Mikrotron presents the new EoSens® 21CXP2 and EoSens® 10CXP2 cameras

Photo by Mikrotron GmbH

Outstanding image acquisition speed

Based on the Gpixel CMOS sensors GSPRINT4521 and GSPRINT4510 with global shutter, the new EoSens® 21CXP2 and EoSens® 10CXP2 combine a resolution of 21 and 10 megapixels, with a pixel size of 4.5 µm, as well as high sensitivity and outstanding image acquisition speed, enabling 230 fps and 478 fps, when using full resolution. By reducing the sensor area read out, it is possible to achieve significantly faster image acquisition and, for example, a frame rate of 5,543 fps for images with 5,120 x 128 pixels. The integrated CoaXPress-12 interface with 4x 12.5 Gbit/s handles the resulting large volumes of data without any latency times and thus ensures a reliable and fast transfer of the captured monochrome or color images to the connected processing system.

Sharp image down to the to the smallest detail

The global shutter sensor used enables sharp imaging down to the smallest detail, even with moving objects. The Mikrotron camera is therefore the perfect choice for many industrial applications in which inspection parts are frequently moved past the image processing station on conveyor belts, in order to reliably detect even the smallest defects, even at high process speeds.

The EoSens® 21CXP2 is an ideal imaging solution, especially for 3D laser profiling, due to its large sensor and opens up high-speed laser triangulation systems with large scan coverage for precise 3D measurements. The use of binning increases the camera’s signal-to-noise ratio, which lowers the required laser power and enables higher resolution to be achieved even with high image amplification.

Even for most difficult industrial environments suitable

With the EoSens® 21CXP2 and the EoSens® 10CXP2, Mikrotron provides two outstanding camera options to users in a wide range of industries, including electronics, automotive, motion analysis, life science, metrology, and many more. The cameras enable very fast acquisition of high-quality, high-resolution images, bringing great advantages in throughput and defect inspection. Intelligent features such as switching between 1, 2 or 4 CoaXPress channels, various binning modes or a controllable fan contribute to the camera’s practicality, as do the compact dimensions of 80 x 80 x 72.8 mm and the robust metal housing, which enables easy system integration and withstands even harsh industrial environments.
