pco.edge 10 bi CLHS

The all new pco.edge 10 bi CLHS sCMOS back illuminated camera with 4 x 25 Gbit/s fiber-optic Camera Link HS interface will be presented for the first time at this year’s Vision show in Stuttgart at the PCO Booth 10E51 from October 5^th – 7^th.

This camera can especially exploit its full performance in microscopy applications with a larger image circle. High resolution and low noise at high frame rate are ideal qualities for life science applications like high content screening, high resolution digital pathology, flow cytometry, widefield microscopy of big samples, and super-resolution localization microscopy. Furthermore, based on the optical CLHS technology interface, the pco.edge 10 bi CLHS is also ideal for physical sciences, i.e. PIV flow visualization applications based on true charge domain global shutter, with excellent shutter ratio, high frame rate, and double shutter technology.Top features pco.edge 10 bi CLHS:

Top features pco.edge 10 bi CLHS:

• 4/3” 10 MPixel (4344 x 2368 pixels)
• 4.6 µm pitch for smaller magnifications
• Larger image circle – 22.8 mm
• Back illuminated technology (QE: 85 % @ 500 nm)
• Dynamic range 1 : 28,000
• NIR enhanced QE 30 % @ 900 nm

• Low readout noise: 0.7 e- @ 5 fps
• Low dark current
• High MTF based on Deep Trench Isolation (DTI) technology

• 4 x 25 Gbit/s fiber-optic Camera Link HS interface
• Forced air (fan) cooling with DT = 45 °C
• Water cooling with DT = 50 °C
• Frame rate 120 fps @ 16 bit
• Lightsheet scanning mode
