Meusburger and Bihler demonstrated their new standardised stamping and forming die set at Blechexpo 2019

The SBP stamping and forming die set with spring-loaded guiding plate from Meusburger
Photo by Meusburger Georg GmbH & Co KG

At Blechexpo 2019 in Stuttgart, the Meusburger stand featured the brand new standardised stamping and forming die set from Meusburger and Bihler. The companies WBI and Segoni also offered a glimpse into their product range.

A special highlight at the Blechexpo was the standardised stamping and forming die set, which is the first of its kind and was developed in cooperation with Bihler for the Bihler NC presses. The new die sets in types ‘tunnel cut’ or ‘spring-loaded guiding plate’ are available for stamping presses with forces up to 400 kN and promise to bring enormous savings in time and cost for Meusburger and Bihler customers in future.

FROM SMALL BATCHES TO LARGE QUANTITIES

The newly developed SB stamping and forming die sets are offered for Bihler NC presses with stamping forces of 200kN, 300kN and 400kN. The die sets are available in lengths up to 596 mm and in the types ‘SBH tunnel cut’ or ‘SBP spring-loaded guiding plate’. While the tunnel cut version is primarily used for prototypes and small batches, the version with spring-loaded guiding plate is ideally suited for producing high precision parts and large quantities.

BENEFITS FOR CUSTOMERS

The standardisation of stamping and forming die sets has great advantages: they are significantly more cost-effective, and they are available from stock. The die sets themselves also offer many product advantages – such as: precision alignment edges and practical anti-rotation protection, as well as helpful mounting threads in the plates for pull handles, eye bolts and spacer discs, and useful vent holes.

EVERYTHING FROM A SINGLE SOURCE

In addition to Meusburger, the associated companies WBI and Segoni also presented their range of products for mould and die makers to the trade fair visitors. WBI Knowledge Management introduced their software specially developed for the knowledge management method. With this software, the resource of knowledge can be collected, shared, further developed and saved thus preventing the loss of important know-how.

Segoni in turn offered a live presentation of the latest version of their software which enables efficient production planning and focuses on companies with individual production structures active in the fields of mould, die, and jigs and fixtures construction. They also provided information for visitors on the use and capabilities of the system.

For more information, please visit http://www.meusburger.com.
