New Piranha4™ 2k line scan cameras released by Teledyne DALSA

teledyne line scan cameras

Piranha4 2k CMOS Line Scan Camera
Photo by Teledyne DALSA Inc

Teledyne DALSA, a Teledyne Technologies company and global leader in machine vision technology, today released two new versions of its successful Piranha4™ series, expanding its flagship line scan family to more than ten models. The new line scan cameras have 2k resolution and an advanced feature set to help customers solve challenging machine vision inspection problems. The new models combine advancements in Teledyne DALSA’s CMOS image sensor technology with exceptional signal-to-noise ratio for unparalleled high speed monochrome and color imaging.

“Our customers often have demanding applications,” said Xing-Fei He, Senior Product Manager for line scan imaging at Teledyne DALSA. “The new Piranha4 2k cameras not only deliver high speed and responsivity, they also include a great feature set including high dynamic range mode. Both cameras can operate at any angle to the web, providing greater flexibility for vision system designs.”

The new monochrome Piranha4 dual line scan camera delivers a maximum line rate of 100 kHz in TDI mode, or 200 kHz in Area mode. The Piranha4 2k trilinear model delivers a maximum line rate of 70 kHz. Advanced features include sub-pixel spatial correction, lens and shading correction, and flat field correction.

Both the color and monochrome models use advanced chipsets to deliver high throughput with extended Camera Link cable lengths to 30 meters. The GenICam™ compliant interface makes the Piranha4 2k easy to set up, control, and integrate.

Applications

The Piranha4 2k models are ideal for high speed inspection applications in both color and monochrome. Color applications include 100% print inspection, banknote inspection, package and label inspection, and food inspection. Monochrome applications include railway inspection, printing, wood, film, and label inspection, and general machine vision applications.

Product Details and Availability

Key features and benefits include:

Area mode enables the Piranha4 2k dual line scan camera to operate two times faster (200 kHz) for increased web speed, while the ability to operate in TDI mode (100 kHz) provides better responsivity and signal-to-noise ratio

High dynamic range mode allows longer exposure time on one line and shorter on the second line to capture even more detail

Sub-pixel spatial correction enables imaging in aspect ratios other than 1:1 to increase web speed and allow precise color registration

Multi-angle positioning allows the new Piranha4 cameras to bepositioned at any angle, in addition to being perpendicular to the web, providing greater flexibility for optimal system designs.

For more information,please visit www.teledynedalsa.com.
