Applications

                                      Valve Control, Joysticks, Steering angle measuring, Servo systems


                                      Features


                                      • Long service life
                                      • Good linearity
                                    • Conductive Plastic Potentiometer POL 230 with ball bearings

                                    • The single-turn precision potentiometer with conductive plastic technology and a servo flange features a robust aluminum housing as well as ball bearings to protect it from high mechanical stress. The cable, wire or pin connection is sealed. The axis diameter can be selected from a range of 3 – 6.35 mm. The POL 230 also features a long lifetime and good linearity.

                                      Applications
                                      Measuring , Servo systems, Valve controls, Joysticks


                                      Features

                                      • Long service life
                                      • Good linearity
                                      • Special Features
                                      • 2x ball bearing
                                      • Diameter: 22 mm
                                      • Service life: 20 million cycles
                                      • Redundant versions
                                      • Special versions possible
                                    • Conductive Plastic Potentiometer POL 120

                                    • The Metallux single-turn potentiometer POL 120, with its robust design, is one of the smallest conductive plastic potentiometers (Ø 13 mm) and features a long lifetime, a wire outlet and good linearity. The servo flange makes precision installation possible.




                                      Applications
                                      Valve Controls, Joysticks, Valve control, Steering angle measurement, Servo systems

                                      Features

                                      • Servo flange acc. to international standards
                                      • Long service life
                                      • Good linearity
                                      • Size Ø 13 mm
                                      • Special Features
                                      • Diameter: 13 mm
                                      • Service life: 3 million cycles
                                      • Connection: Cable wires
                                  • Conductive Plastic with plastic case

                                        • Conductive Plastic Potentiometer POL 200

                                        • The special features of this single-turn potentiometer include plastic housing with injected metal thread and integrated slide bearings. The materials of axis and bearing are choosen to ensure a long lifetime.

                                          Applications
                                          Valve Controls, Joysticks

                                          Features

                                          • Long service life
                                          • Good linearity

                                          Special Features
                                          • Diameter: 20 mm
                                          • Service life: 1 million cycles
                                          • Option: Continuous axis
                                    • Hollow Shaft Potentiometer

                                        • Conductive Plastic Hollow Shaft Potentiometer HWL 60

                                        • The Metallux hollow shaft potentiometer with conductive plastic technology features a long lifetime, a simple design and customised connectors.

                                          Applications
                                          Flap position, Joysticks, Valve controls, Steering angle measurement

                                          Features

                                          • Customised connectors
                                          • Long service life

                                          Special Features


                                          • Redundancy possible
                                          • Service life: 3 million cycles
                                          • Special versions possible
                                        • Conductive Plastic Hollow Shaft Sensor PGL 60

                                        • Extremely robust, with good linearity, excellent resolution and repeatability: These are the defining characteristics of the Metallux conductive plastic hollow shaft precision potentiometer PGL 60.


                                          Applications
                                          Axis position monitoring in robotics, Steering angle measurement on special vehicles, Servo systems

                                          Features

                                          • Hollow shaft
                                          • Extremely robust
                                          • Extremely good linearity
                                          • Excellent resolution and repeatability
                                      • Heavy Duty

                                            • Conductive Plastic Potentiometer POL 790

                                            • The Metallux conductive plastic precision potentiometer POL 790 is extremely robust and features excellent linearity, outstanding resolution and repeatability. The POL 790 is also available with plastic housing.

                                              Applications
                                              Axis position monitoring in robotics, Steering angle measurement on special vehicles, Servo systems

                                              Features

                                              • Extremely robust
                                              • Extremely good linearity
                                              • Excellent resolution and repeatability
                                        • Joysticks

                                        • Joysticks for Industry and Medical Technology

                                          Metallux joysticks are compact, precise, robust and light-weight. Whether you are looking for a standard joystick, a combination of various mechanics with the different sensor technologies (conductive plastic contacts, MetaPot sealed foil potentiometers, Hall sensors), or a custom specific device, our team of experts will work with you to identify the best solution.

                                          Our MJ-xx series joysticks are designed for long-term continuous service and reliable operation in harsh industrial environments as well as in clinical- or rehabilitation applications.

                                            • Joystick 1- and 2-axis analog potentiometric MJ-2K CP OM

                                            • MJ-2K series joysticks with IP66 protection and a special lamellar gaiter seal provide a compact and robust human-machine interface. Analog sensor elements using robust conductive plastic contact technology ensure high-precision control. 1- and 2-axis versions with galvanically isolated directional contacts provide reliable motion control for construction equipment, in mobile hydraulics, for heavy machinery and in marine technology.

                                              Applications
                                              Aerial work platforms, Radio remote controls, Forklift trucks, Hydraulics, Measuring machines, Medical technology, Microscopy

                                              Characteristics

                                              • Long service life
                                              • Robust design
                                              • Compact
                                              • Conductive plastic technology
                                            • Joystick 3-axis analog potentiometric MJ-2K CP OM

                                            • The 3-axis version of the MJ-2K series joystick with IP66 protection excels through its high-precision zero return. A special lamellar gaiter seal provides the required operating reliability even in rough environments. Analog sensors enable high-precision control at low power consumption. Galvanized isolated directional contacts provide reliable operation at construction sites, in robotics, in mechanical- and systems engineering, for construction equipment and marine applications.


                                              Applications

                                              Aerial work platforms, Radio remote controls, Forklift trucks, Hydraulics, Measuring machines, Medical technology, Microscopy

                                              Characteristics

                                              • Long service life
                                              • Space saving design
                                              • Very durable
                                              • Conductive plastic technology
                                            • Joystick 1- and 2-axis digital MJ-2K CP OM

                                            • The MJ-2K series joysticks are also available with digital output signals. Mechanical detents provide tactile feedback. The galvanized isolated directional contacts provide maximum operating reliability for the control of crane systems in factories or on construction sites. Despite their robustness, the joysticks are very light and ergonomically designed for comfortable operation.

                                              Aerial work platforms, Wireless remote controls, Remote controls, Forklift trucks, Hydraulics


                                              Characteristics

                                              • Long service life
                                              • Robust design
                                              • Compact
                                              • Conductive plastic technology
                                            • Joystick 1-, 2-, 3-axis analogue MJ-3K CP

                                            • The MJ-3K joystick series offer compact and robust industrial joysticks which can be supplied with conductive-plastic potentiometer sensor elements in analogue versions as well as with galvanized isolated direction contacts.

                                              The joysticks are available with 1, 2 or 3 axes for applications such as the safety radio remote control of machinery and systems or for mobile hydraulic applications.



                                              Applications


                                              Aerial work platforms, Wireless remote controls, Forklift trucks, Mobile hydraulics, Steering of boats, Grip length 55, Grip length 65

                                              Characteristics

                                              • Long service life
                                              • Robust design
                                              • Compact
                                              • Conductive plastic technology
                                            • Joystick 1- and 2- axis digital MJ-3K

                                            • Digital versions of the MJ-3K joysticks were developed for controlling of crane systems. They can be delivered with mechanical detents for a distinct feedback.

                                              Galvanically isolated direction contacts provide the necessary operational reliability and meet the requirements of the Machinery Directive.

                                              The minimal weight and long service life promote high productivity, whether on construction sites or on factory floors.

                                              Applications

                                              Aerial work platforms, Wireless remote controls, Forklift trucks, Hydraulics

                                              Characteristics

                                              • Long service life
                                              • Robust design
                                              • Compact
                                              • Conductive plastic technology
                                            • Joystick 1-, 2- und 3-achsig analogue membram sensor MJ-3K MTP

                                            • A sealed sensor is the distinguishing feature of MetaPot technology. This technology is also used in the 1-, 2- and 3-axis versions of the MJ-3K joystick series. Analogue output signals and galvanically isolated direction contacts provide reliable manoeuvring of boats and construction equipment. Salty sea air does not influence the function of the joysticks, even though without extra protection of the MetaPotsensors at the joystick. The third axis is realised by a compact, sealed conductive-plastic potentiometer.


                                              Characteristics

                                              • Long service life
                                              • Robust design
                                              • Compact
                                              • MetaPot membrane sensor technology
                                              • EMC-safe


                                            • Joystick 1-axis linear finger tip potentiometric MJ-1L

                                            • The linear joystick of the MJ-1L type series is the robust light-weight of the MJ-xx joystick series. One of its feature characteristics is space-saving in the customer´s housing. The installation space and extra functions, combined with a compact housing are the excellent arguments to choose the MJ-1L. Less weight, easier controls of operations are huge advantages for end users.The robust design

                                              (also available with additional protective cover) guarantees a long service life.

                                              Characteristics

                                              • Ultra Light
                                              • Robust design
                                              • Compact
                                              • Minimal installation dimensions
                                              • Long service life
                                              • Conductive plastic technology

                                              Applications

                                              Remote control, Mobile hydraulics, Comfortable boat monoeuvring
                                            • Joystick 2-axis Hall contactless MJ-4K

                                            • The use of contactless Hall technology in this joystick is recommended if limited installation space is available or the application is subject to high

                                              vibration. The MJ-4K 2-axis joystick fulfils all these requirements to a high dagree. The trusted reliability and proven durability of the MJ-xx joystick series is also incorporated in the MJ-4K series.

                                              The applications are very versatile and range from the rehabilitation industry, automation technology to construction equipment and

                                              marine applications.

                                              The compact Metallux-Joystick in Hall-technology for multitude of applications.

                                              Applications

                                              Platform lifts, Remote Controls, Fork lift trucks, Hydraulic, Robotic, Microscopy, Electro wheel chair

                                            • Joystick putn´stay MJ3K-BRS

                                            • Our Metallux joystick MJ-3K BRS offers a unique and outstanding combination to our customers and prespective clients. By using a modular system, our customers select from various mechanical designs of the MJ-3K joystick, out of the large Metallux range and combine this design with matching sensors, to suit the customers requirements and needs.

                                              Please ask our expert team of joystick and sensor specialists to advise and guide you in your quest to find the perfect solution, tailord to your specific needs an expectations.

                                              Many special applications based on the Metallux standard joystick can be quickly realised to your satisfaction. The picture below shows a Metallux MJ-3K joystick with friction brake "put`n stay".

                                          • High Voltage Resistors

                                          • Metallux High Voltage Resitsors in various designs and shapes. The right decision for demanding and challenging usage. Continuous developments of Thick-Film technology innovations make it possible to apply resistors in different power ranges, shapes and high accuracy on various substrate materials. Applications are in measurement and test engineering, power- and high voltage technology, medical technology, electrostatic, automotive and traffic engineering. Our experts will not only support and advise you in selecting the correct material and size of the resistor for your requirements but will also make sure you choose the most cost effective solution. You are especially interested in our high voltage resistors? Metallux High Voltage Resistors are the right choice for you.


                                              • High Voltage Resistor HVR 967

                                              • With a huge variety of designs, high voltage resistors HVR 967 manufacutred with thick film technology by metallux offer ideal possibilities for measuring, controlling and regulating processes in high voltage applications. Whether for high voltage pulses or for registering constant

                                                high voltages – we have the ideal solution for all your applications in high voltage engineering, high voltage network components, in medical technology, in electrostatics, the automotive industry and traffic engineering.

                                                • Flat shape
                                                • Pulse-proof
                                                • Low inductance
                                                • New: available standard products


                                                Applications
                                                Air ionisation, Electrostatic discharge*, Electrostatic charging**, Electrostatic powder-/wet- coating, Medical technology, Electron accelerator, High-voltage measurement and testing
                                              • High Voltage Resistors HVR 968

                                              • Thick-film high voltage resistors manufactured by Metallux of this HVR 968 type series have been designed specifically for challenging and demanding applications. Heavy-duty and with high electric strength, these top of the range High Voltage Resistor feature the ideal qualities required to achieve excact and reliable measuring, controlling and regulating processes. Whether for high voltage pulses or to register constant high voltages – the Metallux High Voltage Resistor from the HVR 968 series offer the ideal and exact solution for all applications in X-ray technology (medical or industrial), in high voltage measuring technology as well as in energy transmission systems.

                                                • Round shape
                                                • Pulse-proof
                                                • Low inductance
                                                • available as standard or custom specific products

                                                Applications
                                                Measuring resistor (measuring resistor in a high voltage cascade for electrostatic powder/wet paint coating) , voltage divider ( precision-high voltage resistor in high voltage networks), electrostatic, protective resistor

                                              • High Voltage Resitor HVR 969

                                              • Designed and manufactured by Metallux in thick-film technology the high voltage resistors of the series HVR 968 are extremly well-suited to measure and have axcelled in challenging and demanding tasks under very high voltages or for the use as protective high voltage resistors. Whether for high voltage pulses or for registering constant high voltages – Metallux High Voltage Resistors of the HVR 969 series offer the ideal and most cost efficient solution for all applications in high voltage engineering industry, energy transmission technology and-, insulation testing and traffic engineering industries.

                                                • Intrinsic safety
                                                • Pulse-proof
                                                • Low inductance
                                                • New: available standard products



                                              • High Voltage Precision Resistors HPR 967

                                              • High voltage precision resistors were developed specifically for high value measuring applications. The design provides outstanding features for implementation in devices were extreme high precision and most reliable functions are taken vor granted.



                                                Metallux HPR resistors offer the perfect solution for all applications in high voltage engineering, mass spectrometers and in high voltage network components. The medical technology also benefits to a great extent from the extensive know how and vast experience in the design and manufacture of High Voltage Resistors and Hich Voltage Precision Resistors which Metallux has successfully accumulated over the course of many years.


                                                • Flat shape
                                                • Compact design
                                                • Outstanding stability
                                                • Very low inductance
                                                • Minimal drift

                                                Applications

                                                Mass spectrometers, X-ray generators (measuring resistor in X-ray generators) high voltage measurement and testing technology, medical technology, defibrillators, controls for hybrid-and electric vehicles, voltage measurement in battery systems of hybrid-and electric vehicles)
                                              • High Voltage Precision Resistors HPR 968

                                              • The Metallux HPR 968 high voltage precision resistors are in a league of their own when it comes to controling the demanding measuring tasks required in the switching and regulating processes. The high long-term stability makes this type series particularly well-suited for just about applications in industrial and medical X-ray technology as well as for all test processes.

                                                • Outstanding stability
                                                • Very low inductance
                                                • Minimal drift

                                                Applications

                                                Medical technology, electron accelerator, high voltage measurement and testing technology (voltage measurement in hybrid- and electric vehicles), frequency converter, electrostatic.
                                              • High voltage precision resistors HPR 969

                                              • This series of high voltage precision resistors produced by Metallux was designed to simultaneously handle high voltages whilest providing also anexcellent stability. The reliability and precision in recording measurement values are just some of the outstanding features of this type series. At the same time, the Metallux HPR 969 resistors also offer a high loading capacity, making them particularly well-suited for applications in energy transmission, electrostatics and as a protective resistors in electric drives.

                                                • High loading capacity
                                                • Good stability
                                                • Very low inductance

                                                Applications

                                                Medical technology, electron acceleration, high voltage measurement and testing technology, (voltage limitation in electric filters), capacitor discharge, battery management (voltage measurement in hybrid- and electric vehicles), frequency converter, electrostatic.
                                              • High Voltage Pulse Resistors HVI 967, 968, 969

                                              • The generously-dimensioned design of the Metallux high voltage pulse resistors HVI 967, 968, 969 is perfectly suited for energy distribution, providing an ideal solution for pulse applications. Whether for high voltage pulses or pulse sequences – the Metallux HVI resistor offers the perfect answer for many all applications in the high voltage engineering industry in high voltage protection systems and in high voltage network components.

                                                • Flat shape
                                                • High pulse stability
                                                • Very low inductance


                                                Applications

                                                Current pulse limitation, protective resistors, charging-and discharging resistors, air ionisation, power resistors, symmetric resistors, damping resistors (protection of x-ray tubes).
                                              • High Voltage Divider and Resistor Networks

                                              • High voltage dividers and networks are precision resistors that are ideally suited for precise measuring and dividing of voltages thanks to a multitude of combination possibilities. Metallux high voltage dividers are available as a representative selection of various types. Networks are based on special application-oriented requirements.

                                                Please contact us – we will be glad to provide solutions.

                                                • Very good ratio stability
                                                • Low tolerances
                                                • Minimal drift

                                                Applications

                                                X-ray generators (voltage measurement in x-ray generators), high voltage networks (voltage measurement in high voltage networks), electrostatic, medical technology, frequency converter, testing-and verification equipment, diagnostic equipment
                                              • High Voltage SMD Resistors HVS 967

                                              • High voltage SMD resistors augment the reliable HVR 967 type series and present an interesting addition to the classic SMD chip resistors.

                                                • Pulse-proof
                                                • Low inductance
                                                • SMD assembly

                                                Applications

                                                Medical technology, electron accelerator, high voltage measurement- and testing technology (voltage measurement in high voltage circuit networks) capacitor discharge, protective resistors
                                              • High Voltage Potentiometer POC

                                              • The POC 400 high voltage potentiometer is based on a ceramic resistor core, embedded in a well-insulating plastic encasing. Carefully selected high-quality materials, paired with decades of experience in the development and production of linear and rotary sensors, are the guarantee for a long service life without any function loss.

                                                Features

                                                • Adjustable high voltage up to 2.5 kV
                                                • Suitable for implementation in high voltage measurement and power units, spectrometers, electrical precipitators and much more.
                                                • Simple contacting and mounting
                                            • Power Resistors

                                            • Power Resistors in Wire- or Thick Film Technology. The right outfit for any power rating. Metallux supplies versatile Power Resistors manufactured in Thick Film- or Wire Technology. Different shapes and substrate materials can be used. In our wide range there are many application specific Power Resistors. Power Resistors are used in power generation, traffic engineering, drive technology as well as measurement- and control engineering.

                                                • Power Resistors on Steel Substrate PLR 100, 200, 300, 900

                                                • Thick Film Power Resistors in Steel Substrate allow for a high power consumption through their space saving design.

                                                  A broad range of possible resistance values, an extremely small inductivity and universal connection varieties are only some of the excellent characteristics.

                                                • Wire power resistor in ceramic casing PWR-C

                                                • Wire resistors in ceramic casing are power resistors with high load capacity optimised for use in closed systems. Tried and tested resistor

                                                  materials guarantee good long-term stability. Easy assembly and variable connection lines are the advantages of this Type series.

                                                  Applications

                                                  Application as: Circuit resistor, Balance resistors, Grounding resistor, Charging resistor, Heating resistor, Brake resistor

                                                  Application in: Charge filters, Electric machines, Industrial cleaners, Automation plants, Industrial robots, Cranes, Wind power plants, Door actuation

                                                • Wire power resistor in aluminium casing PWR-S

                                                • Wire resistors in aluminium profile combine the high pulse load capacity of conventional resistor materials with optimised thermal conduction

                                                  and a high degree of protection. Assembly on a surface with good thermal conduction properties improves the heat dissipation additionally

                                                  and leads to an increased load capacity. The series PWR-S satisfies the requirements of UL508 and is particularly suitable for applications as

                                                  brake resistor, charging and discharging resistor, or also as heating resistor

                                                  Applications

                                                  Application as: Circuit resistor, Balance resistors, Grounding resistor, Charging resistor, Heating resistor, Brake resistor

                                                  Application in: Charge filters, Electric machines, Industrial cleaners, Automation plants, Industrial robots, Cranes, Wind power plants, Door actuation

                                                • Wire power Resistor in aluminium casing PWR-R

                                                • Wire resistors in aluminium profile combine the high pulse load capacity of conventional resistor materials with optimised thermal conduction and a high degree of protection. Assembly on a surface with good thermal conduction properties improves the heat dissipation additionally and leads to an increased load capacity. The series PWR-R satisfies the requirements of UL508 and is particularly suitable for applications as brake resistor, charging and discharging resistor, or also as heating resistor.

                                                  Applications

                                                  Application as: Circuit resistor, Balance resistors, Grounding resistor, Charging resistor, Brake resistor, Heating resistor

                                                  Application in: Charge filters, Electric machines, Industrial cleaners, Automation plants, Industrial robots, Cranes, Wind power plants, Door actuation

                                                • Wire power resistor in aluminium casing PWR-O

                                                • Wire resistors in aluminium profile combine the high pulse load capacity of conventional resistor materials with optimised thermal conduction

                                                  and a high degree of protection. Assembly on a surface with good thermal conduction properties improves the heat dissipation additionally and leads to an increased load capacity. The series PWR-O satisfies the requirements of UL508 and is particularly suitable for applications as brake resistor, charging and discharging resistor, or also as heating resistor.

                                                  Applications

                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Wire Resistor PWR-F

                                                • Wire resistors in aluminium profile combine the high pulse load capacity of conventional resistor materials with optimised thermal conduction and a high degree of protection. Assembly on a surface with good thermal conduction properties improves the heat dissipation additionally and leads to an increased load capacity. The series PWR-F satisfies the requirements of UL508 and is particularly suitable for applications as brake resistor, charging and discharging resistor, or also as heating resistor.





                                                • Wire power Resistor in stainless steel casing PWR-RFI

                                                • The extremely flat and, at the same time, sturdy design of the wire power resistors in stainless steel casing make this resistor series interesting for all applications with limited installation space and rough environmental surroundings.

                                                  Applications

                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Resistor Assemby PWR-GR

                                                • The type series PWR-GR consists of resistors of the type series PWR-R which are switched variably and connected by means of a terminal box. The basic version is optimised for two or four resistors. Besides that, any combination of resistor values and performances can be adapted.

                                                  Applications

                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Resistor Assembly PWR-GF

                                                • The type series PWR-GF consists of resistors of the type series PWR-R which are switched variably and connected by means of a terminal box. The basic version is optimised for two or four resistors. Besides that, any combination of resistor values and performances can be adapted.

                                                  Applications

                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Draht-Rohrwiderstände bis 100 W PWR-TR 2xx

                                                • Zementierte Draht-Rohrwiderstände sind thermisch optimierte Widerstands-bauformen mit einem sehr breiten Spektrum an Widerstandswerten und Leistungen. Vielfältige Kombinationsmöglichkeiten der elektrischen Eigenschaften, mehrere Anschluss- und Montagevarianten machen diese Widerstände für viele Anwendungen in der Automatisierungstechnik, im Maschinen und Anlagenbau interessant. Optional können diese Widerstände mit einer zusätzlichen Abgriffschelle eingestellt werden (PWR-TRR), oder bei sicherheitsrelevanten Anwendungen mit einer Bügelsicherung ausgerüstet werden (PWR-TRS).



                                                  Besondere Merkmale

                                                  • 4 Rohrgrößen ständig verfügbar alle Bauformen als einstellbare Version lieferbar

                                                  Applikationen

                                                  Einsatz als: Bremswiderstände, Schutzwiderstände, Anlasswiderstände, Erdungswiderstände, Beschaltungswiderstände, Lastwiderstände, Symmetrierwiderstände, Prüfwiderstände, Dämpfungswiderstände, Vorladewiderstände

                                                  Applikationen

                                                  Einsatz in: Antriebssteuerungen, Automatisierungsanlagen, Zentrifugen, Aufzügen, Seil- und Kettenzügen, Wärmepumpen, Werkzeugmaschinen, Pressen und Stanzen, Elektro- und Hybridfahrzeugene, Werkzeugmaschinen, Zentrifugen, Automatisierungsanlagen, Antriebssteuerungen

                                                • Wire and tube resistor up to 1300W PWR-TR 3xx

                                                • Cemented wire tube resistors are thermally optimised resistor designs with a broad spectrum of resistance values and performances. Diverse combination possibilities of the electrical properties, as well as multiple connection and assembly options make these resistors interesting for several applications of automation technology and in mechanical and systems engineering.

                                                  Applications

                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Power Resistor PWR-TR 4xx

                                                • Tube resistors wrapped with oxidised resistor wire can utilise the maximum performance of the resistor material. The insulation effect of the oxide sheath allows for continuous wrapping without distance between the windings. This enables higher pulse performances as well as a broad spectrum of resistance values.


                                                  Applications


                                                  Brake resistor, Discharge resistor, Heating resistor, Circuit resistor

                                                • Wire Resistor PWR-X in stainless steel casing IP20

                                                • The resistor series PWR-X is a ready-to-install combination of tube resistors. Depending on the casing size and the installed tube resistor,

                                                  a performance range from 400 W to 6 KW is covered. The type series are characterised by high flexibility and enable various individual

                                                  solutions. As an option, we offer the matching temperature switch for each performance class.

                                                  Application

                                                  Application as: Circuit resistor, Balance resistors, Grounding resistor, Charging resistor

                                                  Application

                                                  Application in: Charge filters, Electric machines, Industrial cleaners, Automation plants, Industrial robots, Cranes
