Kathrein Solutions’s RTLS UWB-based localization solution utilized for pre-series production of german cars

Photo by Kathrein RFID

Starting in 2020, a German car manufacturer has opted for the UWB-based localization solution from Kathrein Solutions. The result: Vehicles and parts supply trolleys localized with an accuracy of only a few centimeters. The RTLS solution ensures the localization on three building levels.

The production of pre-series vehicles in the automotive industry represents the starting point for a new generation of vehicles. The location for these trials is the pre-series center. What exactly happens there? Technological innovations are tested. Just like in an experimental laboratory, all production processes are tested right up to the final start of series production. Component and production technologies are closely scrutinized. One of the main objectives of pre-series development is to ensure the economic efficiency of production. Preliminary considerations regarding purchase and logistics are, therefore, also part of the concept phase. In this planning phase, it becomes abundantly clear that the transparency of all results and decisions is the key to success and to the adherence of exact schedules.

“Combining IoT technologies creates the springboard to the digital future. The combination of UWB with RFID and NFC increases the transparency and efficiency of a solution. Kathrein Solutions implements complex solutions that generate measurable added value within a short time. The result: Short implementations and fast ROIs.” (Emre Gürbüz, Head of Professional Services, Kathrein Solutions)

The Objective of Pre-Series Production

Pre-series production represents the decisive development phase between prototype development and series production of a vehicle. In pre-series production, all process-related requirements for series production are tested and examined for weak points. Also analyzed are the punctual provision of all components, the technical maturity of the vehicles, the necessary workstations and production stations, the adaptation of production tools, and the training of employees. The pre-series ensures that the pilot series does not have to overcome any start-up difficulties.

Aspects of Pre-Series Production

In the pre-series, all processes that are indispensable for on-time production are defined, tested and approved. This includes the following aspects:

  • Strategy and organization of the series start-up
  • Management of required changes to the vehicle
  • Review and adjustment of costs
  • Test and configuration of production control and tools
  • Involvement of all suppliers
  • Management of all upstream, intermediate and downstream logistics processes

The Following Questions are Scrutinized

  • How mature are the vehicles?
  • Is the availability of the production and logistics facilities guaranteed?
  • Do the targeted production figures correspond to the existing plant capacities?
  • Are supplier and service provider contracts resilient?
  • Is the degree of qualification of the production and logistics staff congruent with the complexity of the vehicle to be produced?

UWB-Based Localization Since the Start of 2020

Since the beginning of 2020, the German car manufacturer has been using the new UWB localization system K-RTLS from Kathrein Solutions in the productive operation of the pre-series. All pre-series vehicles are marked with Kathrein UWB transponders. For the first time, the transponders combine different wireless IoT technologies: In addition to UWB, UHF RFID and NFC interfaces are also integrated. All three technologies are connected in the transponder via I²C with the RTLS controller. The transponder can thus be detected via different technologies.

Localization on Three Floors

The pre-series, like the series production later on, has numerous special workstations. All production stations are designed for dedicated activities, and vehicles usually have to pass through these workstations in a sequence. At the same time, the corresponding commissioning trolleys, with the components specifically prepared for the vehicle, must also be available. The pre-series center covers three floors within a building. Vehicles and parts supply trolleys for the commissioning of vehicle-specific components must be recorded exactly at their current positions. “The implemented localization transparency revolutionizes the work in the pre-series center. The technology provides significant support in visualizing process sequences almost in real time and enables the employees to intervene in a controlled manner – even before time schedules and objectives are in danger of being delayed”, says Emre Gürbüz, underlining the advantages of the RTLS solution.

Hardware: RFID and RTLS

“When a vehicle body that has already been partially assembled and tagged with a UHF RFID label reaches the pre-series center, the ID of the label is automatically ‘married’ to the UWB transponder. From this point on, the vehicle can be precisely located on all three levels of the pre-series building with an exact accuracy of up to 30 centimeters,” says Emre Gürbüz, describing the RTLS process. In addition to the vehicles, the commissioning trolleys are also marked with identically coded transponders. Vehicles and parts supply trolleys continuously and automatically report their current position in real time. An intelligent motion sensor integrated in the transponder ensures that only process-relevant position changes are transmitted. A 256-color LED provides employees with visual feedback on communication and localization processes.

Software IoT Suite Controls All Processes

All localization information converges in the Kathrein CrossTalk IoT Suite. The standardized software solution CrossTalk is used as an elementary tool to make the entire process flow in the pre-series center transparent. “CrossTalk not only reports all relevant process steps to the backend system of the pre-series center, it also monitors all process flows. The IoT Suite can thus alert employees in the control system at any time to prevent delays or even signal when free capacities are available,” explains Emre Gürbüz.

For more information, please visit http://www.ks-rfid.de.
