  • Offer Profile
  • For decades, the name Jetter AG has stood for highest demands on automation solutions that are used in a wide range of industrial and mobile automation sectors.

    Products and components by Jetter AG stand out thanks to their high degree of system integrity and diversity. Our in-house R&D departments (hardware and software), as well as our production plants in Germany allow us to always act in a quick and flexible manner.
Product Portfolio
  • Controllers

      • JetControl series

      • Controllers of the JetControl series come in all performance classes - from micro-controllers to high-performance, high-end controllers for complex Motion Control (MC) applications.

        Distinctive features common to all JetControl controllers:
        • Seamless integration of axis control into the controller. This makes programming even of complex axis motions very easy.
        • Multitasking OS
        • Commissioning and programming in STX - a high-level language to IEC-61131-3
        • Extensibility and flexibility thanks to a host of interfaces
        • Integrated web server as an option. This option lets you send e-mails and text messages from the application program.
          • JetControl 340

          • JetControl 340 is the optimum entry-level solution for basic automation tasks and offers ease of operation. It is most suitable for applications with no computing-intensive processes involved.

            Features
            • Supports up to 3 servo axes (point-to-point)
            • 1 MB STX program/data memory
            • 2,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • 1 CAN port
            • 1 serial port
            • Programming in STX - a high-level language to IEC-61131-3
            • File system for data storage
            • Easy servicing due to plug terminals and modular design

            Options
            • Number of axes (0, 3)
            • SD memory card slot (-SD)
            • Web and e-mail feature (-W)
            • Modbus TCP (-M)
          • JetControl 350

          • JetControl 350 combines high functionality with optimum performance. Thus, it is well equipped for a variety of applications.

            Features
            • Supports up to 8 servo axes (point-to-point)
            • 2 MB STX program/data memory
            • 30,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • SD memory card slot
            • Modbus TCP
            • 1 CAN port
            • 1 serial port
            • Programming in STX - a high-level language to IEC-61131-3
            • File system for data storage
            • Easy servicing due to plug terminals and modular design

            Options
            • Number of axes (4, 6, 8)
            • Web and e-mail feature (-W)
          • JetControl 365 | 365MC

          • JetControl 365 combines high performance with compact design. It is the optimum solution for CPU demanding and large applications. The JetControl 365 MC lets you enter into Motion Control (MC) functionality. It allows the programming of axis groups and complex path control applications.

            Features
            • Up to 16 point-to-point servo axes via CAN
            • Unlimited number of axes via Ethernet (JetMove 200-ETH)
            • Motion Control/path control of up to 12 axes (JetControl 365MC)
            • 24 MB STX program/data memory
            • 60,000 non-volatile registers
            • 1 Ethernet port with integrated switch
            • SD memory card slot
            • Modbus TCP
            • Integrated web and e-mail server

            Options
            • Number of axes (0, 4, 8, 16)
            • Number of axes with MC variant(4, 6, 8, 12)
            • Memory upgrade (totaling 120,000 non-volatile registers) (-R)
        • JetControl Mobile series

        • Controllers of the JetControl Mobile series can best meet the special demands made on mobile automation. Their pre-eminent trait is the combination of ultimate ruggedness, high and scalable CPU performance and the ability to implement individual customer requirements. The controllers can directly be built into the vehicle without a control cabinet being needed. This is space-saving and therefore allows for flexible installation.
            • JetControlMobile 501

            • The compact master controller JCM-501 forms the heart of compact, distributed architectures.

              With 2 CAN interfaces, RS232, USB and Ethernet port, as well as the proven, powerful 32-bit CPU it can be used in system solutions of simple to medium complexity.

              An integrated real-time clock completes the range of functions.

              Product features
              • Controller 32 bit/500 MHz Compact design High connectivity
            • JetControlMobile 511

            • The semi-modular compact controller JetControlMobile 511 is based on the modular JCM-521 series. Due to its vast I/O capacity featuring high-performance H-bridges, PWM outputs, flexibly applicable inputs and high total ampacity, even its basic configuration is already sufficient for numerous applications. Besides hydraulic actuators, it can even directly control electric motors. Extensibility by two MX modules allows for easily adjusting to a great variety of functions and applications.

              Besides standard ports and interfaces, the JCM-511 is equipped with inputs apt for NAMUR, as well as with a LIN port. This way, it can be integrated into almost any systems architecture.

              The high-level language STX to IEC 61131-3 lets you realize virtually any control task. Programming in C/C++ is possible, too.

              Features
              • 32-bit controller, 500 MHz Programming to IEC 61131-3 STX or in C/C++ Partially modular I/O configuration for high flexibility CAN, USB, LIN and RS232 port for high connectivity Compact design
            • JetControlMobile 521

            • The JCM-521 controllers are fully modular. They have been designed for control systems exacting requirements on flexibility and connectivity.

              The controllers consist of a main board and of MX modules which are expansions providing dissimilar features. The main board is equipped with a powerful CPU and FPGA. Depending on the desired configuration, either 6 or 15 MX modules are there to hold any combination of expansions. If all possibilities are made use of, up to 120 I/O connections can be provided. This way, I/O allocation can precisely be adjusted to any application object.

              An optional diagnostics display with controls features production data display, diagnostics and configuration on the spot without additional supporting devices such as PC or testing devices still being needed.

              Features
              • 32-bit controller, 500 MHz
              • Programming to IEC 61131-3 STX or in C/C++
              • Modular I/O configuration for high flexibility
              • CAN, USB, LIN, and RS232 port for high connectivity.
              • Built-in controls with graphic display
          • Safety Controllers

          • Controllers of the JetSafeControl series combine all requirements of your machinery as to productivity and cost effectiveness with an integrated safety concept.

            Typical safety functions can very easily be implemented by using existing features. In doing so, you have a comprehensive function library at your disposal, especially for safe drive monitoring. The modular combination of functions via logic blocks lets you set up safety functionalities tailored to your needs.
              • Expansion Modules

                  • JX3 modules

                      • JX3-AI4

                      • The JX3-AI4 module is an expansion module for connecting analog sensors.

                        Features
                        • 4 analog inputs
                        • Selectable input signal per channel
                        • Resolution: 16 bits Averaging
                        • User-defined scaling
                        • Monitoring of upper/lower limit
                        • Oscilloscope function
                        • Light-emitting diodes for monitoring communication and power supply
                        • Plug-in terminals

                        Options
                        • Galvanic isolation (-EI)
                        • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                      • JX3-AO4

                      • The JX3-AO4 module is an expansion module for connecting analog actuators.

                        Features
                        • 4 analog outputs
                        • Selectable output signal per channel
                        • Resolution: 16 bits
                        • User-defined scaling
                        • Monitoring of limit values
                        • Trailing indicator
                        • Capping
                        • Forcing
                        • Oscilloscope function
                        • Table mode
                        • Light-emitting diodes for monitoring communication and power supply
                        • Plug-in terminals

                        Options
                        • Pluggable field wiring terminals as 10-pin PUSH-IN terminal -(PI)
                      • JX3-BN-CAN

                      • The CAN bus node JX3-BN-CAN is for setting up remote I/O stations. The module is equipped with two bus ports (BUS-IN and BUS-OUT) to connect up standard system bus cables by Jetter AG.

                        Features
                        • Automatic addressing
                        • Automatic baud rate setting
                        • Automatic bus termination
                        • Up to 16 JX3 expansion modules can be connected up (corresponding to 256 I/O channels)
                        • Light-emitting diodes for monitoring communication and power supply
                    • JXM modules

                        • JXM-IO-E02

                        • The large number of individually configurable I/O connections, the high total current as well as the rugged and compact design make the JXM-IO-E02 a multi-purpose CAN remote node.

                          The supply voltage of the inputs and outputs is divided into Standard Feed and Protected Feed, and it allows for independent deactivation of inputs and outputs in safety applications.

                          The CAN ID of the I/O node can be defined via external connection of digital inputs. This way, up to nine nodes can be addressed within one system without further configuration measures to be taken.

                          Features
                          • Flexible I/O configuration
                          • The CAN addresses can be configured via wiring harness
                          • Compact and rugged enclosure
                          • High degree of protection IP66/IP68
                        • JXM-IO-E09

                        • The expansion module JXM-IO-E09 was designed as a high-current CAN node. It is for controlling power consumers such as spotlights or signal encoders in CANopen® networks.

                          Due to its small size, the module can be placed very flexibly very close to the consumer.

                          Features
                          • Rugged and compact enclosure
                          • High degree of protection IP67
                          • High total current
                          • CAN port
                        • JXM-IO-E11

                        • The expansion module JXM-IO-E11 has been designed for signal processing in the dashboard or in the driver's cabin. 20 digital switching signals, 3 analog joystick axes and a 4-way switch can be combined to be transmitted to the controller as a CAN message. Up to 24 LEDs can be controlled via CAN in parallel. Out of these, 20 LEDs can be dimmed individually. This way, a balanced background lighting within the HMI can be set, even if different light sources are used.

                          Features
                          • Grouping of discrete input and output signals
                          • CANopen® port
                          • 5 V power supply, built in
                          • Compact design
                      • HMIs

                          • JetView Series

                              • JetView 1004

                              • Besides its excellent performance, the HMI JetView 1004 impresses by its compact design and front panel sealing (up to IP66). This device can be easily integrated into existing networks thanks to its two Ethernet ports with integrated switch.

                                Features
                                • 4.3" TFT touchscreen
                                • 256 MB memory
                                • 2x Ethernet ports (with integrated switch)
                                • MMC or SD memory card slot
                                • IP66 (front panel)
                              • JetView 1005

                              • The HMIs JetView 1005 offer a universal widescreen display with Projected Capacitive Touchscreen (PCAP). The HMI has two Ethernet ports with switch functionality and is ideal for integration into existing networks. It comes with a scratch-proof and dirt-repellent real glass surface.

                                Features
                                • Seamless glass front panel
                                • Multi-touch
                                • WinCE operating system
                                • 2 Ethernet ports
                                • USB
                                • SD Card
                              • JetView 1007

                              • The HMIs JetView 1007 offer a universal widescreen display with Projected Capacitive Touchscreen (PCAP). The HMI has two Ethernet ports with switch functionality and is ideal for integration into existing networks. It comes with a scratch-proof and dirt-repellent real glass surface.

                                Features
                                • Seamless glass front panel
                                • Multi-touch
                                • WinCE operating system
                                • 2 Ethernet ports
                                • USB
                                • SD Card
                            • JetViewMobile series

                                • JetViewMobile 104

                                • With its compact design and rugged enclosure the JVM-104 is an ideal HMI for any application of mobile machinery. It is equipped with a powerful controller which can be expanded by additional I/O connections, as well as by one Ethernet and one USB port. This device saves you an extra controller for many applications. The HMI is operated via eight backlit keys, and a digipot with pushbutton. The built-in light sensor perfectly adapts the illumination of the display to the brightness of the surroundings.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • Flexible expandability
                                  • High connectivity
                                  • Customizable
                                  • Available either as a flush mount or as surface mount model
                                • JetViewMobile 407B

                                • With its elegant and high-quality design, the JVM-407B HMI is a standout product and can be supplied both as flush mount or surface mount model. To the left and right of the 7" display are 10 LEDs with typical automotive warning and indicator lights which can be directly controlled independently of the electronics. This allows the JVM-407B to be used as an instrument cluster. The integrated controller of the HMI is equipped with multi-purpose interfaces and can therefore be used as a powerful master controller for medium-size systems. A video input allows for integrating a rear view camera. The HMI is operated via four high-value backlit keys, as well as a push encoder, i.e. a digipot used as pushbutton. The acoustic signaling device produces an alarm loud enough to be heard even in noisy surroundings. A USB port at the front side allows for simple data interchange in the field.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • 3 CAN ports, Ethernet, SD card and front-side USB port
                                  • Video input
                                  • Integrated automotive LEDs
                                  • Elegant and high-value design
                                  • Available either as a flush mount or as surface mount model
                                • JetViewMobile 507B

                                • The HMI JVM-507B is equipped with a 7" display and 12 backlit keys with symbols printed to customer's wishes. The keys have been arranged right and left of the display. As an option, the HMI can be supplied with a resistive touch screen. This way, highly flexible and comprehensive operating concepts can be implemented. The HMI has been designed for installation in a double DIN slot in the dashboard. The integrated controller of the HMI is equipped with multi-purpose interfaces and can therefore be used as a powerful master controller for medium-size systems. Four video inputs allow for establishing high-level monitor applications. A light sensor allows for automatically adjusting to display brightness and key backlighting. The acoustic signaling device produces an alarm loud enough to be heard even in noisy surroundings.

                                  Features
                                  • Display with built-in controller 32 bits/500 MHz
                                  • Keys to be labeled
                                  • 2 CAN ports, Ethernet, microSD card and USB port
                                  • 4 video inputs
                                  • Rugged aluminum front panel
                              • Industrial PCs

                                  • JI-PCs

                                      • JI-PC 602

                                      • The industrial PC JI-PC 602 combines compact design with optimum performance. It can reliably handle any automation task thanks to a large number of interfaces and scalable CPU performance. Expansion slots enable the connection of standard fieldbuses. The JI-PC 602 can be operated directly in the control cabinet thanks to its 24 V power supply.

                                        Features
                                        • Compact
                                        • PCIe
                                        • 24 V power supply
                                        • Fanless (Intel® Core™ i5)
                                      • JI-PC 603

                                      • The industrial PC JI-PC 603 combines compact design with optimum performance. It can reliably handle any automation task thanks to a large number of interfaces and scalable CPU performance. Expansion slots enable the connection of standard fieldbuses. The JI-PC 603 can be operated directly in the control cabinet thanks to its 24 V power supply.

                                        Features
                                        • Compact
                                        • PCIe
                                        • 24 V power supply
                                        • Fanless (Intel® Core™ i5)
                                    • Flat panel PCs

                                        • JI-FPC1012

                                        • The flat panel PCs JI-FPC1012/1015/1022 are industrial PCs with widescreen display and Projected Capacitive Touchscreen (PCAP). Their screen sizes of 12.1" ... 21.5" offer sufficient room for monitoring and operating mid-sized plants. With MultiCore CPUs of the ATOM class, these HMIs are able to process several applications simultaneously. Thanks to their many interfaces they can be perfectly adapted to suit individual requirements. The seamless real glass surface is scratch-resistant and dirt-repellent.

                                          Features
                                          • Seamless real glass front panel
                                          • Widescreen (16:9)
                                          • Multi-touch
                                          • PCAP
                                          • DisplayPort™ for an additional monitor
                                          • Windows10 IoT
                                          • JetViewSoft visualization
                                          • QuadCore processor
                                          • 2x Ethernet ports
                                          • USB 2.0 +3.0
                                          • SD card slot
                                          • SSD
                                          • RS-232
                                          • Fanless


                                          Options
                                          • WLAN
                                          • RFID reader
                                          • Additional Ethernet port
                                          • Additional RS-xxx interface
                                        • JI-FPC1015

                                        • The flat panel PCs JI-FPC1012/1015/1022 are industrial PCs with widescreen display and Projected Capacitive Touchscreen (PCAP). Their screen sizes of 12.1" ... 21.5" offer sufficient room for monitoring and operating mid-sized plants. With MultiCore CPUs of the ATOM class, these HMIs are able to process several applications simultaneously. Thanks to their many interfaces they can be perfectly adapted to suit individual requirements. The seamless real glass surface is scratch-resistant and dirt-repellent.

                                          Features
                                          • Seamless real glass front panel
                                          • Widescreen (16:9)
                                          • Multi-touch
                                          • PCAP
                                          • DisplayPort™ for an additional monitor
                                          • Windows10 IoT
                                          • JetViewSoft visualization
                                          • QuadCore processor
                                          • 2x Ethernet ports
                                          • USB 2.0 +3.0
                                          • SD card slot
                                          • SSD
                                          • RS-232
                                          • Fanless


                                          Options
                                          • WLAN
                                          • RFID reader
                                          • Additional Ethernet port
                                          • Additional RS-xxx interface
                                      • Motion Systems

                                          • JetMove Series

                                              • JetMove 1xx - JetMove 105

                                              • The JetMove 105 has especially been designed for the voltage range from DC 12 to 48 V (up to 384 W). This servo amplifier supports all major motor types and offers space-saving installation due to its compact design.

                                                Features
                                                • DC 12 … 48 V
                                                • 5 A
                                                • Supported motor types:
                                                - Synchronous and asynchronous motors
                                                - 2-phase stepper motors
                                                - Direct drives
                                                - DC and BDC motors
                                                - Linear motors
                                                • Great number of integrated technological and special motion functions:
                                                - Electronic gearbox
                                                - Table function/cam disc
                                                - Dynamically changeable tables
                                                - Synchronizing of position and velocity
                                                - Print-mark correction
                                                - Winding function
                                                - Flying saw
                                                - Cross cutter
                                                - Torque/force control
                                              • JetMove 2xx - JM-D203

                                              • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                Features
                                                • 1-phase, AC 230 V up to
                                                • 3-phase, AC 400 V 3 … 25 A
                                                • Supported motor types:
                                                - Synchronous and asynchronous motors
                                                - 3-phase stepper motors
                                                - Direct drives
                                                - Linear motors

                                                Options
                                                • Safe Standstill (STO = Safe Torque Off) (S1)
                                                • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                • Incremental encoder emulation (EMU)
                                                • Ethernet port (ETH)
                                                • Integrated controller (JC-310)
                                              • JetMove 1xxx - JM-1005

                                              • The JetMoves JM-1005 and JM-1008 are servo amplifiers for controlling motors from DC 24 ... 48 V up to 384 Watts with or without encoder in connection with Jetter controllers via EtherCAT® or CANopen®.

                                                Features
                                                • Compact design
                                                • High positioning accuracy and quality of control
                                                • Integrated safety technology (S1)
                                                • Digital encoder interfaces for 1-wire technology(TD)
                                                • Simple commissioning
                                                • Quick installation and wiring


                                                Options
                                                • CANopen® (I4)
                                                • TD - HIPERFACE DSL® (TD)
                                                • LinMot® encoder (TL)
                                                • EnDat 2.2® (digital) (TE)
                                                • Analog output +/-10 V (T6)
                                            • Classic Drives

                                                  • JetMove 225

                                                  • The servo amplifier series JetMove 200 covers the complete voltage range from 1-phase AC 230 V to 3-phase AC 400 V. They can handle currents of up to 25 A.

                                                    Features
                                                    • 1-phase, AC 230 V up to 3-phase, AC 400 V
                                                    • 3 … 25 A
                                                    • Supported motor types:
                                                    - Synchronous and asynchronous motors
                                                    - 3-phase stepper motors
                                                    - Direct drives
                                                    - Linear motors

                                                    Options
                                                    • Safe Standstill (STO = Safe Torque Off) (S1)
                                                    • Second encoder input (CNT) (incremental, SSI, EnDat 2.2 (without analog signals))
                                                    • Incremental encoder emulation (EMU)
                                                    • Ethernet port (ETH)
                                                    • Integrated controller (JC-310)
                                              • Software

                                                  • JetSym

                                                  • JetSym is the central programming tool from Jetter AG, which combines all the automation technology functions. From programming the control system to commissioning entire systems, everything can be realized with JetSym.

                                                    Features
                                                    • Configuration
                                                    • Programming
                                                    • Debugging
                                                    • Oscilloscope function
                                                    • Commissioning
                                                    • Diagnostics
                                                    • Version management


                                                    Minimum System Requirements
                                                    • Windows® 7 SP1, Windows® 8.1 or Windows® 10
                                                    • 2 GHz Processor
                                                    • 2 GB RAM (4 GB recommended)
                                                    • 300 MB available disk space
                                                    • .NET-Framework 4.5.2
                                                    • Microsoft® Internet Explorer


                                                    The programming language STX

                                                    STX meets all requirements of automation technology. Its syntax is based on IEC 61131-3 ST. With this process-oriented language, the real processes of a system can be directly mapped and described. High-performance commands for arithmetical calculations, axis handling, operator interaction and strings make programming of controllers much easier.

                                                    The seamless integration of Motion Control significantly reduces programming expenditure for complex tasks. With STX, even complex axis motions, e.g., a movement of several axes in space, is astonishingly easily with just a single program command. Thus it is possible to create and test programs for complex machinery in the shortest time imaginable. Thanks to its process- and object-oriented approach, getting acquainted with STX is very easy.
                                                  • JetViewSoft

                                                  • The software tool JetViewSoft lets you easily visualize processes and design individual screens for HMIs. The proven object-oriented approach allows you to easily and efficiently complete even complex visualization tasks without previous experience. The user-friendly editor and a pool of predefined objects actively help you create screens in no time at all.

                                                    Features
                                                    • Supports scalable vector graphics and SVG import
                                                    • Features gesture control for modern visualizations
                                                    • Efficient design process thanks to object-oriented structure
                                                    • Database with predefined objects and preview feature
                                                    • Supports creation of multilingual screens and import/export of language resources
                                                    • Alarm handling and trend graph
                                                    • STX as scripting language lets you add new functions
                                                    • Terminal Wizard and simple download to HMIs


                                                    Minimum System Requirements
                                                    • Windows® 7 SP1, Windows® 8.1 oder Windows® 10
                                                    • 2 GHz Processor
                                                    • 2 GB RAM
                                                    • 400 MB available disk space
                                                  • ISO-Designer

                                                  • With the ISO-Designer from Jetter AG, it is simple to create ISOBUS-compliant files. ISO-Designer commands a high-performance graphical editor with a functional scope comparable to graphic programs. Many actions can easily be executed by a few mouse clicks.

                                                    Properties:
                                                    • Creating masks to ISO-11783 (.iop files) Graphics editor Convenient aligning/grouping Operating by Drag&Drop Zoom function Undo/Redo function Configurable GUI Smart copy function Object pool with preview function Library Bookmarks and history Supporting standards on all levels Automatic color space conversion Preview function Multilingualism is easy to implement


                                                    Minimum System Requirements
                                                    • Windows® 7 SP1, Windows® 8.1 oder Windows® 10
                                                    • 2 GHz Processor 2 GB RAM
                                                    • 400 MB available disk space
                                                    • USB 2.0 port


                                                    ISO-Designer – Get your license at no cost for an unlimited period.
