  • Offer Profile
  • For decades, the name Jetter AG has stood for highest demands on automation solutions that are used in a wide range of industrial and mobile automation sectors.

    Products and components by Jetter AG stand out thanks to their high degree of system integrity and diversity. Our in-house R&D departments (hardware and software), as well as our production plants in Germany allow us to always act in a quick and flexible manner.
Product Portfolio
  • Controllers

      • JetControl series

      • Controllers of the JetControl series come in all performance classes - from micro-controllers to high-performance, high-end controllers for complex Motion Control (MC) applications.

        Distinctive features common to all JetControl controllers:
        • Seamless integration of axis control into the controller. This makes programming even of complex axis motions very easy.
        • Multitasking OS
        • Commissioning and programming in STX - a high-level language to IEC-61131-3
        • Extensibility and flexibility thanks to a host of interfaces
        • Integrated web server as an option. This option lets you send e-mails and text messages from the application program.
          • JetControl 340

          • JetControl 340 is the optimum entry-level solution for basic automation tasks and offers ease of operation. It is most suitable for applications with no computing-intensive processes involved.

            Features
            • Supports up to 3 servo axes (point-to-point)
            • 1 MB STX program/data memory
            • 2,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • 1 CAN port
            • 1 serial port
            • Programming in STX - a high-level language to IEC-61131-3
            • File system for data storage
            • Easy servicing due to plug terminals and modular design

            Options
            • Number of axes (0, 3)
            • SD memory card slot (-SD)
            • Web and e-mail feature (-W)
            • Modbus TCP (-M)
          • JetControl 350

          • JetControl 350 combines high functionality with optimum performance. Thus, it is well equipped for a variety of applications.

            Features
            • Supports up to 8 servo axes (point-to-point)
            • 2 MB STX program/data memory
            • 30,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • SD memory card slot
            • Modbus TCP
            • 1 CAN port
            • 1 serial port
            • Programming in STX - a high-level language to IEC-61131-3
            • File system for data storage
            • Easy servicing due to plug terminals and modular design

            Options
            • Number of axes (4, 6, 8)
            • Web and e-mail feature (-W)
          • JetControl 365 | 365MC

          • JetControl 365 combines high performance with compact design. It is the optimum solution for CPU demanding and large applications. The JetControl 365 MC lets you enter into Motion Control (MC) functionality. It allows the programming of axis groups and complex path control applications.

            Features
            • Up to 16 point-to-point servo axes via CAN
            • Unlimited number of axes via Ethernet (JetMove 200-ETH)
            • Motion Control/path control of up to 12 axes (JetControl 365MC)
            • 24 MB STX program/data memory
            • 60,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • SD memory card slot
            • Modbus TCP
            • Integrated web and e-mail server

            Options
            • Number of axes (0, 4, 8, 16)
            • Number of axes with MC variant(4, 6, 8, 12)
            • Memory upgrade (totaling 120,000 non-volatile registers) (-R)
          • JetControl 440EXT

          • The JetControl 440EXT controller offers high performance in a compact design. It is the optimum solution for CPU demanding and large applications. In conjunction with JetMove 1000/3000 servo amplifiers, it opens the door to Motion Control functionality. It allows for easy programming of axis groups and complex path control applications. Thanks to its flexible option model, the range of functions can be easily extended - even at a later date.

            Features
            • Supports up to 24 servo axes
            • Up to 256 local I/Os
            • (allows for expansion to > 65,000 distributed I/Os)
            • 32 MB STX program/data memory
            • 480,000 bytes of non-volatile memory
            • 1x Ethernet port with integrated switch
            • EtherCAT® (option)
            • 2x CANopen®
            • 1 serial interface
            • 1x USB 2.0 (for storage media)
            • Web server (option)
            • E-mail client (option)
            • Modbus TCP (option)
            • OPC UA server (option)
            • MQTT (option)
            • Programming in STX - a high-level language to IEC-61131-3
            • Multitasking
            • File handling
            • String processing
          • JetControl 940MC | 945MC

          • The high-performance controller JetControl 940MC is most suitable for applications requiring highest computing power and comprehensive motion control functions.

            Features
            • Motion Control/path control of up to 64 axes
            • 32 MB STX program/data memory 120,000 non-volatile registers
            • 3 Ethernet ports
            • Modbus TCP
            • Integrated web and e-mail server
            • 4 USB ports
            • Programming in STX - a high-level language to IEC-61131-3
            Options
            • Number of axes (-16, -24, not specified = 64)
            • 3x PCI (-E03-3); only for JC-940MC
          • JetControl 970MC | 975MC

          • The high-performance controller JetControl 970MC | 975MC is most suitable for applications requiring highest computing power, comprehensive motion control and PC functions.

            Control and visualization combined in one device reduce the number of components in the control cabinet. Hypervisor technology keeps the applied operating systems strictly separated. The NVRAM + FLASH memory for non-volatile data is a standard feature. This means there is no extra cost for additional flash cards.

            Features
            • Intel® i5 processor, dual-core
            • Windows + hard realtime combined in a single piece of hardware
            • Highest stability thanks to Hypervisor technology
            • EtherCAT® (JetControl 975MC) 2x PCIexpress (JC-970 only)
            • USB
            • 2x Ethernet ports
            • SD card slot
            • DisplayPort™
            • AutoCopy function
        • JetControl Mobile series

        • Controllers of the JetControl Mobile series can best meet the special demands made on mobile automation. Their pre-eminent trait is the combination of ultimate ruggedness, high and scalable CPU performance and the ability to implement individual customer requirements. The controllers can directly be built into the vehicle without a control cabinet being needed. This is space-saving and therefore allows for flexible installation.
            • JetControlMobile 501

            • The compact master controller JCM-501 forms the heart of compact, distributed architectures.

              With 2 CAN interfaces, RS232, USB and Ethernet port, as well as the proven, powerful 32-bit CPU it can be used in system solutions of simple to medium complexity.

              An integrated real-time clock completes the range of functions.

              Product features
              • Controller 32 bit/500 MHz Compact design High connectivity
            • JetControlMobile 511

            • The semi-modular compact controller JetControlMobile 511 is based on the modular JCM-521 series. Due to its vast I/O capacity featuring high-performance H-bridges, PWM outputs, flexibly applicable inputs and high total ampacity, even its basic configuration is already sufficient for numerous applications. Besides hydraulic actuators, it can even directly control electric motors. Extensibility by two MX modules allows for easily adjusting to a great variety of functions and applications.

              Besides standard ports and interfaces, the JCM-511 is equipped with inputs apt for NAMUR, as well as with a LIN port. This way, it can be integrated into almost any systems architecture.

              The high-level language STX to IEC 61131-3 lets you realize virtually any control task. Programming in C/C++ is possible, too.

              Features
              • 32-bit controller, 500 MHz Programming to IEC 61131-3 STX or in C/C++ Partially modular I/O configuration for high flexibility CAN, USB, LIN and RS232 port for high connectivity Compact design
            • JetControlMobile 521

            • The JCM-521 controllers are fully modular. They have been designed for control systems exacting requirements on flexibility and connectivity.

              The controllers consist of a main board and of MX modules which are expansions providing dissimilar features. The main board is equipped with a powerful CPU and FPGA. Depending on the desired configuration, either 6 or 15 MX modules are there to hold any combination of expansions. If all possibilities are made use of, up to 120 I/O connections can be provided. This way, I/O allocation can precisely be adjusted to any application object.

              An optional diagnostics display with controls features production data display, diagnostics and configuration on the spot without additional supporting devices such as PC or testing devices still being needed.

              Features
              • 32-bit controller, 500 MHz
              • Programming to IEC 61131-3 STX or in C/C++
              • Modular I/O configuration for high flexibility
              • CAN, USB, LIN, and RS232 port for high connectivity.
              • Built-in controls with graphic display
            • JetControlMobile 529

            • In JCM-529, circuit parts for modular expansion of the JCM-521 series have been translated into a concept comprising fixed I/O configuration. This makes it a cost-effective solution keeping up the performance features of the JCM-521 series. Layout-reuse technology enables adjustments to be made in PCB assembly at low cost. 103 I/O connections are available in the fully equipped configuration.

              An optional diagnostics display with controls features production data display, diagnostics and configuration on the spot without additional supporting devices such as PC or testing devices still being needed.

              Features
              • 32-bit controller, 500 MHz
              • Programming to IEC 61131-3 STX or in C/C++
              • Fixed I/O configuration featuring modularizing varieties
              • CAN, LIN, Ethernet and RS232 port for high connectivity
              • Built-in controls with graphic display
            • JetControlMobile 5xx MX modules

            • MX modules are configurable multi-purpose add-on modules for the JCM-511 and -521.

              Available configurations
              • Multi-purpose 8-channel input module with analog-digital mode, current measuring and frequency measuring mode
              • 8-channel output module
              • 4-channel H-bridge module
              • 8-channel output module with precision current measuring mode
              • 2-channel weighing module with tilt sensor
            • JetControlMobile 630

            • The multi-monitor controller JCM-630 combines outstanding video features with high-performance HMI and PLC disciplines in one system.

              A powerful 32-bit CPU with 800 MHz clock rate forms the heart of the automation functions. Four CAN interfaces, Gbit Ethernet connectivity, USB, LIN, and RS232 offer high connectivity for complex architectures.

              The visualization takes place on 2 displays via LVDS interfaces with one connector per display being sufficient. A host of supported display formats and configurations allow a high flexibility in the arrangement of the screens.

              6 camera images from 8 camera channels can be processed simultaneously in one FPGA with minimal latency. The images can be freely scaled, cut, positioned or superimposed with graphic and text elements. This way, operating concepts exceeding the level of integration into modern middle-class cars can be physically established in special-purpose vehicles with moderate application expense.

              The IEC-61131-3-compliant programming language STX, a plug-in for programming in C, and scalable vector graphics support by JetViewSoft offer a highly efficient workflow for control and visualization. The JCM-630 is available with ISOBUS stack.

              Features
              • Powerful PLC with high connectivity
              • Excellent HMI features on two displays
              • Free positioning, size adjustment and scaling of 6 camera images
              • Integrated programming environment to IEC-61131-3 JetSym and JetViewSoft
              • Plug-in for programming in C or 3rd party software
              • Can be updated via USB flash drive
          • Safety Controllers

          • Controllers of the JetSafeControl series combine all requirements of your machinery as to productivity and cost effectiveness with an integrated safety concept.

            Typical safety functions can very easily be implemented by using existing features. In doing so, you have a comprehensive function library at your disposal, especially for safe drive monitoring. The modular combination of functions via logic blocks lets you set up safety functionalities tailored to your needs.
                • JSX1-DIO22

                • The JSX1-DIO22 expansion module features 10 safe IOs, 12 safe inputs, and 2 signaling outputs. The IOs can be configured either as inputs, or outputs.

                  Features
                  • 10 safe IOs which can be configured either as inputs or outputs
                  • 12 safe inputs. 8 of them support OSSD
                  • 2 signaling outputs
                  • Monitoring for shorts between contacts
                  • External contactors allow for contact multiplication and increasing contact ratings. Combination with internal monitoring is also possible
                  • Firmware with integrated comprehensive diagnostic capabilities
            • Expansion Modules

                • JX3 modules

                    • JX3-AI4

                    • The JX3-AI4 module is an expansion module for connecting analog sensors.

                      Features
                      • 4 analog inputs
                      • Selectable input signal per channel
                      • Resolution: 16 bits Averaging
                      • User-defined scaling
                      • Monitoring of upper/lower limit
                      • Oscilloscope function
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Galvanic isolation (-EI)
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-AO4

                    • The JX3-AO4 module is an expansion module for connecting analog actuators.

                      Features
                      • 4 analog outputs
                      • Selectable output signal per channel
                      • Resolution: 16 bits
                      • User-defined scaling
                      • Monitoring of limit values
                      • Trailing indicator
                      • Capping
                      • Forcing
                      • Oscilloscope function
                      • Table mode
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-BN-CAN

                    • The CAN bus node JX3-BN-CAN is for setting up remote I/O stations. The module is equipped with two bus ports (BUS-IN and BUS-OUT) to connect up standard system bus cables by Jetter AG.

                      Features
                      • Automatic addressing
                      • Automatic baud rate setting
                      • Automatic bus termination
                      • Up to 16 JX3 expansion modules can be connected up (corresponding to 256 I/O channels)
                      • Light-emitting diodes for monitoring communication and power supply
                    • JX3-BN-EC

                    • The EtherCAT® bus node JX3-BN-EC is a gateway between an EtherCAT® master and JX3-I/O modules by Jetter.

                      JX3-BN-EC modules are used for the purpose of setting up distributed I/O stations. They enable synchronous communication between controller and distributed JX3 peripheral modules via EtherCAT®.

                      Features
                      #
                      • Automatic addressing
                      • CoE (CAN application protocol over EtherCAT®) is supported
                      • Compliant with EtherCAT® Modular Device Profile
                      • Synchronous communication via Distributed Clocks (DC Sync)
                      • Up to 32 JX3 expansion modules can be connected (corresponding to 512 I/O channels)
                      • LEDs indicate the state of communication and supply voltage.
                    • JX3-BN-ETH

                    • The Ethernet bus node JX3-BN-ETH is for setting up remote I/O stations. This module allows synchronous communication between controllers and the remote I/O station via standard Ethernet.

                      Features
                      • Up to 16 JX3 expansion modules can be connected up (corresponding to 256 I/O channels)
                      • Light-emitting diodes for monitoring communication and power supply
                      • Synchronous communication via Ethernet
                    • JX3-COM

                    • The gateway module JX3-COM allows for communication with different fieldbus systems. The module is availabIe for Ethernet IP and PROFINET®.

                      Features
                      • Implicit data communication
                      • Explicit data communication
                      • Light-emitting diodes for monitoring communication and power supply

                      Models
                      • Ethernet/IP adapter: JX3-COM-EIPA
                      • PROFINET® device: JX3-COM-PND
                    • JX3-DI16

                    • The JX3-DI16 module is an expansion module for connecting digital sensors.

                      Features
                      • 16 digital inputs
                      • Digital input filters
                      • Pulse stretching
                      • Counting feature
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-CNT

                    • The JX3-CNT is a versatile counter module and supports the following modes: single-channel counter, dual-channel counter, and Synchronous Serial Interface (SSI).

                      Features
                      • Trailing indicator
                      • User-defined scaling
                      • Oscilloscope function
                      • Forcing of count values
                      • Monitoring of limit values
                      • Frequency measurement
                      • Period measurement
                      • Gating measurement
                      • 16-fold multi-strobe function
                      • Gate function
                      • Digital filters
                      • Reference
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-DMS2

                    • The strain gage module JX3-DMS2 is an expansion module for measuring strain, force and pressure. This expansion module supports all strain gages working in accordance with the principle “Strain-resistance effect of electrical conductors”. Strain gages are connected in 4-wire technology.

                      Features
                      • 2 inputs
                      • Adjustable measuring accuracy
                      • Trailing indicator
                      • User-defined scaling
                      • Oscilloscope function
                      • Forcing function for measured values
                      • Monitoring of limit values
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-DO16

                    • The JX3-DO16 module is an expansion module for connecting digital actuators.

                      Features
                      • Automatic addressing
                      • 16 digital outputs
                      • Pulse-width modulation (PWM)
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-DIO16

                    • The JX3-DIO16 is an expansion module for connecting of digital sensors and actuators.

                      Features
                      • 8 digital inputs and 8 digital outputs
                      • Outputs can also be used as inputs
                      • Digital input filters
                      • Pulse stretching
                      • Pulse-width modulation (PWM)
                      • Counting feature
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-MIX1

                    • The multi-purpose expansion module JX3-MIX1 provides you with a combination of commonly required I/O functions. This module is ideal for cost-sensitive applications.

                      Features
                      • Counter function
                      • Stepper motor controller
                      • 3 analog inputs
                      • 1 analog output
                      • 8 digital multi-purpose I/Os
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-PS1

                    • The JX3-PS1 module provides power supply for JX3 peripheral modules.

                      Features
                      • Power supply for up to eight JX3 expansion modules
                      • Light-emitting diodes for monitoring the power supply
                    • JX3-THI2-TC

                    • The expansion module JX3-THI2-TC is equipped with two inputs for thermocouple-type temperature sensors. The following thermocouple types can be connected: J, K, B, E, N, R, S, T.

                      Features
                      • Temperature range to DIN 60584-1
                      • Resolution: 0.01 ℃
                      • Integrated terminal temperature compensation
                      • Up to 64-fold averaging
                      • Monitoring of limit values
                      • Trailing indicator
                      • Oscilloscope function
                      • Forcing
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals
                      Options
                      • Galvanic isolation (-EI)
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                    • JX3-THI2-RTD

                    • The expansion module JX3-THI2-RTD is equipped with two inputs for analog temperature sensors of the type Pt100 or Pt1000. The temperature sensors can be connected in 2-, 3- or 4-wire technology.

                      Features
                      • Temperature range: -50 ... +850 °C
                      • Resolution: 0.01 °C
                      • Up to 64-fold averaging
                      • Monitoring of limit values
                      • Trailing indicator
                      • Oscilloscope function
                      • Potentiometer mode
                      • Forcing
                      • Light-emitting diodes for monitoring communication and power supply
                      • Plug-in terminals

                      Options
                      • Galvanic isolation (-EI)
                      • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                  • JXM modules

                      • JXM-IO-E02

                      • The large number of individually configurable I/O connections, the high total current as well as the rugged and compact design make the JXM-IO-E02 a multi-purpose CAN remote node.

                        The supply voltage of the inputs and outputs is divided into Standard Feed and Protected Feed, and it allows for independent deactivation of inputs and outputs in safety applications.

                        The CAN ID of the I/O node can be defined via external connection of digital inputs. This way, up to nine nodes can be addressed within one system without further configuration measures to be taken.

                        Features
                        • Flexible I/O configuration
                        • The CAN addresses can be configured via wiring harness
                        • Compact and rugged enclosure
                        • High degree of protection IP66/IP68
                      • JXM-IO-E09

                      • The expansion module JXM-IO-E09 was designed as a high-current CAN node. It is for controlling power consumers such as spotlights or signal encoders in CANopen® networks.

                        Due to its small size, the module can be placed very flexibly very close to the consumer.

                        Features
                        • Rugged and compact enclosure
                        • High degree of protection IP67
                        • High total current
                        • CAN port
                      • JXM-IO-E11

                      • The expansion module JXM-IO-E11 has been designed for signal processing in the dashboard or in the driver's cabin. 20 digital switching signals, 3 analog joystick axes and a 4-way switch can be combined to be transmitted to the controller as a CAN message. Up to 24 LEDs can be controlled via CAN in parallel. Out of these, 20 LEDs can be dimmed individually. This way, a balanced background lighting within the HMI can be set, even if different light sources are used.

                        Features
                        • Grouping of discrete input and output signals
                        • CANopen® port
                        • 5 V power supply, built in
                        • Compact design
                      • JXM-IO-E30

                      • The expansion module JXM-IO-E30 is the universal remote building block for mobile machinery. Thanks to its well-adjusted I/O configuration, it can take on almost any remote task and this way significantly reduce wiring expenses. The reference output lets you use standard sensors and carry out pre-processing applications.

                        Communication with the JXM-IO-E30 takes place via CANopen®. This allows for integration into conventional CAN networks used in mobile machinery.

                        The potted - and thus rugged - enclosure is applicable in any situation even under harsh environmental conditions.

                        Features
                        • 12 inputs and 14 diagnostics-capable outputs - including high current paths and PWM with current control
                        • High switching capacity thanks to parallel use of outputs and high continuous total current
                        • CAN ID addressing via tri-state inputs allows up to nine nodes in one network without software configuration, and thus supports the common part strategy
                        • Three short-circuit-proof sensor supplies allow "mission critical" sensor networks
                        • Rugged potted housing
                      • JXM-HMI

                      • The JXM-HMI is a universal HMI with three robust push encoders. It is therefore ideally suited for a wide range of dosing and control applications in self-propelled machines.

                        Thanks to its compact design, it can be flexibly mounted in the driver's cab either individually or, for example, in combination with a JetViewMobile 104. CANopen® ensures compatibility with the overall vehicle architecture and communication with the rest of the electronics. The comprehensive functions of the push encoders leave nothing to be desired in terms of adaptation to the application: Bidirectional rotation and a push button enable, for example, precise dosing of products to be applied. Instead of the push encoders, customer-specific adaptation with illuminated membrane keys (up to 16 keys) is possible.

                        The integrated LEDs ensure that the functions of the individual push encoders are clearly visible at all times thanks to the respective symbols. The LEDs can also be dimmed for individual adaptation to the periphery or lighting conditions at day and night. This ensures excellent user-friendliness.

                        Features
                        • 1 CANopen® interface for seamless integration into the vehicle architecture
                        • 3 push encoders with bidirectional rotary function and push button for precise dosing and control tasks
                        • Dimmable LED backlight for adaptation to different daylight and lighting conditions
                        • Highest application flexibility due to compact design: Can be installed individually or in combination with a JVM-104 HMI
                    • HMIs

                        • JetView Series

                            • JetView 1004

                            • Besides its excellent performance, the HMI JetView 1004 impresses by its compact design and front panel sealing (up to IP66). This device can be easily integrated into existing networks thanks to its two Ethernet ports with integrated switch.

                              Features
                              • 4.3" TFT touchscreen
                              • 256 MB memory
                              • 2x Ethernet ports (with integrated switch)
                              • MMC or SD memory card slot
                              • IP66 (front panel)
                            • JetView 1005

                            • The HMIs JetView 1005 offer a universal widescreen display with Projected Capacitive Touchscreen (PCAP). The HMI has two Ethernet ports with switch functionality and is ideal for integration into existing networks. It comes with a scratch-proof and dirt-repellent real glass surface.

                              Features
                              • Seamless glass front panel
                              • Multi-touch
                              • WinCE operating system
                              • 2 Ethernet ports
                              • USB
                              • SD Card
                            • JetView 1007

                            • The HMIs JetView 1007 offer a universal widescreen display with Projected Capacitive Touchscreen (PCAP). The HMI has two Ethernet ports with switch functionality and is ideal for integration into existing networks. It comes with a scratch-proof and dirt-repellent real glass surface.

                              Features
                              • Seamless glass front panel
                              • Multi-touch
                              • WinCE operating system
                              • 2 Ethernet ports
                              • USB
                              • SD Card
                            • JetView 1010

                            • The JetView 1010 has a universal widescreen display with Projected Capacitive Touchscreen (PCAP). The HMI has two Ethernet ports with switch functionality and is ideal for integration into existing networks. The seamless real glass interface is scratch- and dirt-resistant.

                              Features
                              • Seamless glass front panel
                              • Widescreen (16:10)
                              • Multi-touch
                              • WinCE operating system
                              • 2 Ethernet ports
                              • USB
                              • SD Card
                          • LCDs

                              • LCD 16

                              • The HMI LCD16 is a modular device based on a 4-line LCD screen. It can be upgraded by the numerical keypad NUM25 with 5 additional function keys and electronic handwheel module HR1. This way, actual and setpoint values can be displayed and conveniently be input via keyboard and axes can easily be moved.

                                The function keys are user-programmable and can be used for calling the menu and/or for triggering control functions. The 5 keys (with LED) on the basic module, as well as on the handwheel module can be labeled using removable marker strips. Double assignment of keys and, in particular, of function keys is achieved by pressing the SHIFT key.

                                Other function keys are for directly accessing registers and flags, as well as inputs and outputs in monitor mode which can be disabled. This way, the user is given the possibility to test the application without application program

                                Distinctive Features:
                                • Modular control panel
                                • Alphanumeric Liquid Crystal Display
                                • 4 lines of 20 characters each
                                • 5 Function Keys
                                • IP65 (front panel)
                              • LCD 23

                              • The HMI LCD 23 has been designed for displaying simple operating and error messages. Through 3 user-programmable keys various display modes can be selected. Function keys can also be used to select and change parameters, for example:


                                1.- Selecting a parameter using arrow keys
                                2.- Confirming the selected parameter by pressing the Enter key
                                3.- Changing the parameter using arrow keys
                                4.- Confirming the new value by pressing the Enter key

                                Distinctive Features:
                                • Alphanumeric Liquid Crystal Display, backlit
                                • 2 lines of 24 characters each
                                • 3 Short-stroke keys
                                • IP65 (front panel)
                              • LCD 27

                              • The HMI LCD 27 has been designed for displaying simple operating and error messages. It features 11 user-programmable keys. 5 of them can be used for various display modes. The 4 arrow keys can also be used for operating and controlling the plant.

                                Distinctive Features
                                • Alphanumeric Liquid Crystal Display, backlit
                                • 2 lines of 24 characters each
                                • 5 function keys with LED
                                • 4 arrow keys
                                • IP65 (front panel)
                            • JetViewMobile series

                                • JetViewMobile 104

                                • With its compact design and rugged enclosure the JVM-104 is an ideal HMI for any application of mobile machinery. It is equipped with a powerful controller which can be expanded by additional I/O connections, as well as by one Ethernet and one USB port. This device saves you an extra controller for many applications. The HMI is operated via eight backlit keys, and a digipot with pushbutton. The built-in light sensor perfectly adapts the illumination of the display to the brightness of the surroundings.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • Flexible expandability
                                  • High connectivity
                                  • Customizable
                                  • Available either as a flush mount or as surface mount model
                                • JetViewMobile 407B

                                • With its elegant and high-quality design, the JVM-407B HMI is a standout product and can be supplied both as flush mount or surface mount model. To the left and right of the 7" display are 10 LEDs with typical automotive warning and indicator lights which can be directly controlled independently of the electronics. This allows the JVM-407B to be used as an instrument cluster. The integrated controller of the HMI is equipped with multi-purpose interfaces and can therefore be used as a powerful master controller for medium-size systems. A video input allows for integrating a rear view camera. The HMI is operated via four high-value backlit keys, as well as a push encoder, i.e. a digipot used as pushbutton. The acoustic signaling device produces an alarm loud enough to be heard even in noisy surroundings. A USB port at the front side allows for simple data interchange in the field.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • 3 CAN ports, Ethernet, SD card and front-side USB port
                                  • Video input
                                  • Integrated automotive LEDs
                                  • Elegant and high-value design
                                  • Available either as a flush mount or as surface mount model
                                • JetViewMobile 507B

                                • The HMI JVM-507B is equipped with a 7" display and 12 backlit keys with symbols printed to customer's wishes. The keys have been arranged right and left of the display. As an option, the HMI can be supplied with a resistive touch screen. This way, highly flexible and comprehensive operating concepts can be implemented. The HMI has been designed for installation in a double DIN slot in the dashboard. The integrated controller of the HMI is equipped with multi-purpose interfaces and can therefore be used as a powerful master controller for medium-size systems. Four video inputs allow for establishing high-level monitor applications. A light sensor allows for automatically adjusting to display brightness and key backlighting. The acoustic signaling device produces an alarm loud enough to be heard even in noisy surroundings.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • Keys to be labeled
                                  • 2 CAN ports, Ethernet, microSD card and USB port
                                  • 4 video inputs
                                  • Rugged aluminum front panel
                                • JetViewMobile MT101

                                • The outstanding feature of the new monitor generation JVM-Mxxx is its brilliant displays of appealing design which are also readable in bright sunlight.

                                  Coming as mere monitors of 4.3 to 10.1", the devices are low-size enough to be installed even in small spaces.

                                  The corresponding high-performance ECU JCM-630 does not only establish all connections with the mobile machine, but it also provides two monitors with operating parameters by single-cable technology.

                                  Thanks to its multi-kernel processors, its four CAN, LIN, Gbit Ethernet connections, and its eight camera inputs, the JCM-630 is fit for any kind of today's and tomorrow's operating philosophy.

                                  Features
                                  • Brilliant displays readable in bright sunlight
                                  • Slim, modern design
                                  • Single-cable connection to JCM-630
                                  • PCAP can be integrated
                                  • Mounting: VESA/RAM, flush mounting
                                • JetViewMobile M043

                                • The outstanding feature of the new monitor generation JVM-Mxxx is its brilliant displays of appealing design which are also readable in bright sunlight.

                                  Coming as mere monitors of 4.3 to 10.1", the devices are low-size enough to be installed even in small spaces.

                                  The corresponding high-performance ECU JCM-630 does not only establish all connections with the mobile machine, but it also provides two monitors with operating parameters by single-cable technology.

                                  Thanks to its multi-kernel processors, its four CAN, LIN, Gbit Ethernet connections, and its eight camera inputs, the JCM-630 is fit for any kind of today's and tomorrow's operating philosophy.

                                  Features
                                  • Brilliant displays readable in bright sunlight
                                  • Slim, modern design
                                  • Single-cable connection to JCM-630
                                  • PCAP can be integrated
                                  • Mounting: VESA/RAM, flush mounting
                              • Classic HMIs

                                  • BT 15

                                  • With the BT15, we offer an operator panel for complete machine operator control. Thanks to tight front panel installation, the BT15 achieves a degree of protection of IP65. The marker strips are inserted from the sealed inner side of the device which ensures that this degree of protection is maintained. Extensive tests have shown that the BT15 is both reliable and suitable for use in industrial applications. Mechanical stability, EMC, temperature and climatic tests ensure that the high level of quality of the operator panels is maintained.

                                    The monochrome LCD display features CFL background lighting offering high readability from various angles of view. A resolution of 240 x 128 pixels allows for a spacious display of texts and graphics. This HMI is also available as special design for mobile applications. Here, a monochrome, transflective LCD with LED background lighting is used. This ensures good readability even in direct sunlight.
                                    Exchangeable interface modules allow ease of adaptation to various interface standards and various bus systems. The protocol drivers can be loaded through the programming software. Therefore, it is not necessary to order protocol-specific models of the BT15.

                                    Features
                                    • Full-graphics monochrome display, backlit
                                    • Extended temperature range: -20 ... 60 °C
                                    • 26 user-programmable function keys with LEDs
                                    • Numeric keypad
                                    • Programmable Application Interface (PAI)
                                    • Integrated PG-MUX
                                    • Integrated language selection
                                    • Error diagnostics with 4 priorities
                                    • Flash memory with power failure protection
                                    • Password protection
                                    • Optional recipe memory
                                    • Optional real-time clock
                                  • BT 20

                                  • With the BT20, we offer an operator panel for complete machine operator control. Thanks to tight front panel installation, the BT20 achieves a degree of protection of IP65. The marker strips are inserted from the sealed inner side of the device which ensures that this degree of protection is maintained. Extensive tests have shown that the BT20 is both reliable and suitable for use in industrial applications.

                                    It supports the following communication protocols:

                                    3964 R, ABB, AB-DF1, AB-DH485, AEG KS functions, AEG-Modbus, Bosch BUEP19, Bosch BUEP19E, Crouzet, Jetter, Mitsubishi, Modbus, Moeller Sucom A, Omron, SEW-Eurodrive, Siemens L1, Siemens MPI, Siemens PPI, (additional protocols on request)

                                    Supported bus systems are: Interbus-S, Profibus-DP, CAN, Modbus+

                                    Features
                                    • Full-graphics monochrome display, backlit
                                    • Extended temperature range: -20 ... 60 °C
                                    • 8 user-programmable function keys (as option additional 24, or 48 function keys with LED)
                                    • Numeric keypad
                                    • Integrated language selection
                                    • Error diagnostics with 4 priorities
                                    • Flash memory with power failure protection
                                    • Portable project and/or recipe memory
                                  • BT 1000

                                  • With the BT1000, we offer an operator panel for complete machine operator control. Seven pre-cut openings for additional hardware pushbuttons and an area for the emergency stop button avoid the trouble of subsequent front panel machining. The BT1000 can be used in harsh industrial environments without causing EMC problems due to its aluminum front panel and zinc-plated steel plate housing. Thanks to tight front panel installation, the BT1000 achieves a degree of protection of IP65. The marker strips are inserted from the sealed inner side of the device which ensures that this degree of protection is maintained. Extensive tests have shown that the BT1000 is both reliable and suitable for use in industrial applications. Mechanical stability, EMC, temperature and climatic tests ensure that the high level of quality of the operator panels is maintained.

                                    The monochrome VGA display features CFL background lighting offering high readability from various angles of view. A resolution of 640 x 480 pixels allows for a spacious display of texts and graphics.

                                    Exchangeable interface modules allow ease of adaptation to various interface standards and various bus systems. The protocol drivers can be loaded through the programming software. Therefore, it is not necessary to order protocol-specific models of the BT1000.

                                    Features
                                    • Full-graphics monochrome display, backlit
                                    • 22 user-programmable function keys with dual-color LEDs
                                    • Numeric keypad
                                    • Programmable Application Interface (PAI)
                                    • Integrated PG-MUX
                                    • Integrated language selection
                                    • Error diagnostics with 4 priorities
                                    • Flash memory with power failure protection
                                    • Recipe memory
                                    • Realtime Clock (RTC)
                                    • Password protection
                                  • BTM 07

                                  • With its 10.4" display and elegant design, the BTM07 HMI is a standout product. Its high resolution makes it ideal for displaying videos and guarantees comfortable working conditions. Video signals can be streamed in via the video interface.

                                    The integrated control interpreter allows the HMI to be used also as a controller for small to medium-sized applications.

                                    The display is designed to operate perfectly in all light conditions, with large, backlit keys and a light sensor that automatically adapts the illumination of the display to the brightness of the surroundings.

                                    The BTM07 HMI has been specially designed for use in commercial vehicles and mobile machines. It complies with the applicable protection requirements as to ambient temperature, shock, vibration, electromagnetic compatibility and tightness. Depending on the design, the front can be tightened to IP65.

                                    Features
                                    • 10.4" TFT display
                                    • 3 CAN interfaces
                                    • Ethernet connection
                                    • RS485 connection (protocol SAE J1708)
                                    • Video input
                                  • BTM 09

                                  • The compact BTM09 HMI is excellent for outdoor use. Its fully-enclosed housing is equipped with a pressure compensation membrane, providing all-round IP65 protection.

                                    The integrated control interpreter for Jetter application programs (STX) also allows the HMI to be used as a controller for small to medium-scale applications.

                                    The video input gives you the option to connect a camera (e.g., rear-view).

                                    The display is designed to operate perfectly in all light conditions, with backlit keys and a light sensor that automatically adapts the illumination of the display to the brightness of the surroundings.

                                    Features
                                    • 5.6" TFT display
                                    • CAN interface
                                    • Video input
                                • Industrial PCs

                                    • JI-PCs

                                        • JI-PC 602

                                        • The industrial PC JI-PC 602 combines compact design with optimum performance. It can reliably handle any automation task thanks to a large number of interfaces and scalable CPU performance. Expansion slots enable the connection of standard fieldbuses. The JI-PC 602 can be operated directly in the control cabinet thanks to its 24 V power supply.

                                          Features
                                          • Compact
                                          • PCIe
                                          • 24 V power supply
                                          • Fanless (Intel® Core™ i5)
                                        • JI-PC 603

                                        • The industrial PC JI-PC 603 combines compact design with optimum performance. It can reliably handle any automation task thanks to a large number of interfaces and scalable CPU performance. Expansion slots enable the connection of standard fieldbuses. The JI-PC 603 can be operated directly in the control cabinet thanks to its 24 V power supply.

                                          Features
                                          • Compact
                                          • PCIe
                                          • 24 V power supply
                                          • Fanless (Intel® Core™ i5)
                                      • Flat panel PCs

                                          • JI-FPC1012

                                          • The flat panel PCs JI-FPC1012/1015/1022 are industrial PCs with widescreen display and Projected Capacitive Touchscreen (PCAP). Their screen sizes of 12.1" ... 21.5" offer sufficient room for monitoring and operating mid-sized plants. With MultiCore CPUs of the ATOM class, these HMIs are able to process several applications simultaneously. Thanks to their many interfaces they can be perfectly adapted to suit individual requirements. The seamless real glass surface is scratch-resistant and dirt-repellent.

                                            Features
                                            • Seamless real glass front panel
                                            • Widescreen (16:9)
                                            • Multi-touch
                                            • PCAP
                                            • DisplayPort™ for an additional monitor
                                            • Windows10 IoT
                                            • JetViewSoft visualization
                                            • QuadCore processor
                                            • 2x Ethernet ports
                                            • USB 2.0 +3.0
                                            • SD card slot
                                            • SSD
                                            • RS-232
                                            • Fanless


                                            Options
                                            • WLAN
                                            • RFID reader
                                            • Additional Ethernet port
                                            • Additional RS-xxx interface
                                          • JI-FPC1015

                                          • The flat panel PCs JI-FPC1012/1015/1022 are industrial PCs with widescreen display and Projected Capacitive Touchscreen (PCAP). Their screen sizes of 12.1" ... 21.5" offer sufficient room for monitoring and operating mid-sized plants. With MultiCore CPUs of the ATOM class, these HMIs are able to process several applications simultaneously. Thanks to their many interfaces they can be perfectly adapted to suit individual requirements. The seamless real glass surface is scratch-resistant and dirt-repellent.

                                            Features
                                            • Seamless real glass front panel
                                            • Widescreen (16:9)
                                            • Multi-touch
                                            • PCAP
                                            • DisplayPort™ for an additional monitor
                                            • Windows10 IoT
                                            • JetViewSoft visualization
                                            • QuadCore processor
                                            • 2x Ethernet ports
                                            • USB 2.0 +3.0
                                            • SD card slot
                                            • SSD
                                            • RS-232
                                            • Fanless


                                            Options
                                            • WLAN
                                            • RFID reader
                                            • Additional Ethernet port
                                            • Additional RS-xxx interface
                                          • JI-FPC1022

                                          • The flat panel PCs JI-FPC1012/1015/1022 are industrial PCs with widescreen display and Projected Capacitive Touchscreen (PCAP). Their screen sizes of 12.1" ... 21.5" offer sufficient room for monitoring and operating mid-sized plants. With MultiCore CPUs of the ATOM class, these HMIs are able to process several applications simultaneously. Thanks to their many interfaces they can be perfectly adapted to suit individual requirements. The seamless real glass surface is scratch-resistant and dirt-repellent.

                                            Features
                                            • Seamless real glass front panel
                                            • Widescreen (16:9)
                                            • Multi-touch
                                            • PCAP
                                            • DisplayPort™ for an additional monitor
                                            • Windows10 IoT
                                            • JetViewSoft visualization
                                            • QuadCore processor
                                            • 2x Ethernet ports
                                            • USB 2.0 +3.0
                                            • SD card slot
                                            • SSD
                                            • RS-232
                                            • Fanless


                                            Options
                                            • WLAN
                                            • RFID reader
                                            • Additional
                                            • Ethernet port
                                            • Additional RS-xxx interface
                                        • Motion Systems

                                            • JetMove Series

                                                • JetMove 1xx

                                                    • JetMove 105

                                                    • The JetMove 105 has especially been designed for the voltage range from DC 12 to 48 V (up to 384 W). This servo amplifier supports all major motor types and offers space-saving installation due to its compact design.

                                                      Features
                                                      • DC 12 … 48 V
                                                      • 5 A
                                                      • Supported motor types:
                                                      - Synchronous and asynchronous motors
                                                      - 2-phase stepper motors
                                                      - Direct drives
                                                      - DC and BDC motors
                                                      - Linear motors
                                                      • Great number of integrated technological and special motion functions:
                                                      - Electronic gearbox
                                                      - Table function/cam disc
                                                      - Dynamically changeable tables
                                                      - Synchronizing of position and velocity
                                                      - Print-mark correction
                                                      - Winding function
                                                      - Flying saw
                                                      - Cross cutter
                                                      - Torque/force control
                                                    • JetMove 108

                                                    • The JetMove 108 has especially been designed for the voltage range from DC 12 to 48 V (up to 384 W). This servo amplifier supports all major motor types and offers space-saving installation due to its compact design.

                                                      Features
                                                      • DC 12 … 48 V
                                                      • 8 A
                                                      • Supported motor types:
                                                      - Synchronous and asynchronous motors
                                                      - 2-phase stepper motors
                                                      - Direct drives
                                                      - DC and BDC motors
                                                      - Linear Motors

                                                      • Great number of integrated technological and special motion functions:

                                                      - Electronic gearbox
                                                      - Table function/cam disc
                                                      - Dynamically changeable tables
                                                      - Synchronizing of position and velocity
                                                      - Print-mark correction
                                                      - Winding function
                                                      - Flying saw
                                                      - Cross cutter
                                                      - Torque/force control
                                                  • JetMove 2xx

                                                      • JM-D203

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                      • JM-203B

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                      • JM-206B

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                      • JM-204

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                      • JM-208

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                      • JM-215B

                                                      • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                        Features
                                                        • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                        • 3 … 25 A
                                                        • Supported motor types:
                                                        - Synchronous and asynchronous motors
                                                        - 3-phase stepper motors
                                                        - Direct drives
                                                        - Linear motors

                                                        Options
                                                        • Safe Standstill (STO = Safe Torque Off) (S1)
                                                        • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                        • Incremental encoder emulation (EMU)
                                                        • Ethernet port (ETH)
                                                        • Integrated controller (JC-310)
                                                    • JetMove 1xxx

                                                        • JetMove 1005

                                                        • The JetMoves JM-1005 and JM-1008 are servo amplifiers for controlling motors from DC 24 ... 48 V up to 384 Watts with or without encoder in connection with Jetter controllers via EtherCAT® or CANopen®.

                                                          Features
                                                          • Compact design
                                                          • High positioning accuracy and quality of control
                                                          • Integrated safety technology (S1)
                                                          • Digital encoder interfaces for 1-wire technology(TD)
                                                          • Simple commissioning
                                                          • Quick installation and wiring


                                                          Options
                                                          • CANopen® (I4)
                                                          • TD - HIPERFACE DSL® (TD)
                                                          • LinMot® encoder (TL)
                                                          • EnDat 2.2® (digital) (TE)
                                                          • Analog output +/-10 V (T6)
                                                        • JetMove 1008

                                                        • The JetMoves JM-1005 and JM-1008 are servo amplifiers for controlling motors from DC 24 ... 48 V up to 384 Watts with or without encoder in connection with Jetter controllers via EtherCAT® or CANopen®.

                                                          Features
                                                          • Compact design
                                                          • High positioning accuracy and quality of control
                                                          • Integrated safety technology (S1)
                                                          • Digital encoder interfaces for 1-wire technology(TD)
                                                          • Simple commissioning
                                                          • Quick installation and wiring

                                                          Options
                                                          • CANopen® (I4)
                                                          • TD - HIPERFACE DSL® (TD)
                                                          • LinMot® encoder (TL)
                                                          • EnDat 2.2® (digital) (TE)
                                                          • Analog output +/-10 V (T6)
                                                        • JetMove 1206

                                                        • The servo amplifier series JetMove 1000 series is a single-axis system. All of these devices are noted for their compact design, which means they take up very little space whether installed in the control cabinet or directly integrated into machinery. JetMove servo amplifiers are designed to provide a high level of continuous power and to guarantee highly dynamic acceleration processes through high rated currents and triple peak currents. Bus connection is via EtherCAT®.

                                                          Features
                                                          • Compact design
                                                          • High positioning accuracy
                                                          • EtherCAT® bus connection
                                                          • Integrated safety technology (S1)
                                                          • Brake resistor (R1)
                                                          • HIPERFACE DSL® (TD)
                                                          • User-friendly features:
                                                          - Autom. control loop optimization
                                                          - Cogging compensation
                                                          - Load cycle compensation
                                                          • Supported motor types:
                                                          - Synchronous and asynchronous motors
                                                          - Direct drives
                                                          - Torque and linear motors
                                                          • Simple commissioning
                                                        • JetMove 1407

                                                        • The servo amplifier series JetMove 1000 series is a single-axis system. All of these devices are noted for their compact design, which means they take up very little space whether installed in the control cabinet or directly integrated into machinery. JetMove servo amplifiers are designed to provide a high level of continuous power and to guarantee highly dynamic acceleration processes through high rated currents and triple peak currents. Bus connection is via EtherCAT®.

                                                          Features
                                                          • Compact design
                                                          • High positioning accuracy
                                                          • EtherCAT® bus connection
                                                          • Integrated safety technology
                                                          • HIPERFACE DSL® (TD)
                                                          • User-friendly features
                                                          - Autom. control loop optimization
                                                          - Cogging compensation
                                                          - Load cycle compensation
                                                          • Supported motor types:
                                                          - Synchronous and asynchronous motors
                                                          - Direct drives
                                                          - Torque and linear motor
                                                          • Simple commissioning
                                                        • JetMove 1416

                                                        • The servo amplifier series JetMove 1000 series is a single-axis system. All of these devices are noted for their compact design, which means they take up very little space whether installed in the control cabinet or directly integrated into machinery. JetMove servo amplifiers are designed to provide a high level of continuous power and to guarantee highly dynamic acceleration processes through high rated currents and triple peak currents. Bus connection is via EtherCAT®.

                                                          Features
                                                          • Compact design
                                                          • High positioning accuracy
                                                          • EtherCAT® bus connection
                                                          • Integrated safety technology
                                                          • HIPERFACE DSL® (TD)
                                                          • User-friendly features
                                                          - Autom. control loop optimization
                                                          - Cogging compensation
                                                          - Load cycle compensation
                                                          • Supported motor types:
                                                          - Synchronous and asynchronous motors
                                                          - Direct drives
                                                          - Torque and linear motors
                                                          • Simple commissioning
                                                      • JetMove 3xxx

                                                            • JetMove 3xxx

                                                            • Servo amplifiers of the JetMove 3000 series allow for modular design and expansion. They are connected with the supply unit via power bus system. Any servo amplifier of the JetMove 3000 series is available with a choice of 1-, 2- or 3-axis modules. This allows the creation of an individual, high-performance, multi-axis coordinated motion system. High rated currents and triple peak currents guarantee highly dynamic acceleration processes. Bus connection is via EtherCAT®.

                                                              Features
                                                              • Modular design
                                                              • Flexible power bus system
                                                              • Compact design
                                                              • Up to 3 axis modules per device
                                                              • High positioning accuracy
                                                              • EtherCAT® bus connection
                                                              • User-friendly features:
                                                              - Autom. control loop optimization
                                                              - Cogging compensation
                                                              - Load cycle compensation Integrated safety technology
                                                              • Supported motor types:
                                                              - Synchronous and asynchronous motors
                                                              - Direct drives
                                                              - Linear motors Simple commissioning

                                                              Options
                                                              • HIPERFACE DSL®
                                                              • Cold plate cooling
                                                              • Braking resistor (supply unit)
                                                        • Line Filters

                                                            • Line Filter - JM-1206

                                                            • External radio interference filters (JEMCxxx) are available for the servo amplifiers. With the prescribed measurement procedures and the external line filter, the servo amplifiers also satisfy the EMC product standards to IEC 61800--3 for First environment (residential C2) and Second environment (industrial C3). Several servo amplifiers can be connected to a line filter if the cable length between the line filter and the servo amplifiers is less than 1.5 meters.
                                                            • Line Filter - JM-14xx

                                                            • External radio interference filters (JEMCxxx) are available for the servo amplifiers.

                                                              With the prescribed measurement procedures and the external line filter, the servo amplifiers also satisfy the EMC product standards DIN EN 61800-3 resp. IEC 61800-3 for First environment (residential C2) and Second environment (industrial C3).

                                                              Several servo amplifiers can be connected to a line filter if the cable length between the line filter and the servo amplifiers is less than 1.5 meters.

                                                              Up to a motor cable length of 25 m the line filter integrated in the JM-1432 is sufficient. If the length exceeds 25 m, external line filters must be provided.
                                                            • Line Filter - JM-3xxx

                                                            • External radio interference filters (JEMCxxx) are available for the servo amplifiers.

                                                              With the prescribed measurement procedures and the external line filter, the servo amplifiers also satisfy the EMC product standards to IEC 61800--3 for First environment (residential C2) and Second environment (industrial C3).

                                                              The selection is made according to power (10 or 22 kW) and total cable length of the power cables of all axes (up to 120 m, up to 300 m, up to 600 m).
                                                          • Line Reactors

                                                              • Line Reactor - JM-1206

                                                              • The use of line reactors is optional for servo amplifiers with 3-phase mains supply. In the operating instructions you will find the reduced connected loads when feeding in with the recommended line reactor. This reduces the voltage distortions (THD) in the mains and increases the service life of the servo amplifier. Similar to line filters, several servo amplifiers can be connected to one line reactor.

                                                                It is imperative that the servo amplifier is connected via a line reactor in the following situations:
                                                                • if the servo amplifier is used in applications with transient disturbances corresponding to environment class 3, to EN 61000-2-4 and above (harsh industrial environments).
                                                                • with single-phase mains supply (e.g. JM-1206)
                                                                • for compliance with EN 61800-3 resp. IEC 61800-3
                                                              • Line Reactor - JM-14xx/JM-3xxx

                                                              • The use of line reactors is optional for 3-phase line filters. This reduces the voltage distortions (THD) in the mains and increases the service life of the servo amplifier. Similar to line filters, several servo amplifiers can be connected to one line reactor.

                                                                It is imperative that the servo amplifier is connected via a line reactor in the following situations:
                                                                • if the servo amplifier is used in applications with transient disturbances corresponding to environment class 3, to EN 61000-2-4 and above (harsh industrial environments).
                                                                • with single-phase mains supply (e.g. JM-1206)
                                                                • for compliance with EN 61800-3 resp. IEC 61800-3
                                                            • Brake Resistor

                                                                • Brake Resistor - JM-1xxx

                                                                • Servo amplifiers with the order option JM-1xx-xxR1xx have an integrated brake resistor. If this is not sufficient, external brake resistors are available. The User Manuals specify the minimum ohmic resistance permitted for an external brake resistor.

                                                                  On the JetMove 1416, the internal resistor is routed to outside terminals. After disconnecting the internal resistor, an external resistor can be connected here. For the other JM-1000s, a servo amplifier that does not contain an internal brake resistor (no option R1) must be used to connect an external resistor.
                                                                • Brake Resistor - JetMove 3xxx Series

                                                                • Supply units with the order option JM-3Pxx-xxR1xx have an integrated brake resistor.

                                                                  If this is not sufficient, external brake resistors are available. For an assignment of brake resistors to JetMove models see table. The User Manuals specify the minimum ohmic resistance permitted for an external brake resistor.

                                                                  On the JM-3000 supply units, the internal resistor is routed to outside terminals. After disconnecting the internal resistor, an external resistor can be connected here.
                                                              • Classic Drives

                                                                    • JetMove 225

                                                                    • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                                      Features
                                                                      • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                                      • 3 … 25 A
                                                                      • Supported motor types:
                                                                      - Synchronous and asynchronous motors
                                                                      - 3-phase stepper motors
                                                                      - Direct drives
                                                                      - Linear motors

                                                                      Options
                                                                      • Safe Standstill (STO = Safe Torque Off) (S1)
                                                                      • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                                      • Incremental encoder emulation (EMU)
                                                                      • Ethernet port (ETH)
                                                                      • Integrated controller (JC-310)
                                                                • Servomotors

                                                                      • Servomotors

                                                                      • Going with the servo amplifiers of the JetMove series are Jetter motors featuring DC link voltages of DC 24 to 560 V and a great selection of motor windings.

                                                                        By an appropriate combination you can achieve the speed which best fits your application and which also makes the most of the rated current of the servo amplifier used. All Jetter AG servo motors are extremely rugged 3-phase synchronous motors with UL certification. They are available in several series: JL, JK, JH, and JHN.

                                                                        Numerous options for connector outlets, degrees of protection and encoder design are available. Along with this comprehensive range of motors, we offer pre-fabricated and tested servo cables and corresponding gearboxes.

                                                                        JL motors
                                                                        JL motors cover the range from 0.1 Nm (JL1) to 115 Nm (JL8). They feature classic winding technology.

                                                                        JHN motors

                                                                        The segment winding technology on JHN motors has been automated and the motor structure optimized, providing high power density in a very compact design. The motors are available in sizes 2 to 7 with 0.28 Nm to 60 Nm.

                                                                        JHQ motors
                                                                        The JHQ motors comprise frame sizes 2-5 (JH) and 2-8 (JL). Further they have got two intermediate sizes, 23 and 45. Their high torque constant makes them an alternative to the so far used JL and JH motors if an adequate quantity of them is ordered.
                                                                  • Gears

                                                                        • Gears

                                                                        • Planetary gear units let you precisely adapt the speed and the force of a motor to specific customer applications. The optimum design depends on the relation between duty cycle with motion profile and gearbox, motor and servo amplifier design.

                                                                          Motion components selected and orchestrated this way mean long machine lifetime at economic allocation of resources.

                                                                          The transmission ratio of the 1- to 3-stage gear units ranges between i = 3 and i = 1000.
                                                                          The transmission rate lets you improve the ratio between external and internal rotor inertia - J load to J (motor and gear unit) - in such a way that smooth running of the axis is guaranteed, while resonant vibrations are prevented.

                                                                          We also offer gear units fitting for larger Jetter motors of flange size 7 to 8. If you wish, we also provide planetary gear units already connected with the Jetter servo motors.
                                                                    • Classic Drives

                                                                          • JetMove 225

                                                                          • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                                            Features
                                                                            • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                                            • 3 … 25 A
                                                                            • Supported motor types:
                                                                            - Synchronous and asynchronous motors
                                                                            - 3-phase stepper motors
                                                                            - Direct drives
                                                                            - Linear motors

                                                                            Options
                                                                            • Safe Standstill (STO = Safe Torque Off) (S1)
                                                                            • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                                            • Incremental encoder emulation (EMU)
                                                                            • Ethernet port (ETH)
                                                                            • Integrated controller (JC-310)
                                                                      • System Components

                                                                          • POWERTRACK

                                                                          • POWERTRACK allows for HMIs to be expanded by a rotary encoder and 6 user-programmable keys. POWERTRACK connected via CAN enables intuitive and efficient user guidance.

                                                                            Features
                                                                            • Easy-to-grip rotary encoder which can also be handled by a user wearing gloves
                                                                            • 6 user-programmable keys which can be labeled individually
                                                                            • Keys with multi-color LEDs for state reporting
                                                                            • Compact design (degree of protection: IP54)
                                                                            • CAN interface for CANopen® or SAE J1939 (optional)
                                                                          • POWERKEY PRO

                                                                          • The keyboard series POWERKEY PRO excels by its compact design. Being equipped with a CAN interface and keys which can be assigned by the user, this device opens up a wide range of application options. Meeting mobile machinery requirements can very easily be met this way.

                                                                            Features
                                                                            • The keys are raised so they can even be easily pressed by operators wearing gloves
                                                                            • User-programmable keys of layout 2x2, 3x2, 4x2, and 6x2
                                                                            • Individually printable key caps, standard: > 100 icons
                                                                            • Keys with multi-color LEDs for state reporting
                                                                            • Compact design (degree of protection: IP67)
                                                                            • CAN interface for CANopen® or SAE J1939 (optional)
                                                                          • Wiring Harnesses

                                                                          • Design and manufacturing of wiring harnesses are a decisive factor for the functional reliability of mobile machinery. Customized wiring harnesses enable implementing customer-specific features. Jetter AG provides long-year expertise in wiring harness technology.
                                                                          • RAM-MOUNT

                                                                          • Dash mounts by RAM Mount allow quick and easy positioning of HMIs for the perfect angle. For individual HMIs there are corresponding dash mounts and mounting solutions available.
                                                                        • Software

                                                                            • JetSym

                                                                            • JetSym is the central programming tool from Jetter AG, which combines all the automation technology functions. From programming the control system to commissioning entire systems, everything can be realized with JetSym.

                                                                              Features
                                                                              • Configuration
                                                                              • Programming
                                                                              • Debugging
                                                                              • Oscilloscope function
                                                                              • Commissioning
                                                                              • Diagnostics
                                                                              • Version management


                                                                              Minimum System Requirements
                                                                              • Windows® 7 SP1, Windows® 8.1 or Windows® 10
                                                                              • 2 GHz Processor
                                                                              • 2 GB RAM (4 GB recommended)
                                                                              • 300 MB available disk space
                                                                              • .NET-Framework 4.5.2
                                                                              • Microsoft® Internet Explorer


                                                                              The programming language STX

                                                                              STX meets all requirements of automation technology. Its syntax is based on IEC 61131-3 ST. With this process-oriented language, the real processes of a system can be directly mapped and described. High-performance commands for arithmetical calculations, axis handling, operator interaction and strings make programming of controllers much easier.

                                                                              The seamless integration of Motion Control significantly reduces programming expenditure for complex tasks. With STX, even complex axis motions, e.g., a movement of several axes in space, is astonishingly easily with just a single program command. Thus it is possible to create and test programs for complex machinery in the shortest time imaginable. Thanks to its process- and object-oriented approach, getting acquainted with STX is very easy.
                                                                            • JetViewSoft

                                                                            • The software tool JetViewSoft lets you easily visualize processes and design individual screens for HMIs. The proven object-oriented approach allows you to easily and efficiently complete even complex visualization tasks without previous experience. The user-friendly editor and a pool of predefined objects actively help you create screens in no time at all.

                                                                              Features
                                                                              • Supports scalable vector graphics and SVG import
                                                                              • Features gesture control for modern visualizations
                                                                              • Efficient design process thanks to object-oriented structure
                                                                              • Database with predefined objects and preview feature
                                                                              • Supports creation of multilingual screens and import/export of language resources
                                                                              • Alarm handling and trend graph
                                                                              • STX as scripting language lets you add new functions
                                                                              • Terminal Wizard and simple download to HMIs


                                                                              Minimum System Requirements
                                                                              • Windows® 7 SP1, Windows® 8.1 oder Windows® 10
                                                                              • 2 GHz Processor
                                                                              • 2 GB RAM
                                                                              • 400 MB available disk space
                                                                            • ISO-Designer

                                                                            • With the ISO-Designer from Jetter AG, it is simple to create ISOBUS-compliant files. ISO-Designer commands a high-performance graphical editor with a functional scope comparable to graphic programs. Many actions can easily be executed by a few mouse clicks.

                                                                              Properties:
                                                                              • Creating masks to ISO-11783 (.iop files) Graphics editor Convenient aligning/grouping Operating by Drag&Drop Zoom function Undo/Redo function Configurable GUI Smart copy function Object pool with preview function Library Bookmarks and history Supporting standards on all levels Automatic color space conversion Preview function Multilingualism is easy to implement


                                                                              Minimum System Requirements
                                                                              • Windows® 7 SP1, Windows® 8.1 oder Windows® 10
                                                                              • 2 GHz Processor 2 GB RAM
                                                                              • 400 MB available disk space
                                                                              • USB 2.0 port


                                                                              ISO-Designer – Get your license at no cost for an unlimited period.
