We optimize your hospital logistics! With driverless systems for the automatic transport of goods (awt), we secure the supply of wards, sterile departments and nursing areas of your facility - even over several floors.

References

TUSCANY HOSPITALS, ITALY
ek robotics has installed new ATS systems in four hospitals across Tuscany (Pistoia, Prato, Lucca and Massa). 44 transport robots are responsible for supplying approx. 1900 beds on the wards with not only meals for the patients, but also the transport of medicines, laundry and waste according to a fixed schedule.

NEW ROYAL ADELAIDE HOSPITAL, AUSTRALIA
With a local partner, ek robotics has equipped the most modern hospital in Australia, the New Royal Adelaide Hospital, with 25 fully automated AWT robots. Working to a precise plan, the 25 AGVs transport food, laundry containers, containers for sterile products and medical supplies.

HERLEV, KOPENHAGEN, DÄNEMARK
With over 1,600 hospital beds, Herlev Hospital is the largest building in Denmark. Here, ek robotics has installed an ATS system with 11 vehicles that are responsible for transporting a wide variety of rolling containers.

MOTOL, PRAGUE, CZECH REPUBLIC
With over 2400 patient beds, Motol Hospital is the largest in the Czech Republic. Here, the ek robotics service team looks after an ATS system installed in 1995 and ensures a reliable supply of meals to the hospital wards according to program-controlled planning. In addition, the ATS transport robots are responsible for waste and medication transport.

Without a bitter aftertaste: agv solutions for floor-level or block storage offering more flexibility for the beverage and food industry. Without additional costs for shelf installation.

References

MIELE, GÜTERSLOH, GERMANY
Heavy castings are required for production, which are fed to the production facilities fully automatically by the automated guided vehicle system. The racks with the cast components are targeted, safely and precisely controlled, stacked and unstacked in a block storage system with over 1,000 storage locations on 6 levels by 4 fully automatic SMART MOVE transport vehicles.

ARLA FOODS, AYLESBURY, UK
The Aylesbury, UK production site of Arla Foods houses the largest fresh milk production in the world. As an integral part of the intralogistics, ek robotics supply’s 90 CUSTOM MOVE vehicles in the chilled store. Over 10,000 storage spaces are managed in this floor block warehouse by the ek robotics transport manager, which also ensures that the vehicle fleet performs its tasks with maximum efficiency..

BREWERY, GERMANY
17 COMPACT MOVE vehicles from ek robotics supply the fully automated block storage system with over 10,000 storage locations of a well-known brewery in Germany. The AGVs are equipped with a double pallet handler attachment allowing transport of two pallets at the same time, stacking and de stacking them in a process-safe manner.

PET BOTTLE PRODUCTION, GERMANY
Unstable and unevenly shaped products, such as stacked PET bottles or canisters, place high demands on transport and storage. ek robotics uses 3D camera technology for this, which evaluates the storage situation in real time with software developed by ek robotics. This enables the driverless transport vehicle to recognise the exact position of the goods to be transported and the pallets.

Transport robots support employees in internal order picking processes. The transport robots assemble certain partial quantities on the basis of shipping or production orders. The vehicle is called picking AGV, picker or gripper. Here it is possible to have particularly routine or time-consuming transports carried out by transport robots. In the future, efficiency will be further optimised, for example by allowing goods to be sorted while they are still in transit.

References

Since 2008, 15 Compact 300 vehicles from the CUSTOM MOVE product group have been supplying prefabricated components to a renowned truck and bus manufacturer in Germany's axle production department. The picking racks are transported by drive-under vehicles with lifting rams.

Reaching your destination without congestion: individual agv transport systems with active or passive load handling devices. Workpieces can be mounted directly on the platforms or transported between the individual workplaces.

References

SML, GENK, BELGIUM
Over 100 ek robotics transport robots of the vehicle type CUSTOM MOVE are in use at the automotive supplier SML for the assembly of engines and axles. Within seven months, the transport robotics specialist designed and manufactured customised assembly vehicles and put them into operation during a 3-week shutdown. The engines and axles were delivered to the car manufacturer's SOP without interrupting production and just in time.

OEM, CHINA
For flexible engine assembly, 130 ek robotics transport vehicles were designed, manufactured and commissioned on site at an automotive plant in China.With the transport robots designed by ek robotics, the engines can be lifted, rotated and tilted as part of the assembly steps. This ensures particularly efficient and ergonomic working for the various assembly activities.

For yard & hall: in the future, indoor and outdoor transport robots will reliably and efficiently manoeuvre between your production halls and warehouses wherever you previously had to transport goods manually.

References

JTI, TRIER, GERMANY
For the transport of special storage containers, the tobacco company JTI use driverless transport vehicles from ek robotics in combined indoor and outdoor operation.
The CUSTOM MOVE transport robots from ek robotics, developed for outdoor operation, can be used 365 days a year, 24 hours a day, regardless of the weather conditions, thanks to the fast-charging technology and LI-ION batteries.

BAXTER, HECHINGEN, GERMANY
Since 2003, Baxter (formerly Gambro) has been using two fully automatic CUSTOM MOVE outdoor transport robots from ek robotics for the connection between the production building and the warehouse. By means of inductive track guidance and contactless energy transmission CPS, the driverless transport vehicles, specially designed for outdoor operation, are used.

GEROLSTEINER MINERALBRUNNEN, GEROLSTEIN, GERMANY
Gerolsteiner has been using driverless transport systems from ek robotics since 2013. Five CUSTOM MOVE transport robots with robust weather protection cladding are used for the area link between production and warehouse in the outdoor area.

We stack for you with precision in block, row or support arm storage systems, which are loaded by transport robots. Many product-specific parameters determine whether a static or dynamic storage system is created on site.

References

FLOW RACK
With the COMPACT MOVE, ek robotics offers a very compact, powerful transport robot that can be flexibly adapted to customer requirements.
For the application at a leading manufacturer of deodorants, shower and hygiene products, the transport robots dispose of the production and feed it to different storage areas.
A special requirement is the operation of the flow rack system with transfer heights of over four metres. Thanks to the integrated fork tilter, the pallets can be delivered here at the required angle of inclination.

Efficient towing! With fts drive trucks, which enable transports even over long distances while towing drive-less trailers, this is possible! A more than forward-looking solution for the transport of large loads.

References

MILK-RUN, COMMISSIONING, CZECH REPUBLIC
An automotive supplier uses four ek robotics SMART MOVE P30C tow tractors for parts picking in the supermarket and assembly line supply. The tractors have a capacity of 3,000 kg and pull four trailers simultaneously.

We continue to look higher and higher. Even where other suppliers have long since reached the end of the line due to constriction or lack of space. You can make full use of our agv transporters with swivel or telescopic forks – at heights of up to 14 metres.

References

DAW
The HEAVY MOVE VNA is a modular transport robot from ek robotics that can also be optimally used in narrow aisles. The driverless transport vehicles are compact, weight-optimised and individually adaptable to the inventory warehouse applications.
Error-tolerant load cycles are ensured by the 3D camera technology developed by ek robotics. This ensures that the pallets can be safely stored and retrieved despite many tolerances, such as uneven floors, yielding shelves or pallets.

DDH
In the area of narrow-aisle warehouses, ek robotics offers fully automated solutions with transfer heights of up to 14 metres. The transport robotics specialist automates conventional manual narrow-aisle stackers with the appropriate navigation technology and sensors which enables process-reliable load cycles even at high heights.

GEROLSTEINER
ek robotics also offers suitable fully automatic solutions for use in a mobile racking system, e.g. for storing packaging materials with a lower load turnover. In this way, an optimal space utilisation ratio is achieved.
ek robotics designs individual solutions for each mobile racking system, which are responsible for the storage of pallets or even long goods with lengths of up to six metres. Depending on the configuration of the system, the transfer heights can be up to 10 metres or more.

We can handle it for you! Up to 50 tons - we have the right vehicle for the transport of heavy loads.

References

PACKAGING MATERIAL, CARDBOARD BOXES, OUTDOOR
In its new plant of Tricor Packaging & Logistics in Bad Wöridshofen, two impressive ek robotics CUSTOM MOVE heavy-duty transport robots transport entire swap bodies for trucks. The swap bodies weighing almost 12,000 kg, are picked up by the omnidirectionally travelling AGV vehicles in a covered transfer zone in the outdoor area in an error-tolerant manner, using a lifting device and transported to the production for loading.

For us, you are unique! Especially when it comes to agv transport vehicles for specific project requirements, such as extreme temperatures, weights or hazard risks. We design one-of-a-kind vehicles that will last for decades.

References

CERAMICS INDUSTRY
Customised transport solutions and the highest engineering skills are combined in ek robotics' CUSTOM MOVE transport robots. We implement almost every task in a customised way so that the individual production processes of our customers can be served with an automatic transport system AGV.
For example, the ek robotics CUSTOM MOVE transports a tunnel kiln rack loaded with ceramic products weighing up to 16,000 kg, lifts them, tilts the forks for transport and transports them safely to their destination - without any problems.

GE JENBACHER
The manufacturer of gas engines and combined heat & power units INNIO Jenbacher has been relying on twelve CUSTOM MOVE transport robots from ek robotics for many years. The area-moving assembly platforms are equipped with a swivel device for ergonomic assembly on the gas engines, which weigh up to 25,000 kg.The passage of the assembly line takes place in a clocked manner. When assembly is complete, the CUSTOM MOVE vehicles reverse back to the start to be loaded with the next engine block.

AUTOMOTIVE SUPPLIER, PAINTING, HEAVY DUTY
Customised transport solutions combined with the highest engineering skills: CUSTOM MOVE transport robots from ek robotics. Almost every task is customised in such a way that the customer's individual production processes can be served with an AGV driverless transport system.
For example, the area-moving CUSTOM MOVE transports painting racks which are five metres wide and weigh up to 2,200 kg as well as lifting them up to a height of 4.5 metres - a 'can't do' doesn't exist.
